KWR17B Remote Control Test Setup Photos - FCC ID 2AADIKWR17B
FCC ID 2AADIKWR17B
Test setup photo
Remote Control
Document preview loads when visible.
Document Details
| FCC ID | 2AADIKWR17B |
|---|---|
| Document ID | 2466182 |
| Document Type | Test Setup Photos |
| Description | Test setup photo |
| Document Title | 1480545R-RFUSP01V00 A1 |
| Applicant | HCS (Suzhou) Limited |
| Equipment Class | Remote Control |
| Product Code | KWR17B |
| Application ID | mZbgwRk22E09EbPZlRAprg== |
| Application Purpose | Original Equipment |
| Application Date | 2014-12-08 |
| Frequency Range | 2425-2475 MHz |
| FRN | 0022717680 |
| Test Firm | DEKRA TESTING AND CERTIFICATION CO., LTD. LinKou |
| Certified By | Gene Chang President |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Submitted | 2014-12-08 |
| Available | 2014-12-08 |
| Created | 2014-10-02 |
| Modified | 2014-10-02 |
| Pages | 2 |
| File Type | Adobe Acrobat PDF |
| File Size | 316179 |
| File SHA-256 | 1699e63e6ab2770eb4c2e3e2c932c705ccb4c0e32decf9e3e69bd603cfbcd6e7 |
| PDF Metadata Author | Jinn-pc_2 |
| PDF Metadata Producer | Acrobat Distiller 9.0.0 (Windows) Jinn-pc_2 |
| FCC.gov Sources | FCC.gov 2466182 |
