TRKM035C GPS Tracker Test Setup Photos - FCC ID 2AAI6-TRKM035-C

FCC ID 2AAI6-TRKM035-C

TestSetupPhotos-PCB

GPS Tracker

by Trackimo INC.

Document preview loads when visible.

Document Details

FCC ID2AAI6-TRKM035-C
Document ID9324865
Document TypeTest Setup Photos
DescriptionTestSetupPhotos-PCB
ApplicantTrackimo INC.
Equipment ClassGPS Tracker
Product CodeTRKM035C
Application IDlm7xCjljd8dQLCR8+nX7jA==
Application PurposeOriginal Equipment
Application Date2026-05-24
Frequency Range1711.5-1753.5 MHz
FRN0022795520
Test FirmSHENZHEN STS TEST SERVICES CO.,LTD.
Certified ByBOVEY YANG
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Modular EquipmentDoes not apply
Composite DeviceYes
Submitted2026-05-24
Available2026-05-24
Created2026-02-25
Modified2026-02-25
Pages2
File TypeAdobe Acrobat PDF
File Size643741
File SHA-2568bdf9d0f29ea199ff389d5d8aa4fcbbb04b16f37cb05ff35214715508f641d66
PDF Metadata Authoradmin
PDF Metadata ProducerMicrosoft® Word 2013 Microsoft® Word 2013
FCC.gov SourcesFCC.gov 9324865
