DSX39 Floor Cleaning Robot User Manual - FCC ID 2A64B-DSX39
FCC ID 2A64B-DSX39
User Manual-ed2
Floor Cleaning Robot
Document preview loads when visible.
Document Details
| FCC ID | 2A64B-DSX39 |
|---|---|
| Document ID | 7411464 |
| Document Type | Users Manual |
| Description | User Manual-ed2 |
| Applicant | Ecovacs Home Service Robotics Co., Ltd. |
| Equipment Class | Floor Cleaning Robot |
| Product Code | DSX39 |
| Application ID | 9vAaT2b+Hc6tjtNWc0Qnow== |
| Application Purpose | Original Equipment |
| Application Date | 2024-06-20 |
| Frequency Range | 2402-2480 MHz |
| FRN | 0032456899 |
| Test Firm | Intertek Testing Services Shanghai |
| Certified By | Eric Li Certification Engineer |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Submitted | 2024-06-19 |
| Available | 2024-06-20 |
| Created | 2024-06-14 |
| Modified | 2024-06-17 |
| Pages | 45 |
| File Type | Adobe Acrobat PDF |
| File Size | 5944261 |
| File SHA-256 | 4c687fd71a299d3e3ca59dedcd53eb444352f2289dacb1ff5eece3a81474c78a |
| PDF Metadata Producer | Adobe PDF Library 15.0 Adobe InDesign CC 14.0 (Windows) |
| FCC.gov Sources | FCC.gov 7411464 |
