FCC ID 2AAD3JA1D0J0
Wireless module
by Ability Enterprise Co., Ltd.
Grantee Code: 2AAD3 Product Code: JA1D0J0
Latest application date: 2016-01-19
Device Images
FCC ID Device Details
| FCC ID | 2AAD3JA1D0J0 |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | 2AAD3 |
| Product Code | JA1D0J0 |
| Applicant Business | Ability Enterprise Co., Ltd. 🇹🇼 |
| Related Domains |  abilitycorp.com.tw  quietek.com |
| Equipment Class | Wireless module |
| Test Firm | DEKRA TESTING AND CERTIFICATION CO., LTD. LinKou |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 2402-2480 MHz | Original Equipment | 2016-01-19 |
| 2402-2480 MHz | Original Equipment | 2016-01-19 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| Users Manual | Users Manual | 2016-01-19 | PDF 998.9 KB |
| Internal Photos | Internal Photos | 2016-01-19 | PDF 766 KB |
| External Photos | External Photos | 2016-01-19 | PDF 248.5 KB |
| ID Label | ID Label/Location Info | 2016-01-19 | PDF 25.4 KB |
| Label Location | ID Label/Location Info | 2016-01-19 | PDF 124.8 KB |
| Test Setup Photos | Test Setup Photos | 2016-01-19 | PDF 303.1 KB |
| Test Setup Photos for SAR | Test Setup Photos | 2016-01-19 | PDF 202.6 KB |
| SAR Test Report | RF Exposure Info | 2016-01-19 | PDF 1.9 MB |
| Test Report Metadata only | Test Report | 2016-01-19 | PDF 1.3 MB |
| Test Report for BLE Metadata only | Test Report | 2016-01-19 | PDF 610.7 KB |
| Test Report for BLE_revised0119 | Test Report | 2016-01-19 | PDF 613.3 KB |
| Test Report for WLAN Metadata only | Test Report | 2016-01-19 | PDF 1.3 MB |
| Test Report for WLAN_revised0119 | Test Report | 2016-01-19 | PDF 1.4 MB |
| Test Report_revised0119 | Test Report | 2016-01-19 | PDF 1.9 MB |
| Attestation | Cover Letter(s) | 2016-01-19 | PDF 31.9 KB |
| Channels 12 & 13 Declaration letter (Slave device) | Cover Letter(s) | 2016-01-19 | PDF 31.6 KB |
| Confidentiality | Cover Letter(s) | 2016-01-19 | PDF 48.8 KB |
| DOC | Cover Letter(s) | 2016-01-19 | PDF 34.9 KB |
| Declaration of authorization | Cover Letter(s) | 2016-01-19 | PDF 29.6 KB |
| DoC letter | Cover Letter(s) | 2016-01-19 | PDF 34.9 KB |
| Module Approval letter | Cover Letter(s) | 2016-01-19 | PDF 106.3 KB |
| Module Approval Request | Cover Letter(s) | 2016-01-19 | PDF 106.3 KB |
| confidentiality | Cover Letter(s) | 2016-01-19 | PDF 48.8 KB |
| Block Diagram Metadata only | Block Diagram | PDF 435.1 KB | |
| Schematics Metadata only | Schematics | PDF 895.1 KB | |
| Operational Description Metadata only | Operational Description | PDF 32.7 KB | |
| Operational Description for BLE Metadata only | Operational Description | PDF 14.5 KB | |
| Operational Description for WLAN Metadata only | Operational Description | PDF 14.3 KB |
Application Information
| Application ID | RF4zLNPM2su6+Wz/HSBakw== |
|---|---|
| Final Action Date | 2016-01-19 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0022723480 |
| Model | JA1D0J0 |
| Frequency Range | 2402-2480 MHz |
| Equipment Class | DTS - Digital Transmission System |
| Device Description | Wireless module |
| Responsible Party | Ricky Liao, EMC Assistant Manager, Ricky.Liao@abilitycorp.com.tw , 886285229788 |
| Agent | Vincent Vincent Vincent, QuieTek Corporation, vincent@quietek.com , 886-2-86013788 |
| Technical Contact | Maggie Chen, QuieTek Corporation, maggiechen@quietek.com , 886-2-8601-3788 |
| Non-Technical Contact | Maggie Chen, QuieTek Corporation, maggiechen@quietek.com , 886-2-8601-3788 |
| Test Firm | Mirenda Liao, DEKRA TESTING AND CERTIFICATION CO., LTD. LinKou, mirenda.liao@dekra.com  , +886-2-2602-7968 |
| TCB Email | certification@telefication.com  |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Single Modular Approval |
| Composite Device | Yes |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Modular Approval. Power output listed is conducted. This grant is valid only when the module is sold to OEM integrators and must be installed by the OEM or OEM integrators. The antennas used for this transmitter as shown in this filing must be installed to provide a separation distance of 5 mm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. End-users must be informed of the body requirements to satisfy RF exposure compliance. SAR has been evaluated at 5 mm. The highest reported SAR value for body use conditions & Simultaneous Transmission are 0.40 W/kg (1g), 0.57 W/kg (1g) respectively. This device has 20 MHz bandwidth mode. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| RF4zLNPM2su6+Wz/HSBakw== | 2016-01-19 | Original Equipment |
| 8U3Ls8mcV/tQrybY8eVZLA== | 2016-01-19 | Original Equipment |
Equipment Authorization
Grants
TCB Grant - Application RF4zLNPM2su6+Wz/HSBakw==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Telefication B.V. Wilmersdorf 50 Apeldoorn, NL-7300 AC Netherlands |
