7824 Digital Media Receiver Test Setup Photos - FCC ID 2A4DH-7824

FCC ID 2A4DH-7824

2A4DH-7824_FCC RF_Spot Check_Setup Photo

Digital Media Receiver

by Amazon.com Services LLC

Document preview loads when visible.

Document Details

FCC ID2A4DH-7824
Document ID8642155
Document TypeTest Setup Photos
Description2A4DH-7824_FCC RF_Spot Check_Setup Photo
Document TitleFCC RF Test Report
ApplicantAmazon.com Services LLC
Equipment ClassDigital Media Receiver
Product Code7824
Application IDoy/0tMNigSly4cLFocRIug==
Application PurposeOriginal Equipment
Application Date2025-09-30
Frequency Range5955-7115 MHz
FRN0026561829
Test FirmSporton International Inc. (Kunshan)
Certified ByTunji Yusuf
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Modular EquipmentDoes not apply
Composite DeviceYes
Submitted2025-09-04
Available2026-03-29
Created2025-04-11
Modified2025-04-11
Pages5
File TypeAdobe Acrobat PDF
File Size758723
File SHA-256f7a393d4a1815e84e69cd1c14b02455d29f0a4ce4a90c29d35ef5b972d4a93c5
PDF Metadata AuthorWBU Documentation Depr.
PDF Metadata ProducerMicrosoft® Word 2013 Microsoft® Word 2013
FCC.gov SourcesFCC.gov 8642155, FCC.gov 8642112, FCC.gov 8642052, FCC.gov 8642021, FCC.gov 8641983
