FCC ID 2ABN7SWDVR850H
Wireless Digital Video Recorder
by SHENZHEN BAICHUAN SECURITY TECHNOLOGY CO., LTD
Grantee Code: 2ABN7 Product Code: SWDVR850H
Latest application date: 2016-06-24
Device Images
FCC ID Device Details
| FCC ID | 2ABN7SWDVR850H |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | 2ABN7 |
| Product Code | SWDVR850H |
| Applicant Business | SHENZHEN BAICHUAN SECURITY TECHNOLOGY CO., LTD 🇨🇳 |
| Related Domains |  sz-bcs.com.cn |
| Equipment Class | Wireless Digital Video Recorder |
| Test Firm | Shenzhen BCTC Technology Co., Ltd. |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 2405-2480 MHz | Original Equipment | 2016-06-24 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| Manual | Users Manual | 2016-06-24 | PDF 1.6 MB |
| Internal Photos | Internal Photos | 2016-06-24 | PDF 856.2 KB |
| External Photos | External Photos | 2016-06-24 | PDF 448.3 KB |
| label&label location | ID Label/Location Info | 2016-06-24 | PDF 101.8 KB |
| Setup Photos | Test Setup Photos | 2016-06-24 | PDF 155.6 KB |
| Test Report | Test Report | 2016-06-24 | PDF 1.6 MB |
| Agent Authorization Letter | Cover Letter(s) | 2016-06-24 | PDF 83 KB |
| Long Term Confidentiality Request Letter | Cover Letter(s) | 2016-06-24 | PDF 107.3 KB |
| MPE | RF Exposure Info | 2016-06-24 | PDF 183.7 KB |
| Block diagram Metadata only | Block Diagram | PDF 76.2 KB | |
| Sch Metadata only | Schematics | PDF 250.2 KB | |
| operation description Metadata only | Operational Description | PDF 97.1 KB | |
| BOM Metadata only | Parts List/Tune Up Info | PDF 58.4 KB |
Application Information
| Application ID | H039T3MGQIRRcs+h6P1+7Q== |
|---|---|
| Final Action Date | 2016-06-24 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0023244817 |
| Model | SWDVR850H |
| Frequency Range | 2405-2480 MHz |
| Equipment Class | DTS - Digital Transmission System |
| Device Description | Wireless Digital Video Recorder |
| Responsible Party | Aijun Wang, General Manager, duwch@sz-bcs.com.cn , (86) 755-86199350 |
| Technical Contact | James Zhang, Shenzhen BCTC Technology Co., Ltd, jams.zhang@btc-lab.com  , 86-755-33640208 |
| Test Firm | James Zhang, Shenzhen BCTC Technology Co., Ltd., jams.zhang@btc-lab.com , 86-755-33640208 |
| TCB Email | tcbinfo@metlabs.com  |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Output power is conducted. The antenna used for this transmitter as shown in this filing must provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| H039T3MGQIRRcs+h6P1+7Q== | 2016-06-24 | Original Equipment |
Equipment Authorization
| Frequency | Output | Rules |
|---|---|---|
| 2405-2480 MHz | 0.0039000 | 15C |
Grants
TCB Grant - Application H039T3MGQIRRcs+h6P1+7Q==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Eurofins Electrical and Electronic Testing NA, Inc 914 W. Patapsco Avenue Baltimore, MD 21230-3432 |
Date of Grant: 06/24/2016 Application Dated: 06/24/2016 |
| SHENZHEN BAICHUAN SECURITY TECHNOLOGY CO., LTD |
| 2-4th Floor, Building 2, YuanLing Industrial Park |
| ShangWu, Shiyan Street, Bao'an District |
| Shenzhen, 518000 China |
| Attention: Aijun Wang , General Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2ABN7SWDVR850H |
| Name of Grantee: | SHENZHEN BAICHUAN SECURITY TECHNOLOGY CO., LTD |
| Equipment Class: | Digital Transmission System |
| Notes: | Wireless Digital Video Recorder |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2405.0 - 2480.0 | 0.0039 |
| Output power is conducted. The antenna used for this transmitter as shown in this filing must provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter |
EAS Grant - Application H039T3MGQIRRcs+h6P1+7Q==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
SHENZHEN BAICHUAN SECURITY TECHNOLOGY CO., LTD 2-4th Floor, Building 2, YuanLing Industrial Park ShangWu, Shiyan Street, Bao'an District Shenzhen, 518000 China |
Date of Grant: 06/24/2016 Application Dated: 06/24/2016 |
| Attention: Aijun Wang , General Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2ABN7SWDVR850H |
| Name of Grantee: | SHENZHEN BAICHUAN SECURITY TECHNOLOGY CO., LTD |
| Equipment Class: | Digital Transmission System |
| Notes: | Wireless Digital Video Recorder |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2405.0 - 2480.0 | 0.0039 |
| Output power is conducted. The antenna used for this transmitter as shown in this filing must provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter |
