FCC ID 2AB5K-SD5001
SD5001
by LUMI LEGEND ELECTRICAL CO.,LTD
Grantee Code: 2AB5K Product Code: SD5001
Latest application date: 2015-12-31
Device Images
FCC ID Device Details
| FCC ID | 2AB5K-SD5001 |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | 2AB5K |
| Product Code | SD5001 |
| Applicant Business | LUMI LEGEND ELECTRICAL CO.,LTD 🇨🇳 |
| Related Domains |  lumitek.cn |
| Equipment Class | SD5001 |
| Test Firm | Intertek Testing Services Limited Shanghai |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 433.92 MHz | Original Equipment | 2015-12-31 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| user manual | Users Manual | 2015-12-31 | PDF 102.5 KB |
| Internal picture | Internal Photos | 2015-12-31 | PDF 297.2 KB |
| External picture | External Photos | 2015-12-31 | PDF 332 KB |
| Label | ID Label/Location Info | 2015-12-31 | PDF 314.3 KB |
| test Setup | Test Setup Photos | 2015-12-31 | PDF 240.6 KB |
| FCC Part 15.231 | Test Report | 2015-12-31 | PDF 97.9 KB |
| test data_REV1 | Test Report | 2015-12-31 | PDF 130.2 KB |
| FCC Agent | Cover Letter(s) | 2015-12-31 | PDF 130.5 KB |
| FCC confidentiality | Cover Letter(s) | 2015-12-31 | PDF 1.1 MB |
| Bolck diagrm_Rev1 Metadata only | Block Diagram | PDF 24.6 KB | |
| Confidential_circuit schematic Metadata only | Schematics | PDF 21.7 KB | |
| Description operation_REV2 Metadata only | Operational Description | PDF 29.4 KB |
Application Information
| Application ID | 6wtlVbHfIBXrBrHNfVvNHw== |
|---|---|
| Final Action Date | 2015-12-31 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0023351141 |
| Model | SD5001 |
| Frequency Range | 433.92 MHz |
| Equipment Class | DSC - Part 15 Security/Remote Control Transmitter |
| Device Description | SD5001 |
| Responsible Party | limin zhang, certification, qc@lumitek.cn , +8657488165637 |
| Agent | Jesse Jesse Jesse, Intertek Testing Services Limited Shanghai, jesse.xu@intertek.com  , 86-21-61215147 |
| Technical Contact | Jesse Xu, Intertek Testing Services Limited Shanghai, jesse.xu@intertek.com , 86-21-61215147 |
| Test Firm | Jonny Jing, Intertek Testing Services Limited Shanghai, jonny.jing@intertek.com , 86-21-61278271 |
| TCB Email | hotline@acbcert.com  |
| TCB Scope | A1: Low Power Transmitters below 1 GHz (except Spread Spectrum), Unintentional Radiators, EAS (Part 11) & Consumer ISM devices |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| 6wtlVbHfIBXrBrHNfVvNHw== | 2015-12-31 | Original Equipment |
Equipment Authorization
| Frequency | Rules |
|---|---|
| 433.92 MHz | 15.231 |
Grants
TCB Grant - Application 6wtlVbHfIBXrBrHNfVvNHw==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
ACB, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 |
Date of Grant: 12/31/2015 Application Dated: 12/31/2015 |
| LUMI LEGEND ELECTRICAL CO.,LTD |
| no.18 lane 239 |
| ningbo, 315032 China |
| Attention: limin zhang , certification |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2AB5K-SD5001 |
| Name of Grantee: | LUMI LEGEND ELECTRICAL CO.,LTD |
| Equipment Class: | Part 15 Security/Remote Control Transmitter |
| Notes: | SD5001 |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15.231 | 433.92 - 433.92 |
EAS Grant - Application 6wtlVbHfIBXrBrHNfVvNHw==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
LUMI LEGEND ELECTRICAL CO.,LTD no.18 lane 239 ningbo, 315032 China |
Date of Grant: 12/31/2015 Application Dated: 12/31/2015 |
| Attention: limin zhang , certification |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2AB5K-SD5001 |
| Name of Grantee: | LUMI LEGEND ELECTRICAL CO.,LTD |
| Equipment Class: | Part 15 Security/Remote Control Transmitter |
| Notes: | SD5001 |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15.231 | 433.92 - 433.92 |
| Mail To: |
