PN007A vehicle player Test Setup Photos - FCC ID 2A4LQ-PN007A

FCC ID 2A4LQ-PN007A

Test Setup Photos

vehicle player

by Shenzhen Cheluzhe technology co., LTD

Document preview loads when visible.

Document Details

FCC ID2A4LQ-PN007A
Document ID7417130
Document TypeTest Setup Photos
DescriptionTest Setup Photos
ApplicantShenzhen Cheluzhe technology co., LTD
Equipment Classvehicle player
Product CodePN007A
Application IDsyFNLDuOpZI+5xdVEFp3Sw==
Application PurposeOriginal Equipment
Application Date2024-06-21
Frequency Range2412-2462 MHz
FRN0031977689
Test FirmSHENZHEN CTA TESTING TECHNOLOGY CO., LTD.
Certified ByZhikun Zheng Manager
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceYes
Composite PartNo
Submitted2024-06-21
Available2024-06-21
Created2024-06-20
Modified0002-01-01
Pages1
File TypeAdobe Acrobat PDF
File Size140245
File SHA-256eec785edfcafee12cc1296b451a0f83268fab2f8b74c3f5a2c25acbea5410c3f
PDF Metadata ProducerMicrosoft® Word 2016 Microsoft® Word 2016
FCC.gov SourcesFCC.gov 7417130, FCC.gov 7417089
