FCC ID 2AB6Z-DT173-AS4-SL
17.3 inches Quad Core Media Player Slim Housing
by HUNG WAI HOLDINGS LIMITED
Grantee Code: 2AB6Z Product Code: DT173AS4SL
Latest application date: 2016-07-24
Device Images
FCC ID Device Details
| FCC ID | 2AB6Z-DT173-AS4-SL |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | 2AB6Z |
| Product Code | DT173AS4SL |
| Applicant Business | HUNG WAI HOLDINGS LIMITED 🇨🇳 |
| Related Domains |  hungwai.com |
| Equipment Class | 17.3 inches Quad Core Media Player Slim Housing |
| Test Firm | Shenzhen Zhongjian Nanfang Testing Co.,Ltd |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 2402-2480 MHz | Original Equipment | 2016-07-24 |
| 5180-5240 MHz | Original Equipment | 2016-07-24 |
| 2402-2480 MHz | Original Equipment | 2016-07-24 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| User manual | Users Manual | 2016-07-24 | PDF 134.3 KB |
| Internal photos | Internal Photos | 2016-07-24 | PDF 1.5 MB |
| External photos | External Photos | 2016-07-24 | PDF 594.3 KB |
| Label | ID Label/Location Info | 2016-07-24 | PDF 122 KB |
| Test setup | Test Setup Photos | 2016-07-24 | PDF 292.8 KB |
| Modular test report | Test Report | 2016-07-24 | PDF 2.5 MB |
| Modular test report | Test Report | 2016-07-24 | PDF 2.7 MB |
| Modular test report | Test Report | 2016-07-24 | PDF 3.9 MB |
| Test report | Test Report | 2016-07-24 | PDF 2.7 MB |
| Test report | Test Report | 2016-07-24 | PDF 1.5 MB |
| Test report | Test Report | 2016-07-24 | PDF 3.4 MB |
| Cover letter | Cover Letter(s) | 2016-07-24 | PDF 453.4 KB |
| RF Exposure | RF Exposure Info | 2016-07-24 | PDF 1.1 MB |
| Block Diagram Metadata only | Block Diagram | PDF 95.1 KB | |
| Schematics Metadata only | Schematics | PDF 363.6 KB | |
| Operational Description Metadata only | Operational Description | PDF 2 MB | |
| Software Security Metadata only | SDR Software/Security Inf | PDF 124.2 KB |
Application Information
| Application ID | k/9aTV/1AxzNYaxeE1xsEA== |
|---|---|
| Final Action Date | 2016-07-24 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0023508104 |
| Model | DT173-AS4-SL |
| Frequency Range | 2402-2480 MHz |
| Equipment Class | DSS - Part 15 Spread Spectrum Transmitter |
| Device Description | 17.3 inches Quad Core Media Player Slim Housing |
| Responsible Party | Qinhong Liao, Andy@hungwai.com , (852)90907758 |
| Test Firm | Bruce Zhang, Shenzhen Zhongjian Nanfang Testing Co.,Ltd, bruce.zhang@ccis-cb.com  , 86-755-23118282 |
| TCB Email | stuart.beck@nemko.com  |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | Yes |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | Yes |
| Grant Comments | Power output listed is conducted. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be collocated or operating in conjunction with any other transmitter. End-users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| k/9aTV/1AxzNYaxeE1xsEA== | 2016-07-24 | Original Equipment |
| SCMn6AoEiUnraw4z/3uvbA== | 2016-07-24 | Original Equipment |
| B14PSEXYsBbJzWVtse9nKQ== | 2016-07-24 | Original Equipment |
Equipment Authorization
Grants
TCB Grant - Application SCMn6AoEiUnraw4z/3uvbA==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Nemko North America, INC. 303 River Road Ottawa, Ontario, K1V 1H2 Canada |
Date of Grant: 07/24/2016 Application Dated: 07/22/2016 |
| HUNG WAI HOLDINGS LIMITED |
| Unit 11, 12/F., New Commerce Centre, |
| 19 On Sum Street, Shatin, Hong Kong |
| Hong Kong, China |
| Attention: Qinhong Liao |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2AB6Z-DT173-AS4-SL |
| Name of Grantee: | HUNG WAI HOLDINGS LIMITED |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | 17.3 inches Quad Core Media Player Slim Housing |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 38 CC | 15E | 5180.0 - 5240.0 | 0.0235 | ||
| 38 CC | 15E | 5745.0 - 5825.0 | 0.0251 |
| Power output listed is conducted. This device has a 20 MHz, 40 MHz and 80 MHz bandwidth mode. Operation in 5.15-5.25 GHz band is restricted for indoor use only. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other transmitter. End-users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. |
| 38: | This device has shown compliance, in all grant-listed U-NII sub-bands, with the new rules for U-NII devices adopted under Docket No. 13-49 and may be marketed, manufactured or imported after the June 1, 2016 transition deadline. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
EAS Grant - Application SCMn6AoEiUnraw4z/3uvbA==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
HUNG WAI HOLDINGS LIMITED Unit 11, 12/F., New Commerce Centre, 19 On Sum Street, Shatin, Hong Kong Hong Kong, China |
