VCM7601V01 WLAN USB module Label Diagram - FCC ID 2AAIXVCM7601V01
FCC ID 2AAIXVCM7601V01
Host Label Sample and Label Location
WLAN USB module
Document preview loads when visible.
Document Details
| FCC ID | 2AAIXVCM7601V01 |
|---|---|
| Document ID | 3941742 |
| Document Type | ID Label/Location Info |
| Description | Host Label Sample and Label Location |
| Document Title | JM7130S20PL_IC Label Sample and Label Location |
| Applicant | Axia Innovations LTD. |
| Equipment Class | WLAN USB module |
| Product Code | VCM7601V01 |
| Application ID | 6geHdZGKqRBKNwACbF0COQ== |
| Application Purpose | Original Equipment |
| Application Date | 2018-07-27 |
| Frequency Range | 2412-2462 MHz |
| FRN | 0022790760 |
| Test Firm | WALTEK TESTING GROUP CO., LTD. |
| Certified By | Philo zhong General Manager |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Grant Deferral | No |
| Modular Equipment | Limited Single Modular Approval |
| Composite Device | No |
| Composite Part | No |
| Submitted | 2018-07-27 |
| Available | 2018-07-27 |
| Created | 2018-07-23 |
| Modified | 2018-07-23 |
| Pages | 1 |
| File Type | Adobe Acrobat PDF |
| File Size | 124068 |
| File SHA-256 | 6c492ca87fdb080318eb4cf48bd2dc07c9df1824d5617df0bf6ba0170484f1e1 |
| PDF Metadata Author | Administrator |
| PDF Metadata Producer | Administrator Acrobat Distiller 11.0 (Windows) |
| FCC.gov Sources | FCC.gov 3941742 |
