Shenzhen Zhongjian Nanfang Testing Co., Ltd.
Report No: CCISE181213401
1. Cover Page
FCC REPORT
(GSM & WCDMA)
Applicant:
SKY PHONE LLC
Address of Applicant:
1348 Washington Av. Suite 350, Miami Beach, FL 33139
Equipment Under Test (EUT)
Product Name:
3G Smart Phone
Model No.:
Platinum UNO
Trade mark:
SKY DEVICES
FCC ID:
2ABOSSKYPLATUNO
Applicable standards:
FCC CFR Title 47 Part 2
FCC CFR Title 47 Part 22 Subpart H
FCC CFR Title 47 Part 24 Subpart E
FCC CFR Title 47 Part 27 Subpart L
Date of sample receipt:
27 Dec., 2018
Date of Test:
27 Dec., 2018 to 22 Feb., 2019
Date of report issued:
22 Feb., 2019
Test Result:
PASS*
In the configuration tested, the EUT complied with the standards specified above.
Authorized Signature:
Bruce Zhang
Laboratory Manager
This report details the results of the testing carried out on one sample. The results contained in this test report do not relate to other
samples of the same product and does not permit the use of the CCIS product certification mark. The manufacturer should ensure that all
products in series production are in conformity with the product sample detailed in this report.
This report may only be reproduced and distributed in full. If the product in this report is used in any configuration other than that detailed in
the report, the manufacturer must ensure the new system complies with all relevant standards.
This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or
falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law.
Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days
only.
Report No: CCISE181213401
2. Version
Version No.
Date
Description
00
22 Feb., 2019
Original
Tested by:
Date:
22 Feb., 2019
Date:
22 Feb., 2019
Test Engineer
Reviewed by:
Project Engineer
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
Project No.: CCISE1812134
Page 2 of 55
Report No: CCISE181213401
3. Contents
Page
1.
COVER PAGE .............................................................................................................................................................. 1
2.
VERSION ....................................................................................................................................................................... 2
3.
CONTENTS................................................................................................................................................................... 3
4.
TEST SUMMARY ......................................................................................................................................................... 4
5.
GENERAL INFORMATION ........................................................................................................................................ 5
5.1
5.2
5.3
5.4
5.5
5.6
5.7
5.8
6.
CLIENT INFORMATION ............................................................................................................................................ 5
GENERAL DESCRIPTION OF E.U.T........................................................................................................................ 5
TEST MODES .......................................................................................................................................................... 7
DESCRIPTION OF SUPPORT UNITS ........................................................................................................................ 7
MEASUREMENT UNCERTAINTY.............................................................................................................................. 7
LABORATORY FACILITY.......................................................................................................................................... 7
LABORATORY LOCATION ....................................................................................................................................... 8
TEST INSTRUMENTS LIST ....................................................................................................................................... 8
TEST RESULTS ........................................................................................................................................................... 9
6.1
6.2
6.3
6.4
6.5
6.6
6.7
6.8
CONDUCTED OUTPUT POWER, ERP AND EIRP .................................................................................................. 9
PEAK-TO-AVERAGE POWER RATIO .................................................................................................................... 13
OCCUPY BANDWIDTH .......................................................................................................................................... 15
MODULATION CHARACTERISTIC .......................................................................................................................... 22
OUT OF BAND EMISSION AT ANTENNA TERMINALS .............................................................................................. 22
FIELD STRENGTH OF SPURIOUS RADIATION MEASUREMENT............................................................................... 31
FREQUENCY STABILITY V.S. TEMPERATURE MEASUREMENT............................................................................. 37
FREQUENCY STABILITY V.S. VOLTAGE MEASUREMENT ..................................................................................... 40
TEST SETUP PHOTO ............................................................................................................................................... 42
EUT CONSTRUCTIONAL DETAILS ...................................................................................................................... 43
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
Project No.: CCISE1812134
Page 3 of 55
Report No: CCISE181213401
4. Test Summary
Test Item
Section in CFR 47
Result
RF Exposure (SAR)
Part 1.1307
Part 2.1093
Pass
(Please refer to
SAR Report)
RF Output Power
Part 2.1046
Part 22.913 (a)(2)
Part 24.232 (c)
Part 27.50 (d)(4)
Pass
Peak-to-Average Power Ratio
Part 24.232 (d)
Part 27.50(d)(5)
Pass
Modulation Characteristics
Part 2.1047
Pass
99% & -26 dB Occupied Bandwidth
Part 2.1049
Part 22.917(b)
Part 24.238(b)
Part 27.53(h)
Pass
Out of band emission at antenna terminals
Part 2.1053
Part 22.917 (a)
Part 24.238 (a)
Part 27.53 (h)
Pass
Field strength of spurious radiation
Part 22.917 (a)
Part 24.238 (a)
Part 27.53 (h)
Pass
Frequency stability vs. temperature
Part 22.355
Part 24.235
Part 27.54
Part 2.1055(a)(1)(b)
Pass
Frequency stability vs. voltage
Part 22.355
Part 24.235
Part 27.54
Part 2.1055(d)(2)
Pass
Pass: The EUT complies with the essential requirements in the standard.
