R9008 WIRELESS RECEIVER RF Exposure Info EMC EMISSION - TEST REPORT Shenzhen Loyal Electronics Co., Ltd.

Shenzhen Loyal Electronics Co., Ltd. WIRELESS RECEIVER

Page 1 of R9008 WIRELESS RECEIVER RF Exposure Info EMC EMISSION - TEST REPORT Shenzhen Loyal Electronics Co., Ltd.

Report Number: 68.950.18.0319.01A
RF exposure Estimation
Introduction
G5300E-2 (FCC ID: 2AAVD-R9008) is a WIRELESS RECEIVER, which contain 2.4G Radio
function inside.
1.
Limit and Guidelines on Exposure to Electromagnetic Fields
According to§15.247(e)(i) and §1.1307(b)(1), systems operating under the provisions of this
section shall be operated in a manner that ensure that the public is not exposed to radio
frequency energy level in excess of the Commission’s guideline.
According to KDB 447498 Mobile Portable RF Exposure, no SAR required if power is lower
than the flowing threshold:
The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation
distances ≤ 50 mm are determined by:
[(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)]
[√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where
• f(GHz) is the RF channel transmit frequency in GHz
• Power and distance are rounded to the nearest mW and mm before calculation25
• The result is rounded to one decimal place for comparison
• 3.0 and 7.5 are referred to as the numeric thresholds in the step 2 below
The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm
and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test
separation distance is < 5 mm, a distance of 5 mm according to 5) in section 4.1 is applied to
determine SAR test exclusion.
2.
Calculation method
[(max. power of` channel, including tune-up tolerance, mW)/(min. test separation distance,
mm)] ·[√f(GHz)] ≤ 3.0
Conducted Power + tune up tolerance = -2.95dBm+4dB=1.05dBm=1.274mW
Distance = 5 mm
f = 2.408 GHz
[1.274/5] * SQRT(2.408) =0.395
0.395≤ 3.0
Therefore, excluded from SAR testing.
TUV SUD China, Shenzhen Branch
Reviewed by:
Prepared By:
Phoebe Hu/ EMC Section Manager
Date: 2018-9-07
Vincent Zheng/EMC Project Engineer
Date: 2018-9-07
TÜV SÜD Certification and Testing (China) Co., Ltd. Shenzhen Branch
Building 12&13, Zhiheng Wisdomland Business Park, Nantou Checkpoint Road 2, Nanshan District, Shenzhen City, 518052, P. R. China Tel. +86 755 8828 6998, Fax: +86 755
8828 5299
