M63F BLUETOOTH SPEAKER Test Setup Photos - FCC ID 2AB9SM63F

FCC ID 2AB9SM63F

Test Setup Photos

BLUETOOTH SPEAKER

by Shenzhen Jonter Digital Co., Ltd

Document preview loads when visible.

Document Details

FCC ID2AB9SM63F
Document ID3911096
Document TypeTest Setup Photos
DescriptionTest Setup Photos
ApplicantShenzhen Jonter Digital Co., Ltd
Equipment ClassBLUETOOTH SPEAKER
Product CodeM63F
Application IDiHQlxiCFZwLbg5OneGwQcQ==
Application PurposeOriginal Equipment
Application Date2018-07-03
Frequency Range2402-2480 MHz
FRN0023545940
Test FirmAttestation of Global Compliance (Shenzhen) Co., L
Certified ByXiaohuai Wang General Manager
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2018-07-03
Available2018-07-03
Created2018-06-27
Modified2018-06-27
Pages3
File TypeAdobe Acrobat PDF
File Size409335
File SHA-256b42043aeaad66eb92bdf03aa9a6bf573a50ccf645c468c669bd2d31fced797ce
PDF Metadata AuthorAdministrator
PDF Metadata ProducerMicrosoft® Office Word 2007 Microsoft® Office Word 2007
FCC.gov SourcesFCC.gov 3911096
