BR20 BCM Body Computer Modul Teardown... - FCC ID 2AAJCBR20
FCC ID 2AAJCBR20
Internal Photos
BCM Body Computer Modul
Document preview loads when visible.
Document Details
| FCC ID | 2AAJCBR20 |
|---|---|
| Document ID | 4195460 |
| Document Type | Internal Photos |
| Description | Internal Photos |
| Document Title | 1-5475/17-01-01_AnnexB |
| Applicant | Robert Bosch GmbH |
| Equipment Class | BCM Body Computer Modul |
| Product Code | BR20 |
| Application ID | ntic0QXuefvy/4i2NqgHiA== |
| Application Purpose | Original Equipment |
| Application Date | 2019-03-08 |
| Frequency Range | 433.46-434.36 MHz |
| FRN | 0022798011 |
| Test Firm | CTC advanced GmbH |
| Certified By | Dr Slava Tihovsky |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Short-Term Confidentiality Date | 06/05/2019 |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Submitted | 2019-03-08 |
| Available | 2019-06-05 |
| Created | 2018-08-09 |
| Modified | 2018-11-22 |
| Pages | 4 |
| File Type | Adobe Acrobat PDF |
| File Size | 616486 |
| File SHA-256 | 3289d72a3cf3f9528ccdc186699cf557084a0b32d0346c8fc5300db9b2beafdd |
| PDF Metadata Author | Christoph Schneider |
| PDF Metadata Producer | Christoph Schneider pdfmake |
| FCC.gov Sources | FCC.gov 4195460 |
