MWEPB08 360 Rotating Scanner Test Setup... - FCC ID 2A4MW-MWE-PB08

FCC ID 2A4MW-MWE-PB08

Test Setup Photos

360 Rotating Scanner

by Marvel Technology(China)Co.,Ltd

Document preview loads when visible.

Document Details

FCC ID2A4MW-MWE-PB08
Document ID8327927
Document TypeTest Setup Photos
DescriptionTest Setup Photos
ApplicantMarvel Technology(China)Co.,Ltd
Equipment Class360 Rotating Scanner
Product CodeMWEPB08
Application IDFR+ZlCW2yhhsfQEkIaTYew==
Application PurposeOriginal Equipment
Application Date2025-05-26
Frequency Range2402-2480 MHz
FRN0031987969
Test FirmShenzhen Toby Technology Co., Ltd.
Certified ByQing Zhou Manager
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2025-05-26
Available2025-05-26
Created2025-05-09
Modified2025-05-09
Pages2
File TypeAdobe Acrobat PDF
File Size846085
File SHA-2560186d86aaee4fdf86d9999a9210fe7d28ef1596773e1ded1cd6180747e1e1f64
PDF Metadata AuthorTOBY 808
PDF Metadata ProducerMicrosoft® Word 2016 TOBY 808
FCC.gov SourcesFCC.gov 8327927