Date of Grant: 07/24/2016 Application Dated: 07/22/2016 |
| Attention: Qinhong Liao |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2AB6Z-DT173-AS4-SL |
| Name of Grantee: | HUNG WAI HOLDINGS LIMITED |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | 17.3 inches Quad Core Media Player Slim Housing |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 38 CC | 15E | 5180.0 - 5240.0 | 0.0235 | ||
| 38 CC | 15E | 5745.0 - 5825.0 | 0.0251 |
| Power output listed is conducted. This device has a 20 MHz, 40 MHz and 80 MHz bandwidth mode. Operation in 5.15-5.25 GHz band is restricted for indoor use only. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other transmitter. End-users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. |
| 38: | This device has shown compliance, in all grant-listed U-NII sub-bands, with the new rules for U-NII devices adopted under Docket No. 13-49 and may be marketed, manufactured or imported after the June 1, 2016 transition deadline. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| Mail To: | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Nemko North America, INC. 303 River Road Ottawa, Ontario, K1V 1H2 Canada |
Date of Grant: 07/24/2016 Application Dated: 07/24/2016 |
| HUNG WAI HOLDINGS LIMITED |
| Unit 11, 12/F., New Commerce Centre, |
| 19 On Sum Street, Shatin, Hong Kong |
| Hong Kong, China |
| Attention: Qinhong Liao |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2AB6Z-DT173-AS4-SL |
| Name of Grantee: | HUNG WAI HOLDINGS LIMITED |
| Equipment Class: | Part 15 Spread Spectrum Transmitter |
| Notes: | 17.3 inches Quad Core Media Player Slim Housing |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC | 15C | 2402.0 - 2480.0 | 0.0047 |
| Power output listed is conducted. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be collocated or operating in conjunction with any other transmitter. End-users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
EAS Grant - Application k/9aTV/1AxzNYaxeE1xsEA==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
HUNG WAI HOLDINGS LIMITED Unit 11, 12/F., New Commerce Centre, 19 On Sum Street, Shatin, Hong Kong Hong Kong, China |
Date of Grant: 07/24/2016 Application Dated: 07/24/2016 |
| Attention: Qinhong Liao |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2AB6Z-DT173-AS4-SL |
| Name of Grantee: | HUNG WAI HOLDINGS LIMITED |
| Equipment Class: | Part 15 Spread Spectrum Transmitter |
| Notes: | 17.3 inches Quad Core Media Player Slim Housing |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC | 15C | 2402.0 - 2480.0 | 0.0047 |
| Power output listed is conducted. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be collocated or operating in conjunction with any other transmitter. End-users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| Mail To: | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Nemko North America, INC. 303 River Road Ottawa, Ontario, K1V 1H2 Canada |
Date of Grant: 07/24/2016 Application Dated: 07/24/2016 |
| HUNG WAI HOLDINGS LIMITED |
| Unit 11, 12/F., New Commerce Centre, |
| 19 On Sum Street, Shatin, Hong Kong |
| Hong Kong, China |
| Attention: Qinhong Liao |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2AB6Z-DT173-AS4-SL |
| Name of Grantee: | HUNG WAI HOLDINGS LIMITED |
| Equipment Class: | Digital Transmission System |
| Notes: | 17.3 inches Quad Core Media Player Slim Housing |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC | 15C | 2412.0 - 2462.0 | 0.0396 | ||
| CC | 15C | 2402.0 - 2480.0 | 0.0022 |
| Power output listed is conducted. This device has a 20 MHz and 40 MHz bandwidth mode. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other transmitter. End-users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
EAS Grant - Application B14PSEXYsBbJzWVtse9nKQ==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
HUNG WAI HOLDINGS LIMITED Unit 11, 12/F., New Commerce Centre, 19 On Sum Street, Shatin, Hong Kong Hong Kong, China |
Date of Grant: 07/24/2016 Application Dated: 07/24/2016 |
| Attention: Qinhong Liao |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2AB6Z-DT173-AS4-SL |
| Name of Grantee: | HUNG WAI HOLDINGS LIMITED |
| Equipment Class: | Digital Transmission System |
| Notes: | 17.3 inches Quad Core Media Player Slim Housing |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC | 15C | 2412.0 - 2462.0 | 0.0396 | ||
| CC | 15C | 2402.0 - 2480.0 | 0.0022 |
| Power output listed is conducted. This device has a 20 MHz and 40 MHz bandwidth mode. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other transmitter. End-users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| Mail To: |
