DXYBT015 DXY BLE MODULE Test Setup Photos - FCC ID 2A876-DXYBT015
FCC ID 2A876-DXYBT015
Test Setup Photos
DXY BLE MODULE
Document preview loads when visible.
Document Details
| FCC ID | 2A876-DXYBT015 |
|---|---|
| Document ID | 6346639 |
| Document Type | Test Setup Photos |
| Description | Test Setup Photos |
| Document Title | BL-SZ2290649-AR RF test setup photo |
| Applicant | Wuhan P&S; Information Technology Co.,Ltd |
| Equipment Class | DXY BLE MODULE |
| Product Code | DXYBT015 |
| Application ID | Gx02qZgJtJkF37GwIJbAYA== |
| Application Purpose | Original Equipment |
| Application Date | 2023-03-06 |
| Frequency Range | 2402-2480 MHz |
| FRN | 0033051145 |
| Test Firm | Shenzhen BALUN Technology Co., Ltd. |
| Certified By | Xuewen Wu Certification Manager |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Short-Term Confidentiality Date | 07/31/2023 |
| Grant Deferral | No |
| Modular Equipment | Limited Single Modular Approval |
| Composite Device | No |
| Composite Part | No |
| Submitted | 2023-01-31 |
| Available | 2023-07-31 |
| Created | 2022-11-02 |
| Modified | 2022-11-02 |
| Pages | 4 |
| File Type | Adobe Acrobat PDF |
| File Size | 725893 |
| File SHA-256 | 40e528a2d95b191827ae711e7daf5d30fc7b18c6b738520e7c7ae9df0eead4ea |
| PDF Metadata Author | 刘柳 |
| PDF Metadata Producer | Microsoft® Word 2019 刘柳 |
| FCC.gov Sources | FCC.gov 6346639 |
