FCC ID 2AB7S-NA788
Car Audio System player
by Soundmax Electronics Limited
Grantee Code: 2AB7S Product Code: NA788
Latest application date: 2015-12-13
Device Images
FCC ID Device Details
| FCC ID | 2AB7S-NA788 |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | 2AB7S |
| Product Code | NA788 |
| Applicant Business | Soundmax Electronics Limited 🇨🇳 |
| Related Domains |  soundmax.com.hk |
| Equipment Class | Car Audio System player |
| Test Firm | Dongguan Dongdian Testing Service Co.,Ltd |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 2402-2480 MHz | Original Equipment | 2015-12-13 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| User manual | Users Manual | 2015-12-13 | PDF 1.1 MB |
| Internal photos | Internal Photos | 2015-12-13 | PDF 1.5 MB |
| External photos | External Photos | 2015-12-13 | PDF 386.8 KB |
| Label | ID Label/Location Info | 2015-12-13 | PDF 245.8 KB |
| Test setup | Test Setup Photos | 2015-12-13 | PDF 113 KB |
| Test report | Test Report | 2015-12-13 | PDF 2.5 MB |
| Cover letter | Cover Letter(s) | 2015-12-13 | PDF 350.4 KB |
| RF Exposure | RF Exposure Info | 2015-12-13 | PDF 29.1 KB |
| Block Diagram Metadata only | Block Diagram | PDF 126.9 KB | |
| Schematics Metadata only | Schematics | PDF 904.1 KB | |
| Operational Description Metadata only | Operational Description | PDF 26.1 KB |
Application Information
| Application ID | XTU8ZRSF09i5+zKRh3V+1g== |
|---|---|
| Final Action Date | 2015-12-13 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0023525363 |
| Model | NA788 |
| Frequency Range | 2402-2480 MHz |
| Equipment Class | DSS - Part 15 Spread Spectrum Transmitter |
| Device Description | Car Audio System player |
| Responsible Party | Roy Wu, roy.wu@soundmax.com.hk , 852-2311-1963 |
| Test Firm | Jamy Yu, Dongguan Dongdian Testing Service Co.,Ltd, yqaly@163.com  , 086-0769-22891499 |
| TCB Email | stuart.beck@nemko.com  |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Output power listed is conducted. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| XTU8ZRSF09i5+zKRh3V+1g== | 2015-12-13 | Original Equipment |
Equipment Authorization
| Frequency | Output | Rules |
|---|---|---|
| 2402-2480 MHz | 0.0030900 | 15C |
Grants
TCB Grant - Application XTU8ZRSF09i5+zKRh3V+1g==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Nemko North America, INC. 303 River Road Ottawa, Ontario, K1V 1H2 Canada |
Date of Grant: 12/13/2015 Application Dated: 12/13/2015 |
| Soundmax Electronics Limited |
| 17/F EU YANG SANG TOWER, |
| 11-15 CHATHAM ROAD,T.S.T, KOWLOON |
| Hong Kong, China |
| Attention: Roy Wu |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2AB7S-NA788 |
| Name of Grantee: | Soundmax Electronics Limited |
| Equipment Class: | Part 15 Spread Spectrum Transmitter |
| Notes: | Car Audio System player |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2402.0 - 2480.0 | 0.00309 |
| Output power listed is conducted. |
EAS Grant - Application XTU8ZRSF09i5+zKRh3V+1g==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Soundmax Electronics Limited 17/F EU YANG SANG TOWER, 11-15 CHATHAM ROAD,T.S.T, KOWLOON Hong Kong, China |
Date of Grant: 12/13/2015 Application Dated: 12/13/2015 |
| Attention: Roy Wu |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2AB7S-NA788 |
| Name of Grantee: | Soundmax Electronics Limited |
| Equipment Class: | Part 15 Spread Spectrum Transmitter |
| Notes: | Car Audio System player |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2402.0 - 2480.0 | 0.00309 |
| Output power listed is conducted. |
