V20 Smartphone Label Diagram - FCC ID 2A2EB-V20

FCC ID 2A2EB-V20

Label and Label Location

Smartphone

by MCMLXV

Document preview loads when visible.

Document Details

FCC ID2A2EB-V20
Document ID5334595
Document TypeID Label/Location Info
DescriptionLabel and Label Location
ApplicantMCMLXV
Equipment ClassSmartphone
Product CodeV20
Application IDiBwhqoj/cjKoPAim3vAV1g==
Application PurposeOriginal Equipment
Application Date2021-07-10
Frequency Range1710-1755 MHz
FRN0030904312
Test FirmShenzhen Tongzhou Testing Co., LTD
Certified ByVortex Cellular
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceYes
Composite PartNo
Submitted2021-07-10
Available2021-07-10
Created2021-06-25
Modified2021-07-09
Pages1
File TypeAdobe Acrobat PDF
File Size362589
File SHA-2561b9e2ca693eea61958f736f1b39e7746874dc696357594f574ce613474464ebe
PDF Metadata ProducerPDFsharp 1.50.5147 (www.pdfsharp.com) (Original: Microsoft® Word 2010) Microsoft® Word 2010
FCC.gov SourcesFCC.gov 5334595, FCC.gov 5333817, FCC.gov 5333777
