1. FCC ID
  2. 2ABOS
  3. 2ABOSGC140602
  4. Test Setup Photos of the EUT_SAR

GC140602 WCDMA Mobile Phone Test Setup Photos - FCC ID 2ABOSGC140602

FCC ID 2ABOSGC140602

Test Setup Photos of the EUT_SAR

WCDMA Mobile Phone

by Sky Phone LLC

Document preview loads when visible.

Document Details

FCC ID2ABOSGC140602
Document ID2354248
Document TypeTest Setup Photos
DescriptionTest Setup Photos of the EUT_SAR
Document Title1407FS15_SAR Test Setup Photographs _14-0629_
ApplicantSky Phone LLC
Equipment ClassWCDMA Mobile Phone
Product CodeGC140602
Application ID4sOGL5WMVvLEDQhSdaDwBA==
Application PurposeOriginal Equipment
Application Date2014-08-12
Frequency Range2402-2480 MHz
FRN0023252042
Test FirmA Test Lab Techno Corp.
Certified ByRoberto Conrado
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceYes
Composite PartNo
Submitted2014-08-12
Available2014-08-12
Created2014-08-01
Modified2014-08-05
Pages13
File TypeAdobe Acrobat PDF
File Size672970
File SHA-2565c6e749840e43d2bcc0bebf057f62edd6b2f54090af07d594497247e8b7eb2a4
PDF Metadata Authorpeggy.chang
PDF Metadata Producerpeggy.chang Acrobat Distiller 8.1.0 (Windows)
FCC.gov SourcesFCC.gov 2354248, FCC.gov 2354234