Date of Grant: 01/19/2016 Application Dated: 01/19/2016 |
| Ability Enterprise Co., Ltd. |
| No.200, Sec. 3, Zhonghuan Rd., Xinzhuang Dist., |
| New Taipei City, 24242 Taiwan |
| Attention: Ricky Liao , EMC Assistant Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2AAD3JA1D0J0 |
| Name of Grantee: | Ability Enterprise Co., Ltd. |
| Equipment Class: | Digital Transmission System |
| Notes: | Wireless module |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC | 15C | 2412.0 - 2462.0 | 0.157 | ||
| CC | 15C | 2402.0 - 2480.0 | 0.0022 |
| Modular Approval. Power output listed is conducted. This grant is valid only when the module is sold to OEM integrators and must be installed by the OEM or OEM integrators. The antennas used for this transmitter as shown in this filing must be installed to provide a separation distance of 5 mm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. End-users must be informed of the body requirements to satisfy RF exposure compliance. SAR has been evaluated at 5 mm. The highest reported SAR value for body use conditions & Simultaneous Transmission are 0.40 W/kg (1g), 0.57 W/kg (1g) respectively. This device has 20 MHz bandwidth mode. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
EAS Grant - Application RF4zLNPM2su6+Wz/HSBakw==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Ability Enterprise Co., Ltd. No.200, Sec. 3, Zhonghuan Rd., Xinzhuang Dist., New Taipei City, 24242 Taiwan |
Date of Grant: 01/19/2016 Application Dated: 01/19/2016 |
| Attention: Ricky Liao , EMC Assistant Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2AAD3JA1D0J0 |
| Name of Grantee: | Ability Enterprise Co., Ltd. |
| Equipment Class: | Digital Transmission System |
| Notes: | Wireless module |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC | 15C | 2412.0 - 2462.0 | 0.157 | ||
| CC | 15C | 2402.0 - 2480.0 | 0.0022 |
| Modular Approval. Power output listed is conducted. This grant is valid only when the module is sold to OEM integrators and must be installed by the OEM or OEM integrators. The antennas used for this transmitter as shown in this filing must be installed to provide a separation distance of 5 mm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. End-users must be informed of the body requirements to satisfy RF exposure compliance. SAR has been evaluated at 5 mm. The highest reported SAR value for body use conditions & Simultaneous Transmission are 0.40 W/kg (1g), 0.57 W/kg (1g) respectively. This device has 20 MHz bandwidth mode. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| Mail To: | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Telefication B.V. Wilmersdorf 50 Apeldoorn, NL-7300 AC Netherlands |
Date of Grant: 01/19/2016 Application Dated: 01/19/2016 |
| Ability Enterprise Co., Ltd. |
| No.200, Sec. 3, Zhonghuan Rd., Xinzhuang Dist., |
| New Taipei City, 24242 Taiwan |
| Attention: Ricky Liao , EMC Assistant Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2AAD3JA1D0J0 |
| Name of Grantee: | Ability Enterprise Co., Ltd. |
| Equipment Class: | Part 15 Spread Spectrum Transmitter |
| Notes: | Wireless module |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC | 15C | 2402.0 - 2480.0 | 0.0027 |
| Modular Approval. Power output listed is conducted. This grant is valid only when the module is sold to OEM integrators and must be installed by the OEM or OEM integrators. The antennas used for this transmitter as shown in this filing must be installed to provide a separation distance of 5 mm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. End-users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
EAS Grant - Application 8U3Ls8mcV/tQrybY8eVZLA==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Ability Enterprise Co., Ltd. No.200, Sec. 3, Zhonghuan Rd., Xinzhuang Dist., New Taipei City, 24242 Taiwan |
Date of Grant: 01/19/2016 Application Dated: 01/19/2016 |
| Attention: Ricky Liao , EMC Assistant Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2AAD3JA1D0J0 |
| Name of Grantee: | Ability Enterprise Co., Ltd. |
| Equipment Class: | Part 15 Spread Spectrum Transmitter |
| Notes: | Wireless module |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC | 15C | 2402.0 - 2480.0 | 0.0027 |
| Modular Approval. Power output listed is conducted. This grant is valid only when the module is sold to OEM integrators and must be installed by the OEM or OEM integrators. The antennas used for this transmitter as shown in this filing must be installed to provide a separation distance of 5 mm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. End-users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
