VMM50 UHF RFID Reader Module Test Setup Photos - FCC ID 2A3H9VM-M50
FCC ID 2A3H9VM-M50
Test setup
UHF RFID Reader Module
Document preview loads when visible.
Document Details
| FCC ID | 2A3H9VM-M50 |
|---|---|
| Document ID | 6760454 |
| Document Type | Test Setup Photos |
| Description | Test setup |
| Document Title | HD 271 S1 |
| Applicant | Shenzhen Vanch Intelligent Technology Co.,Ltd |
| Equipment Class | UHF RFID Reader Module |
| Product Code | VMM50 |
| Application ID | +ZdkuPt2IrUO8ejH4SIVVw== |
| Application Purpose | Original Equipment |
| Application Date | 2023-08-26 |
| Frequency Range | 902.25-927.75 MHz |
| FRN | 0031559685 |
| Test Firm | JianYan Testing Group Shenzhen Co., Ltd. |
| Certified By | Bruce Zhang EMC Laboratory Manager |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Grant Deferral | No |
| Modular Equipment | Single Modular Approval |
| Composite Device | No |
| Composite Part | No |
| Submitted | 2023-08-26 |
| Available | 2023-08-26 |
| Created | 2023-08-11 |
| Modified | 2023-08-11 |
| Pages | 1 |
| File Type | Adobe Acrobat PDF |
| File Size | 223815 |
| File SHA-256 | 5c047cb15701cd045c6cd3b6a72089720e63bdab7df4dda2ee65971d69ed3a47 |
| PDF Metadata Author | LAB02 |
| PDF Metadata Producer | LAB02 Microsoft® Word 2010 |
| FCC.gov Sources | FCC.gov 6760454 |
