MG001 Portable radio Test Setup Photos - FCC ID 2A72Z-MG001
FCC ID 2A72Z-MG001
Test Setup Photos
Portable radio
Document preview loads when visible.
Document Details
| FCC ID | 2A72Z-MG001 |
|---|---|
| Document ID | 7932365 |
| Document Type | Test Setup Photos |
| Description | Test Setup Photos |
| Document Title | HD 271 S1 |
| Applicant | Shenzhen Moliao technology co., LTD |
| Equipment Class | Portable radio |
| Product Code | MG001 |
| Application ID | Kgw6133VTarIJFAUkqW7GQ== |
| Application Purpose | Original Equipment |
| Application Date | 2024-12-25 |
| Frequency Range | 2402-2480 MHz |
| FRN | 0032693111 |
| Test Firm | Dongguan Yaxu (AiT) Technology Limited |
| Certified By | Kaizhi Huang Manager |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | Yes |
| Composite Part | No |
| Submitted | 2024-12-25 |
| Available | 2024-12-25 |
| Created | 2024-12-18 |
| Modified | 2024-12-18 |
| Pages | 2 |
| File Type | Adobe Acrobat PDF |
| File Size | 1316787 |
| File SHA-256 | 9d9c9b62da7e0c20ec8f0b9566eefc7d227ff3e929d4f2d6895f23226d9de3e5 |
| PDF Metadata Author | Allo |
| PDF Metadata Producer | WPS 文字 |
| FCC.gov Sources | FCC.gov 7932365, FCC.gov 7932277 |
