RA86 Mobile Radio Teardown Internal Photos - FCC ID 2A3OORA86
FCC ID 2A3OORA86
Internal Photos
Mobile Radio
Document preview loads when visible.
Document Details
| FCC ID | 2A3OORA86 |
|---|---|
| Document ID | 6280044 |
| Document Type | Internal Photos |
| Description | Internal Photos |
| Document Title | ATTACHMENT PHOTOGRAPHS OF EUT |
| Applicant | Shenzhen Ysair Technology Co., LTD |
| Equipment Class | Mobile Radio |
| Product Code | RA86 |
| Application ID | EefKhS6t3EyXy+NkYbkMsg== |
| Application Purpose | Original Equipment |
| Application Date | 2022-12-15 |
| Frequency Range | 462.55-462.725 MHz |
| FRN | 0031641426 |
| Test Firm | Shenzhen Accurate Technology Co., Ltd. |
| Certified By | Weidong Shen |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | Yes |
| Composite Part | No |
| Submitted | 2022-12-15 |
| Available | 2022-12-15 |
| Created | 2022-12-05 |
| Modified | 2022-12-05 |
| Pages | 6 |
| File Type | Adobe Acrobat PDF |
| File Size | 1169718 |
| File SHA-256 | 5b29eea01e660b71089ee8d61fd44952bccc4b100f6823a3d4be97ffe9eefa7f |
| PDF Metadata Author | 高莹莹 |
| PDF Metadata Producer | Microsoft® Office Word 2007 Microsoft® Office Word 2007 |
| FCC.gov Sources | FCC.gov 6280044, FCC.gov 6279998 |
