FCC ID 2ABLX-140704
ZigBee RFIC
by The Watt Stopper Inc., d/b/a Qmotion
Grantee Code: 2ABLX Product Code: 140704
Latest application date: 2016-01-11
Device Images
FCC ID Device Details
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 2405-2480 MHz | Original Equipment | 2016-01-11 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| User Manual | Users Manual | 2016-01-11 | PDF 919.1 KB |
| Internal Photos | Internal Photos | 2016-01-11 | PDF 870.7 KB |
| External Photos | External Photos | 2016-01-11 | PDF 359.8 KB |
| Label Info | ID Label/Location Info | 2016-01-11 | PDF 130.7 KB |
| Test Setup Photos | Test Setup Photos | 2016-01-11 | PDF 986.7 KB |
| Test Report | Test Report | 2016-01-11 | PDF 666.4 KB |
| Agency Authorization Letter | Cover Letter(s) | 2016-01-11 | PDF 158 KB |
| Confidentiality Letter | Cover Letter(s) | 2016-01-11 | PDF 44.4 KB |
| RF Exposure Info | RF Exposure Info | 2016-01-11 | PDF 6.6 KB |
| Block Diagram Metadata only | Block Diagram | PDF 26.4 KB | |
| Schematics Metadata only | Schematics | PDF 41.8 KB | |
| Operational Description Metadata only | Operational Description | PDF 251.1 KB | |
| Operational Description Antenna Specification Metadata only | Operational Description | PDF 221.8 KB |
Application Information
| Application ID | k998xmq+xej5UA/g3gx2SA== |
|---|---|
| Final Action Date | 2016-01-11 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0019566918 |
| Model | 140704 |
| Frequency Range | 2405-2480 MHz |
| Equipment Class | DTS - Digital Transmission System |
| Device Description | ZigBee RFIC |
| Responsible Party | David Ayer, RF Design Engineer, dayer@qmotionshades.com  , 850-308-7328 |
| Test Firm | George Yang, US Tech, gyang@ustech-lab.com  , 770-740-0717 |
| TCB Email | tei@timcoengr.com  |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Power listed is conducted. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operated in conjunction with any other antenna or transmitter. Users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| k998xmq+xej5UA/g3gx2SA== | 2016-01-11 | Original Equipment |
Equipment Authorization
| Frequency | Output | Rules |
|---|---|---|
| 2405-2480 MHz | 0.0740000 | 15C |
Grants
TCB Grant - Application k998xmq+xej5UA/g3gx2SA==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Timco Engineering, Inc. 849 NW State Road 45 Newberry, FL 32669 |
Date of Grant: 01/11/2016 Application Dated: 01/11/2016 |
| The Watt Stopper Inc., d/b/a Qmotion |
| 3400 Copter Rd. |
| Pensacola, FL 32514 |
| Attention: David Ayer , RF Design Engineer |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2ABLX-140704 |
| Name of Grantee: | The Watt Stopper Inc., d/b/a Qmotion |
| Equipment Class: | Digital Transmission System |
| Notes: | ZigBee RFIC |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2405.0 - 2480.0 | 0.074 |
| Power listed is conducted. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operated in conjunction with any other antenna or transmitter. Users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. |
EAS Grant - Application k998xmq+xej5UA/g3gx2SA==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
The Watt Stopper Inc., d/b/a Qmotion 3400 Copter Rd. Pensacola, FL 32514 United States |
Date of Grant: 01/11/2016 Application Dated: 01/11/2016 |
| Attention: David Ayer , RF Design Engineer |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2ABLX-140704 |
| Name of Grantee: | The Watt Stopper Inc., d/b/a Qmotion |
| Equipment Class: | Digital Transmission System |
| Notes: | ZigBee RFIC |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2405.0 - 2480.0 | 0.074 |
| Power listed is conducted. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operated in conjunction with any other antenna or transmitter. Users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. |
