H132AS WIFI module Test Setup Photos - FCC ID 2AATL-H132AS

FCC ID 2AATL-H132AS

Test setup

WIFI module

by FN-LINK TECHNOLOGY LIMITED

Document preview loads when visible.

Document Details

FCC ID2AATL-H132AS
Document ID5947553
Document TypeTest Setup Photos
DescriptionTest setup
ApplicantFN-LINK TECHNOLOGY LIMITED
Equipment ClassWIFI module
Product CodeH132AS
Application IDX9eT369Caq4Q/FWddRBLxA==
Application PurposeOriginal Equipment
Application Date2022-06-20
Frequency Range2412-2462 MHz
FRN0022902761
Test FirmBlueAsia of Technical Services (Shenzhen)
Certified ByJim Hu Manager
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentSingle Modular Approval
Composite DeviceNo
Composite PartNo
Submitted2022-06-20
Available2022-06-20
Created2022-06-08
Modified2022-06-08
Pages3
File TypeAdobe Acrobat PDF
File Size982402
File SHA-2565c7d263aa9706f3f0a2299fc3aa214971f232bbfeb194788e2eb560a723aeaff
PDF Metadata Authorr f
PDF Metadata ProducerWPS 文字
FCC.gov SourcesFCC.gov 5947553
