EH301 125KHz RFID reader Label Diagram - FCC ID 2A4U3-EH301
FCC ID 2A4U3-EH301
06_EH301 LabelSmpl-US
125KHz RFID reader
Document preview loads when visible.
Document Details
| FCC ID | 2A4U3-EH301 |
|---|---|
| Document ID | 5747250 |
| Document Type | ID Label/Location Info |
| Description | 06_EH301 LabelSmpl-US |
| Applicant | ShenZhen YanShen Electronic Co., Ltd |
| Equipment Class | 125KHz RFID reader |
| Product Code | EH301 |
| Application ID | hkGIxUxFf0qonGNaPjGcpw== |
| Application Purpose | Original Equipment |
| Application Date | 2022-03-12 |
| Frequency Range | 0.125 MHz |
| FRN | 0032004715 |
| Test Firm | Shenzhen CTL Testing Technology Co., Ltd. |
| Certified By | Joerg Kusig Head of Certification |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Submitted | 2022-03-12 |
| Available | 2022-03-12 |
| Created | 2022-03-08 |
| Modified | 2022-03-08 |
| Pages | 1 |
| File Type | Adobe Acrobat PDF |
| File Size | 1589586 |
| File SHA-256 | 4f53ae94f2da12b7eceb0f58b944958bd2c8eb211b968c3f4bf8b80e678e3b76 |
| PDF Metadata Author | wang |
| PDF Metadata Producer | WPS 文字 |
| FCC.gov Sources | FCC.gov 5747250 |
