E900BT E900 BT Teardown Internal Photos - FCC ID 2A25A-E900BT

FCC ID 2A25A-E900BT

Internal photos

E900 BT

by YI ZHAO (SHENZHEN) CO., LIMITED.

Document preview loads when visible.

Document Details

FCC ID2A25A-E900BT
Document ID7733002
Document TypeInternal Photos
DescriptionInternal photos
ApplicantYI ZHAO (SHENZHEN) CO., LIMITED.
Equipment ClassE900 BT
Product CodeE900BT
Application IDVhVb0IOp1Vkk0aAIsd3ZAw==
Application PurposeOriginal Equipment
Application Date2024-10-14
Frequency Range2402-2480 MHz
FRN0031347248
Test FirmShenzhen Microtest Co., Ltd.
Certified ByJenny Qiu Purchasing Manager
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2024-10-14
Available2024-10-14
Created2024-10-10
Modified2024-10-10
Pages5
File TypeAdobe Acrobat PDF
File Size595750
File SHA-256cea8fb7e00456149bb60eb5666068cf7b757a704bedd8c71ee4dafebbcdd8da4
PDF Metadata AuthorHank Yan
PDF Metadata ProducerHank Yan Adobe PDF Library 15.0
FCC.gov SourcesFCC.gov 7733002
