FCC ID 2AAVWADTSTOUCH-02
ADTS TOUCH-ER
by Druck Ltd
Grantee Code: 2AAVW Product Code: ADTSTOUCH02
Latest application date: 2016-06-20
Device Images
FCC ID Device Details
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 2400-2483.5 MHz | Original Equipment | 2016-06-20 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| USERS MANUAL | Users Manual | 2016-06-20 | PDF 4.1 MB |
| INTERNAL PHOTOS | Internal Photos | 2016-06-20 | PDF 1.1 MB |
| WT41-A_Internal_Pictures | Internal Photos | 2016-06-20 | PDF 80 KB |
| EXTERNAL PHOTOS | External Photos | 2016-06-20 | PDF 611.2 KB |
| WT41-A_External_Pictures | External Photos | 2016-06-20 | PDF 103.3 KB |
| ID LABEL | ID Label/Location Info | 2016-06-20 | PDF 329.7 KB |
| LABEL LOCATION INFO | ID Label/Location Info | 2016-06-20 | PDF 133.7 KB |
| TEST SETUP PHOTOS | Test Setup Photos | 2016-06-20 | PDF 308 KB |
| TEST REPORT 9F2925WUS2B | Test Report | 2016-06-20 | PDF 4.7 MB |
| TEST REPORT 9F2925WUS2a | Test Report | 2016-06-20 | PDF 2.6 MB |
| Test Report | Test Report | 2016-06-20 | PDF 1.6 MB |
| LETTER OF AGENCY | Attestation Statements | 2016-06-20 | PDF 42.9 KB |
| LETTER OF CONFIDENTIALITY | Cover Letter(s) | 2016-06-20 | PDF 46.6 KB |
| LETTER OF CONFIDENTIALITY MODULE | Cover Letter(s) | 2016-06-20 | PDF 25.7 KB |
| SAR REPORT P1 | RF Exposure Info | 2016-06-20 | PDF 4.1 MB |
| SAR REPORT P2 | RF Exposure Info | 2016-06-20 | PDF 3.5 MB |
| BLOCK DIAGRAM Metadata only | Block Diagram | PDF 104.6 KB | |
| BLOCK DIAGRAM module Metadata only | Block Diagram | PDF 131.7 KB | |
| SCHEMATICS Metadata only | Schematics | PDF 509.8 KB | |
| WT41-A_schematic Metadata only | Schematics | PDF 236.6 KB | |
| OPERATIONAL DESCRIPTION Metadata only | Operational Description | PDF 1.4 MB | |
| OPERATIONAL DESCRIPTION SOFTWARE - REDUCED POWER Metadata only | Operational Description | PDF 97 KB | |
| OPERATIONAL DESCRIPTION WT41 Metadata only | Operational Description | PDF 258.2 KB | |
| ADTS_TOUCH-ER_PARTS_LIST_IA4532-2-V0 Metadata only | Parts List/Tune Up Info | PDF 92.8 KB | |
| PARTS LIST Metadata only | Parts List/Tune Up Info | PDF 30.9 KB | |
| WT41A_BOM Metadata only | Parts List/Tune Up Info | PDF 26.2 KB |
Application Information
| Application ID | bI0uYon32LOhCL9e8xaLBg== |
|---|---|
| Final Action Date | 2016-06-20 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0022928626 |
| Model | ADTSTOUCH-02 |
| Frequency Range | 2400-2483.5 MHz |
| Equipment Class | DSS - Part 15 Spread Spectrum Transmitter |
| Device Description | ADTS TOUCH-ER |
| Responsible Party | Matthew T Concannon, Mr, matthew.concannon@ge.com  , +44 116 231 7444 |
| Test Firm | Stewart Barrowclough, Element Materials Technology Warwick Ltd, stewart.barrowclough@element.com  , 01695556666 |
| TCB Email | roy.ediss@element.com |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | The RF Output Power in this product has been reduced to 0.008W. This device must not be used with an antenna that is not approved to operate in conjunction with this device. This equipment has been tested for compliance with SAR limits for body worn configurations, the highest reported SAR value is 0.163 [W/kg] |
