Y1 LED Remote Control Dimmer Test Setup Photos - FCC ID 2A559Y-1

FCC ID 2A559Y-1

Test setup photos

LED Remote Control Dimmer

by Dongguan Yi Xu Technology Co., LTD

Document preview loads when visible.

Document Details

FCC ID2A559Y-1
Document ID5815877
Document TypeTest Setup Photos
DescriptionTest setup photos
ApplicantDongguan Yi Xu Technology Co., LTD
Equipment ClassLED Remote Control Dimmer
Product CodeY1
Application IDFkNlzhZVydTcw59/u/M09w==
Application PurposeOriginal Equipment
Application Date2022-04-13
Frequency Range433.93 MHz
FRN0032193005
Test FirmShenzhen CTB Testing Technology Co., Ltd.
Certified ByXudong li Manager
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2022-04-13
Available2022-04-13
Created2022-04-11
Modified2022-04-12
Pages2
File TypeAdobe Acrobat PDF
File Size160845
File SHA-25644c386752e3990c8f869b7b58d147f8fa7b3eaee5d4f8d5002564320bf3a7a11
PDF Metadata AuthorAdmin
PDF Metadata ProducerAdmin Adobe PDF Library 15.0
FCC.gov SourcesFCC.gov 5815877
