FCC ID 2AB3N-CPSW603
ACTIVE SUBWOOFER SYSTEM
by S&O; ELECTRONICS (MALAYSIA) SDN. BHD.
Grantee Code: 2AB3N Product Code: CPSW603
Latest application date: 2016-02-17
Device Images
FCC ID Device Details
| FCC ID | 2AB3N-CPSW603 |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | 2AB3N |
| Product Code | CPSW603 |
| Applicant Business | S&O; ELECTRONICS (MALAYSIA) SDN. BHD. 🇲🇾 |
| Related Domains |  soem.sharpworld.com  intertek.com |
| Equipment Class | ACTIVE SUBWOOFER SYSTEM |
| Test Firm | Intertek Testing Services Shenzhen Ltd. |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 2402-2480 MHz | Original Equipment | 2016-02-17 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| User Manual | Users Manual | 2016-02-17 | PDF 1.5 MB |
| Internal Photos | Internal Photos | 2016-02-17 | PDF 754 KB |
| External Photos | External Photos | 2016-02-17 | PDF 837 KB |
| Label Artwork and Location | ID Label/Location Info | 2016-02-17 | PDF 597 KB |
| Conducted Emission | Test Setup Photos | 2016-02-17 | PDF 919.4 KB |
| Radiated Emission | Test Setup Photos | 2016-02-17 | PDF 248.1 KB |
| Bandedge | Test Report | 2016-02-17 | PDF 45 KB |
| Bandwith Plot | Test Report | 2016-02-17 | PDF 50.5 KB |
| Test Report | Test Report | 2016-02-17 | PDF 374.5 KB |
| Confidentiality Request | Cover Letter(s) | 2016-02-17 | PDF 310.3 KB |
| Letter of Agency | Cover Letter(s) | 2016-02-17 | PDF 210.6 KB |
| Analysis Report | RF Exposure Info | 2016-02-17 | PDF 68.7 KB |
| Block Diagram Metadata only | Block Diagram | PDF 385 KB | |
| Circuit Diagram Metadata only | Schematics | PDF 3 MB | |
| Technical Description Metadata only | Operational Description | PDF 58.1 KB |
Application Information
| Application ID | BjLFLCHgs66bNb1csRQ3Jw== |
|---|---|
| Final Action Date | 2016-02-17 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0023459449 |
| Model | CPSW603 |
| Frequency Range | 2402-2480 MHz |
| Equipment Class | DXX - Part 15 Low Power Communication Device Transmitter |
| Device Description | ACTIVE SUBWOOFER SYSTEM |
| Responsible Party | TEH CHANG PING, SENIOR MANAGER, tehcp@soem.sharpworld.com , 604-4552319 |
| Agent | Stella Stella Stella, Intertek Testing Services Shenzhen Ltd. Kejiyuan B |
| Technical Contact | Stella Yang, Intertek Testing Services Shenzhen Ltd. Kejiyuan B, stella.xh.yang@intertek.com , (86-755) 8614 0712 |
| Non-Technical Contact | Stella Yang, Intertek Testing Services Shenzhen Ltd. Kejiyuan B, stella.xh.yang@intertek.com , (86-755) 8614 0712 |
| Test Firm | Shawn Xing, Intertek Testing Services Shenzhen Ltd., Shawn.xing@intertek.com , 86-75586140603 |
| TCB Email | TCB_Admin@intertek.com |
| TCB Scope | A2: Low Power Transmitters (except Spread Spectrum) and radar detectors operating above 1 GHz |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | Yes |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | This device must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter, except in accordance with FCC multi-transmitter product procedures. End-users must be informed of the operating requirements for satisfying RF exposure compliance. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| BjLFLCHgs66bNb1csRQ3Jw== | 2016-02-17 | Original Equipment |
Equipment Authorization
| Frequency | Rules |
|---|---|
| 2402-2480 MHz | 15C |
Grants
TCB Grant - Application BjLFLCHgs66bNb1csRQ3Jw==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Intertek Testing Services NA, Inc. 70 Codman Hill Road Boxborough, MA 01719 |
Date of Grant: 02/17/2016 Application Dated: 02/17/2016 |
| S&O ELECTRONICS (MALAYSIA) SDN. BHD. |
| LOT 202, BAKAR ARANG INDUSTRIAL ESTATE, |
| 08000 SUNGAI PETANI, |
| KEDAH, Malaysia |
| Attention: TEH CHANG PING , SENIOR MANAGER |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2AB3N-CPSW603 |
| Name of Grantee: | S&O ELECTRONICS (MALAYSIA) SDN. BHD. |
| Equipment Class: | Part 15 Low Power Communication Device Transmitter |
| Notes: | ACTIVE SUBWOOFER SYSTEM |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2402.0 - 2480.0 |
| This device must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter, except in accordance with FCC multi-transmitter product procedures. End-users must be informed of the operating requirements for satisfying RF exposure compliance. |
EAS Grant - Application BjLFLCHgs66bNb1csRQ3Jw==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
S&O ELECTRONICS (MALAYSIA) SDN. BHD. LOT 202, BAKAR ARANG INDUSTRIAL ESTATE, 08000 SUNGAI PETANI, KEDAH, Malaysia |
Date of Grant: 02/17/2016 Application Dated: 02/17/2016 |
| Attention: TEH CHANG PING , SENIOR MANAGER |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2AB3N-CPSW603 |
| Name of Grantee: | S&O ELECTRONICS (MALAYSIA) SDN. BHD. |
| Equipment Class: | Part 15 Low Power Communication Device Transmitter |
| Notes: | ACTIVE SUBWOOFER SYSTEM |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2402.0 - 2480.0 |
| This device must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter, except in accordance with FCC multi-transmitter product procedures. End-users must be informed of the operating requirements for satisfying RF exposure compliance. |
