FCC ID 2ABLX-150562Z
Zigbee Hardwired Dual Channel Switch
by The Watt Stopper Inc., d/b/a Qmotion
Grantee Code: 2ABLX Product Code: 150562Z
Latest application date: 2016-01-28
Device Images
FCC ID Device Details
| FCC ID | 2ABLX-150562Z |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | 2ABLX |
| Product Code | 150562Z |
| Applicant Business | The Watt Stopper Inc., d/b/a Qmotion 🇺🇸 |
| Related Domains |  qmotionshades.com |
| Equipment Class | Zigbee Hardwired Dual Channel Switch |
| Test Firm | TUV SUD America, Inc. |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 2405-2480 MHz | Original Equipment | 2016-01-28 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| Manual | Users Manual | 2016-01-28 | PDF 1.4 MB |
| Internal Photos | Internal Photos | 2016-01-28 | PDF 450.4 KB |
| External Photos | External Photos | 2016-01-28 | PDF 1.1 MB |
| Label Information | ID Label/Location Info | 2016-01-28 | PDF 788.2 KB |
| Test Setup Photos | Test Setup Photos | 2016-01-28 | PDF 984 KB |
| Test Report | Test Report | 2016-01-28 | PDF 794.5 KB |
| Agency Agreement | Cover Letter(s) | 2016-01-28 | PDF 684.9 KB |
| Confidentiality Request | Cover Letter(s) | 2016-01-28 | PDF 1.2 MB |
| FCC Cover Letter | Cover Letter(s) | 2016-01-28 | PDF 12.7 KB |
| RF Exposure | RF Exposure Info | 2016-01-28 | PDF 41.7 KB |
| Block Diagram Metadata only | Block Diagram | PDF 59.2 KB | |
| Schematics Metadata only | Schematics | PDF 48.2 KB | |
| Theory of Operation Metadata only | Operational Description | PDF 108.5 KB |
Application Information
| Application ID | jUSU5JPGwF5PTGuYpixQqQ== |
|---|---|
| Final Action Date | 2016-01-28 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0019566918 |
| Model | 150562Z |
| Frequency Range | 2405-2480 MHz |
| Equipment Class | DTS - Digital Transmission System |
| Device Description | Zigbee Hardwired Dual Channel Switch |
| Responsible Party | David Ayer, RF Design Engineer, dayer@qmotionshades.com , 850-308-7328 |
| Agent | Sam Sam Sam, Advanced Compliance Solutions, Inc. |
| Test Firm | Sam Wismer, TUV SUD America, Inc., swismer@tuvam.com  , 678-341-5924 |
| TCB Email | jwoods@acstestlab.com  |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Power listed is conducted. This device must be installed to provide a separation distance of at least 20 cm from all persons. Users must be provided with device operating conditions for satisfying RF exposure compliance. Device must operate with a source-based, time-averaged duty cycle not to exceed 66% controlled via software or firmware. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| jUSU5JPGwF5PTGuYpixQqQ== | 2016-01-28 | Original Equipment |
Equipment Authorization
| Frequency | Output | Rules |
|---|---|---|
| 2405-2480 MHz | 0.0006000 | 15C |
Grants
TCB Grant - Application jUSU5JPGwF5PTGuYpixQqQ==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
TUV SUD America Inc. 401 Edgewater Place Suite #500 Wakefield, MA 01880 |
Date of Grant: 01/28/2016 Application Dated: 01/28/2016 |
| The Watt Stopper Inc., d/b/a Qmotion |
| 3400 Copter Rd. |
| Pensacola, FL 32514 |
| Attention: David Ayer , RF Design Engineer |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2ABLX-150562Z |
| Name of Grantee: | The Watt Stopper Inc., d/b/a Qmotion |
| Equipment Class: | Digital Transmission System |
| Notes: | Zigbee Hardwired Dual Channel Switch |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2405.0 - 2480.0 | 0.0006 |
| Power listed is conducted. This device must be installed to provide a separation distance of at least 20 cm from all persons. Users must be provided with device operating conditions for satisfying RF exposure compliance. Device must operate with a source-based, time-averaged duty cycle not to exceed 66% controlled via software or firmware. |
EAS Grant - Application jUSU5JPGwF5PTGuYpixQqQ==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
The Watt Stopper Inc., d/b/a Qmotion 3400 Copter Rd. Pensacola, FL 32514 United States |
Date of Grant: 01/28/2016 Application Dated: 01/28/2016 |
| Attention: David Ayer , RF Design Engineer |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2ABLX-150562Z |
| Name of Grantee: | The Watt Stopper Inc., d/b/a Qmotion |
| Equipment Class: | Digital Transmission System |
| Notes: | Zigbee Hardwired Dual Channel Switch |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2405.0 - 2480.0 | 0.0006 |
| Power listed is conducted. This device must be installed to provide a separation distance of at least 20 cm from all persons. Users must be provided with device operating conditions for satisfying RF exposure compliance. Device must operate with a source-based, time-averaged duty cycle not to exceed 66% controlled via software or firmware. |
| Mail To: |
