ND4 Wearable Device Teardown Internal Photos - FCC ID 2AB8ZND4
FCC ID 2AB8ZND4
Internal Photos
Wearable Device
Document preview loads when visible.
Document Details
| FCC ID | 2AB8ZND4 |
|---|---|
| Document ID | 2663615 |
| Document Type | Internal Photos |
| Description | Internal Photos |
| Applicant | Intel Corporation |
| Equipment Class | Wearable Device |
| Product Code | ND4 |
| Application ID | talrdFs38HPIQiZvfmw7Cg== |
| Application Purpose | Original Equipment |
| Application Date | 2015-07-01 |
| Frequency Range | 2402-2480 MHz |
| FRN | 0023539596 |
| Test Firm | UL LLC |
| Certified By | Grace Rincand |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Short-Term Confidentiality Date | 12/27/2015 |
| Grant Deferral | No |
| Modular Equipment | Limited Single Modular Approval |
| Composite Device | No |
| Composite Part | No |
| Submitted | 2015-07-01 |
| Available | 2015-12-27 |
| Created | 2015-06-25 |
| Modified | 2015-06-25 |
| Pages | 1 |
| File Type | Adobe Acrobat PDF |
| File Size | 200595 |
| File SHA-256 | d82075fdf1d21d0d1ddad12087bd00b4e092ae2e8e286d8c9c88f021c5e6d238 |
| PDF Metadata Producer | Adobe Acrobat 9.3.4 Adobe Acrobat 9.3.4 Image Conversion Plug-in |
| FCC.gov Sources | FCC.gov 2663615, FCC.gov 2663614 |
