NHH1SL1 N-Series Digital Wireless System... - FCC ID 2A3FT-NHH1SL1

FCC ID 2A3FT-NHH1SL1

Test_Setup_Photos

N-Series Digital Wireless System Handheld Transmitter

by DPA Microphones A/S

Document preview loads when visible.

Document Details

FCC ID2A3FT-NHH1SL1
Document ID8543998
Document TypeTest Setup Photos
DescriptionTest_Setup_Photos
ApplicantDPA Microphones A/S
Equipment ClassN-Series Digital Wireless System Handheld Transmitter
Product CodeNHH1SL1
Application IDC+0t8RvyC1GfguollHDS3A==
Application PurposeOriginal Equipment
Application Date2025-08-06
Frequency Range470-608 MHz
FRN0031532708
Test Firmcetecom advanced GmbH
Certified ByNiels Schou Frederiksen
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2025-08-06
Available2025-08-06
Pages5
File TypeAdobe Acrobat PDF
File Size455720
File SHA-25697e6fd7ff7cbb862c68deb76accfa8c11a53fac7a7762c84d6401df6c5cf6639
PDF Metadata ProducerPrince 20240827 (www.princexml.com)
FCC.gov SourcesFCC.gov 8543998
