FCC ID 2AATL-F89FTSM13
Wifi Module
by HUNAN FN-LINK TECHNOLOGY LIMITED
Grantee Code: 2AATL Product Code: F89FTSM13
Latest application date: 2016-06-07
Device Images
FCC ID Device Details
| FCC ID | 2AATL-F89FTSM13 |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | 2AATL |
| Product Code | F89FTSM13 |
| Applicant Business | HUNAN FN-LINK TECHNOLOGY LIMITED 🇨🇳 |
| Related Domains |  fn-link.com |
| Equipment Class | Wifi Module |
| Test Firm | Dongguan NTC Co.,Ltd., |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 2412-2465 MHz | Original Equipment | 2016-06-07 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| 15_F89FTSM13 UserMan, r2.pdf | Users Manual | 2016-06-07 | PDF 2.1 MB |
| 09_F89FTSM13 IntPho.pdf | Internal Photos | 2016-06-07 | PDF 341.2 KB |
| 08_F89FTSM13 ExtPho.pdf | External Photos | 2016-06-07 | PDF 341.2 KB |
| 06-07_F89FTSM13 LabelSmpl-Loc.pdf | ID Label/Location Info | 2016-06-07 | PDF 145.1 KB |
| 17_F89FTSM13 AntSpec, r1.pdf | Operational Description | 2016-06-07 | PDF 19.2 KB |
| 10_F89FTSM13 TSup.pdf | Test Setup Photos | 2016-06-07 | PDF 441.5 KB |
| 14_F89FTSM13 TestRpt, r1.pdf | Test Report | 2016-06-07 | PDF 2.2 MB |
| 18_F89FTSM13 RFExp.pdf | RF Exposure Info | 2016-06-07 | PDF 34.7 KB |
| 12_F89FTSM13 BlkDia.pdf Metadata only | Block Diagram | PDF 183.3 KB | |
| 13_F89FTSM13 Schem.pdf Metadata only | Schematics | PDF 63.6 KB | |
| 11_F89FTSM13 OpDes.pdf Metadata only | Operational Description | PDF 120.9 KB | |
| 16_F89FTSM13 PartsLst.pdf Metadata only | Parts List/Tune Up Info | PDF 28.3 KB |
Application Information
| Application ID | JrH0e2mSKY1IxzZGx5p3bg== |
|---|---|
| Final Action Date | 2016-06-07 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0022902761 |
| Model | F89FTSM13 |
| Frequency Range | 2412-2465 MHz |
| Equipment Class | DTS - Digital Transmission System |
| Device Description | Wifi Module |
| Responsible Party | Jim Hu, Manager, jim@fn-link.com , +8613538178944 |
| Test Firm | sunm lv sunm lv, Dongguan NTC Co.,Ltd.,, sunmlv@21cn.com  , 86-769-22022444 |
| TCB Email | joergkusig@eurofins.com  |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Limited Single Modular Approval |
| Composite Device | No |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Output power listed is Conducted. Compliance of this device in all final host configurations is the responsibility of the Grantee. OEM integrators and end-users must be provided with specific operating instructions for satisfying RF exposure compliance. OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. Installation is limited to the host system evaluated in this filing. Additional host systems will require reassessment of radiated spurious emissions due to the lack of shielding on the module. SAR evaluation is valid for mobile applications only applications (distance minimum 20cm to human bodies). |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| JrH0e2mSKY1IxzZGx5p3bg== | 2016-06-07 | Original Equipment |
Equipment Authorization
| Frequency | Output | Rules |
|---|---|---|
| 2412-2465 MHz | 0.0365000 | 15C |
Grants
TCB Grant - Application JrH0e2mSKY1IxzZGx5p3bg==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Eurofins Product Service GmbH Storkower Strasse 38c D-15526 Reichenwalde, Germany |
Date of Grant: 06/07/2016 Application Dated: 06/07/2016 |
| HUNAN FN-LINK TECHNOLOGY LIMITED |
| No.8, Litong Road, Liuyang Economic & |
| Technical Development Zone, |
| Changsha, Hunan, China |
| Attention: Jim Hu , Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2AATL-F89FTSM13 |
| Name of Grantee: | HUNAN FN-LINK TECHNOLOGY LIMITED |
| Equipment Class: | Digital Transmission System |
| Notes: | Wifi Module |
| Modular Type: | Limited Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2412.0 - 2465.0 | 0.0365 |
| Output power listed is Conducted. Compliance of this device in all final host configurations is the responsibility of the Grantee. OEM integrators and end-users must be provided with specific operating instructions for satisfying RF exposure compliance. OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. Installation is limited to the host system evaluated in this filing. Additional host systems will require reassessment of radiated spurious emissions due to the lack of shielding on the module. SAR evaluation is valid for mobile applications only applications (distance minimum 20cm to human bodies). |
EAS Grant - Application JrH0e2mSKY1IxzZGx5p3bg==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
HUNAN FN-LINK TECHNOLOGY LIMITED No.8, Litong Road, Liuyang Economic & Technical Development Zone, Changsha, Hunan, China |
Date of Grant: 06/07/2016 Application Dated: 06/07/2016 |
| Attention: Jim Hu , Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2AATL-F89FTSM13 |
| Name of Grantee: | HUNAN FN-LINK TECHNOLOGY LIMITED |
| Equipment Class: | Digital Transmission System |
| Notes: | Wifi Module |
| Modular Type: | Limited Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2412.0 - 2465.0 | 0.0365 |
| Output power listed is Conducted. Compliance of this device in all final host configurations is the responsibility of the Grantee. OEM integrators and end-users must be provided with specific operating instructions for satisfying RF exposure compliance. OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. Installation is limited to the host system evaluated in this filing. Additional host systems will require reassessment of radiated spurious emissions due to the lack of shielding on the module. SAR evaluation is valid for mobile applications only applications (distance minimum 20cm to human bodies). |
