FCC ID 2AB99CMIT-AUTO-I100
Vehicle Diagnostic
by Carman International Co., Ltd.
Grantee Code: 2AB99 Product Code: CMITAUTOI100
Latest application date: 2016-06-15
Device Images
FCC ID Device Details
| FCC ID | 2AB99CMIT-AUTO-I100 |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | 2AB99 |
| Product Code | CMITAUTOI100 |
| Applicant Business | Carman International Co., Ltd. 🇰🇷 |
| Related Domains |  carmanit.com |
| Equipment Class | Vehicle Diagnostic |
| Test Firm | CTK Co., Ltd. |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 2402-2480 MHz | Original Equipment | 2016-06-15 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| Users Manual | Users Manual | 2016-06-15 | PDF 894.3 KB |
| Internal Photos | Internal Photos | 2016-06-15 | PDF 1.1 MB |
| External Photos | External Photos | 2016-06-15 | PDF 261.2 KB |
| Label Sample and Location | ID Label/Location Info | 2016-06-15 | PDF 84.5 KB |
| Test Setup Photos | Test Setup Photos | 2016-06-15 | PDF 526.4 KB |
| Test Report | Test Report | 2016-06-15 | PDF 2.1 MB |
| Attestation Statement FHSS | Cover Letter(s) | 2016-06-15 | PDF 66.1 KB |
| Confidentiality Requst Letter | Cover Letter(s) | 2016-06-15 | PDF 21.2 KB |
| MPE Report | RF Exposure Info | 2016-06-15 | PDF 44.7 KB |
| Block Diagram Metadata only | Block Diagram | PDF 76.1 KB | |
| PCB Layout Schematics Metadata only | Schematics | PDF 388.8 KB | |
| Schematics Metadata only | Schematics | PDF 518.7 KB | |
| Operational Description Metadata only | Operational Description | PDF 106.7 KB | |
| Operational Description Antenna Spec Metadata only | Operational Description | PDF 715.1 KB | |
| Parts List Metadata only | Parts List/Tune Up Info | PDF 69.5 KB |
Application Information
| Application ID | sLE365IGCPhPM3BcD1qX1w== |
|---|---|
| Final Action Date | 2016-06-15 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0023565260 |
| Model | CMIT-AUTO-I100 |
| Frequency Range | 2402-2480 MHz |
| Equipment Class | DSS - Part 15 Spread Spectrum Transmitter |
| Device Description | Vehicle Diagnostic |
| Responsible Party | Tae Min Ahn, Associate Research Engineer, tmahn@carmanit.com , +82-2-2627-4592 |
| Test Firm | Young-Joon Park, CTK Co., Ltd., joonpak@e-ctk.com  , 82-31-339-9871 |
| TCB Email | TEI@TIMCOENGR.COM  |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Power listed is conducted. End-users must be provided with the specific operating instructions for satisfying RF exposure compliance. The device must operate with the minimum separation distance tested for compliance, as described in this filing, which is 20 cm. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| sLE365IGCPhPM3BcD1qX1w== | 2016-06-15 | Original Equipment |
Equipment Authorization
| Frequency | Output | Rules |
|---|---|---|
| 2402-2480 MHz | 0.0020000 | 15C |
Grants
TCB Grant - Application sLE365IGCPhPM3BcD1qX1w==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Timco Engineering, Inc. 849 NW State Road 45 Newberry, FL 32669 |
Date of Grant: 06/15/2016 Application Dated: 06/15/2016 |
| Carman International Co., Ltd. |
| #209, Second floor, Hanshin IT Tower, 272, |
| Digital-ro, Guro-gu |
| Seoul, 08389 South Korea |
| Attention: Tae Min Ahn , Associate Research Engineer |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2AB99CMIT-AUTO-I100 |
| Name of Grantee: | Carman International Co., Ltd. |
| Equipment Class: | Part 15 Spread Spectrum Transmitter |
| Notes: | Vehicle Diagnostic |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2402.0 - 2480.0 | 0.002 |
| Power listed is conducted. End-users must be provided with the specific operating instructions for satisfying RF exposure compliance. The device must operate with the minimum separation distance tested for compliance, as described in this filing, which is 20 cm. |
EAS Grant - Application sLE365IGCPhPM3BcD1qX1w==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Carman International Co., Ltd. #209, Second floor, Hanshin IT Tower, 272, Digital-ro, Guro-gu Seoul, 08389 South Korea |
Date of Grant: 06/15/2016 Application Dated: 06/15/2016 |
| Attention: Tae Min Ahn , Associate Research Engineer |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2AB99CMIT-AUTO-I100 |
| Name of Grantee: | Carman International Co., Ltd. |
| Equipment Class: | Part 15 Spread Spectrum Transmitter |
| Notes: | Vehicle Diagnostic |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2402.0 - 2480.0 | 0.002 |
| Power listed is conducted. End-users must be provided with the specific operating instructions for satisfying RF exposure compliance. The device must operate with the minimum separation distance tested for compliance, as described in this filing, which is 20 cm. |
