KY03 TWS BLUETOOTH ADPHONE Teardown Internal... - FCC ID 2AB5T-KY03

FCC ID 2AB5T-KY03

Internal photos

TWS BLUETOOTH ADPHONE

by Shenzhen MeiDong Acoustics Co., LTD

Document preview loads when visible.

Document Details

FCC ID2AB5T-KY03
Document ID4590624
Document TypeInternal Photos
DescriptionInternal photos
Document TitleKY03_internal Photox
ApplicantShenzhen MeiDong Acoustics Co., LTD
Equipment ClassTWS BLUETOOTH ADPHONE
Product CodeKY03
Application ID8j0jeclmMC07l94tA/JPuQ==
Application PurposeOriginal Equipment
Application Date2020-01-15
Frequency Range2402-2480 MHz
FRN0026846626
Test FirmSHENZHEN STS TEST SERVICES CO.,LTD.
Certified ByHuang hua Manager
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2020-01-15
Available2020-01-15
Created2020-01-07
Modified2020-01-07
Pages4
File TypeAdobe Acrobat PDF
File Size2346164
File SHA-256e52ab4962f25a7cd29975efac23963bdfb080e06dfb0cd556b8c373c2d81aebc
PDF Metadata AuthorAdministrator
PDF Metadata ProducerAcrobat Distiller 9.0.0 (Windows) Administrator
FCC.gov SourcesFCC.gov 4590624
