6188SUF 802.11b/g/n module Test Setup Photos - FCC ID 2AATL-6188SUF
FCC ID 2AATL-6188SUF
Test set-up_Radiated
802.11b/g/n module
Document preview loads when visible.
Document Details
| FCC ID | 2AATL-6188SUF |
|---|---|
| Document ID | 3637922 |
| Document Type | Test Setup Photos |
| Description | Test set-up_Radiated |
| Document Title | Radiated emission test set-up photo |
| Applicant | HUNAN FN-LINK TECHNOLOGY LIMITED |
| Equipment Class | 802.11b/g/n module |
| Product Code | 6188SUF |
| Application ID | xbn63RzdWCdw4oqH5LaQUA== |
| Application Purpose | Original Equipment |
| Application Date | 2017-11-14 |
| Frequency Range | 2412-2462 MHz |
| FRN | 0022902761 |
| Test Firm | Intertek Testing Services Taiwan Ltd |
| Certified By | Wakeyou Wang |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Grant Deferral | No |
| Modular Equipment | Single Modular Approval |
| Composite Device | No |
| Composite Part | No |
| Submitted | 2017-11-13 |
| Available | 2017-11-14 |
| Created | 2017-10-27 |
| Modified | 2017-10-27 |
| Pages | 3 |
| File Type | Adobe Acrobat PDF |
| File Size | 388591 |
| File SHA-256 | db9d487167165c48c2c3f6469eaa9abc08dbc9d3c6c711c9eb0d4e67443b1504 |
| PDF Metadata Author | sunny.pq.l |
| PDF Metadata Producer | Acrobat Distiller 7.0.5 (Windows) sunny.pq.l |
| FCC.gov Sources | FCC.gov 3637922 |
