NABE5 IoT Device Test Setup Photos - FCC ID 2A4GZ-NABE5

FCC ID 2A4GZ-NABE5

Test Setup Photos

IoT Device

by Brightway Innovation Intelligent Technology (Suzhou) Co., Ltd.

Document preview loads when visible.

Document Details

FCC ID2A4GZ-NABE5
Document ID7485424
Document TypeTest Setup Photos
DescriptionTest Setup Photos
ApplicantBrightway Innovation Intelligent Technology (Suzhou) Co., Ltd.
Equipment ClassIoT Device
Product CodeNABE5
Application IDui97tbJOmagA5N6bVOopTQ==
Application PurposeOriginal Equipment
Application Date2024-07-18
Frequency Range2402-2480 MHz
FRN0031966674
Test FirmBay Area Compliance Laboratories Corp. (Kunshan)
Certified ByWentao Shi
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceYes
Composite PartNo
Submitted2024-07-18
Available2024-07-18
Created2024-07-08
Modified2024-07-08
Pages4
File TypeAdobe Acrobat PDF
File Size1369495
File SHA-2562fb7c9df9451d6edafa5f5a6125e1da2dfa159069e3887291cbdb555912ce5fe
PDF Metadata Authorbaclks96
PDF Metadata Producerbaclks96 Acrobat Distiller 20.0 (Windows)
FCC.gov SourcesFCC.gov 7485424
