MJ6709 Barcode Scanner Test Setup Photos - FCC ID 2A4THMJ-6709
FCC ID 2A4THMJ-6709
Test photos
Barcode Scanner
Document preview loads when visible.
Document Details
| FCC ID | 2A4THMJ-6709 |
|---|---|
| Document ID | 5794662 |
| Document Type | Test Setup Photos |
| Description | Test photos |
| Applicant | Shenzhen Alacrity Barcode Technology Co., Ltd |
| Equipment Class | Barcode Scanner |
| Product Code | MJ6709 |
| Application ID | nCB7bAxGeTqpclMRZ6pRtg== |
| Application Purpose | Original Equipment |
| Application Date | 2022-04-01 |
| Frequency Range | 2402-2480 MHz |
| FRN | 0032003170 |
| Test Firm | Shenzhen United Testing Technology Co., Ltd. |
| Certified By | MR LIU ZE |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | Yes |
| Composite Part | No |
| Submitted | 2022-04-01 |
| Available | 2022-04-01 |
| Created | 2022-03-18 |
| Modified | 2022-03-18 |
| Pages | 2 |
| File Type | Adobe Acrobat PDF |
| File Size | 273693 |
| File SHA-256 | 74005cb30eaabf4875c2885c7906930f2d2be8ea79cc1c07fe30c314dc58994f |
| PDF Metadata Author | Administrator |
| PDF Metadata Producer | Microsoft® Office Word 2007 Microsoft® Office Word 2007 |
| FCC.gov Sources | FCC.gov 5794662, FCC.gov 5794585 |
