AM15CWC02 Wireless Charger Test Setup... - FCC ID 2A5O4-AM15CWC02

FCC ID 2A5O4-AM15CWC02

Test setup photos

Wireless Charger

by Shenzhen Shibituo Technology Co., Ltd

Document preview loads when visible.

Document Details

FCC ID2A5O4-AM15CWC02
Document ID5790473
Document TypeTest Setup Photos
DescriptionTest setup photos
ApplicantShenzhen Shibituo Technology Co., Ltd
Equipment ClassWireless Charger
Product CodeAM15CWC02
Application ID/wkZxNpHfnGQbgbyr6xOYA==
Application PurposeOriginal Equipment
Application Date2022-03-30
Frequency Range0.11-0.205 MHz
FRN0032085045
Test FirmShenzhen Tongzhou Testing Co., LTD
Certified ByCyrus WONG Product Development Manager
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2022-03-30
Available2022-03-30
Created2022-03-20
Modified2022-03-20
Pages2
File TypeAdobe Acrobat PDF
File Size311817
File SHA-256ea132541e16295d985163f15707fd9c031913fbbb4bf7fe2cbb7e4f41af7cd1f
PDF Metadata ProducerMicrosoft® Word 2019 Microsoft® Word 2019
FCC.gov SourcesFCC.gov 5790473