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
Project No.: CCISE1812134
Page 4 of 55
Report No: CCISE181213401
5. General Information
5.1 Client Information
Applicant:
SKY PHONE LLC
Address:
1348 Washington Av. Suite 350, Miami Beach, FL 33139
Manufacturer
SKY PHONE LLC
Address:
1348 Washington Av. Suite 350, Miami Beach, FL 33139
5.2 General Description of E.U.T.
Product Name:
3G Smart Phone
Model No.:
Platinum UNO
Operation Frequency range:
GSM 850: 824.20MHz-848.80MHz
PCS1900: 1850.20MHz-1909.80MHz
WCDMA Band V: 826.4MHz-846.6MHz
WCDMA Band II: 1852.4 MHz-1907.6 MHz
WCDMA Band IV: 1712.4 MHz-1752.6 MHz
Modulation type:
GSM/GPRS: GMSK, UMTS: QPSK
Antenna type:
Internal Antenna
Antenna gain:
GSM 850: -1.0 dBi
PCS 1900: -1.0 dBi
WCDMA Band V: 1.0 dBi
WCDMA Band II: 1.0 dBi
WCDMA Band IV: 1.0 dBi
Power supply:
Rechargeable Li-ion Battery DC3.7V-2500mAh
AC adapter:
Model: TPA-97050100UU
Input: AC100-240V, 50/60Hz, 0.15A
Output: DC 5.0V, 1000mA
Test Sample Condition:
The test samples were provided in good working order with no visible
defects.
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
Project No.: CCISE1812134
Page 5 of 55
Report No: CCISE181213401
Operation Frequency List:
GSM 850
Channel
Frequency (MHz)
128
824.20
129
824.40
….
….
189
836.40
190
836.60
191
836.80
…
…
250
848.60
251
848.80
WCDMA Band V
Channel
Frequency (MHz)
4132
826.40
4133
826.60
….
….
4182
836.40
4183
836.60
4184
836.80
…
…
4232
846.40
4233
846.60
WCDMA Band IV
Channel
Frequency (MHz)
1312
1712.40
1313
1712.60
….
….
1412
1732.40
1413
1732.60
1414
1732.80
…
…
1512
1752.40
1513
1752.60
PCS1900
Channel
512
513
….
660
661
662
…
809
810
Frequency (MHz)
1850.20
1850.40
….
1879.80
1880.00
1880.20
…
1909.60
1909.80
WCDMA Band II
Channel
Frequency (MHz)
9262
1852.40
9263
1852.60
….
….
9399
1879.80
9400
1880.00
9401
1880.20
…
…
9537
1907.40
9538
1907.60
Regards to the operating frequency range over 10 MHz, the Lowest frequency, the middle frequency, and the
highest frequency of channel were selected to perform the test, and the selected channel see below:
GSM850
Channel
Frequency(MHz)
Lowest channel
128
824.20
Middle channel
190
836.60
Highest channel
251
848.80
WCDMA Band V
Channel
Frequency(MHz)
Lowest channel
4132
826.40
Middle channel
4183
836.60
Highest channel
4233
846.60
WCDMA Band IV
Channel
Frequency(MHz)
Lowest channel
1312
1712.40
Middle channel
1413
1732.60
Highest channel
1513
1752.60
PCS1900
Channel
Frequency(MHz)
Lowest channel
512
1850.20
Middle channel
661
1880.00
Highest channel
810
1909.80
WCDMA Band II
Channel
Frequency(MHz)
Lowest channel
9262
1852.40
Middle channel
9400
1880.00
Highest channel
9538
1907.60
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
Project No.: CCISE1812134
Page 6 of 55
Report No: CCISE181213401
5.3 Test modes
Operating Environment:
Temperature:
Normal: 15℃ ~ 35℃, Extreme: -30℃ ~ +50℃
Humidity:
20 % ~ 75 % RH
Atmospheric Pressure: 1008 mbar
Voltage:
Nominal: 3.7Vdc, Extreme: Low 3.5 Vdc, High 4.2 Vdc
Test mode:
GSM mode
Keep the EUT communication with simulated station in GSM mode
GPRS mode
Keep the EUT communication with simulated station in GPRS mode
RMC mode
Keep the EUT communication with simulated station in RMC mode
HSDPA
Keep the EUT communication with simulated station in HSDPA mode
HSUPA
Keep the EUT communication with simulated station in HSUPA mode
Remark: The EUT has been tested under continuous transmitting mode. Channel Low, Mid and High
for each type band with rated data rate were chosen for full testing. The field strength of spurious
radiation emission was measured as EUT stand-up position (H mode) and lie down position (E1, E2
mode) for these modes with power adaptor, earphone and Data cable. Just the worst case position (H
mode) shown in report.
5.4 Description of Support Units
Test Equipment
Manufacturer
Model No.
Serial No.
Simulated Station
Anritsu
MT8820C
6201026545
5.5 Measurement Uncertainty
Parameters
Radiated Emission (9kHz ~ 30MHz)
Radiated Emission (30MHz ~ 1000MHz)
Radiated Emission (1GHz ~ 18GHz)
Radiated Emission (18GHz ~ 40GHz)
Expanded Uncertainty
±2.76 dB (k=2)
±4.28 dB (k=2)
±5.72 dB (k=2)
±2.88 dB (k=2)
5.6 Laboratory Facility
The test facility is recognized, certified, or accredited by the following organizations:
 FCC - Registration No.: 727551
Shenzhen Zhongjian Nanfang Testing Co., Ltd. has been accredited as a testing laboratory by FCC
(Federal Communications Commission). The Registration No. is 727551.
 IC - Registration No.: 10106A-1
The 3m Semi-anechoic chamber of Shenzhen Zhongjian Nanfang Testing Co., Ltd. has been
Registered by Certification and Engineering Bureau of Industry Canada for radio equipment testing with
Registration No.: 10106A-1.
 CNAS - Registration No.: CNAS L6048
Shenzhen Zhongjian Nanfang Testing Co., Ltd. is accredited to ISO/IEC 17025:2005 General
Requirements for the Competence of Testing and Calibration laboratories for the competence of
testing. The Registration No. is CNAS L6048.
 A2LA - Registration No.: 4346.01
This laboratory is accredited in accordance with the recognized International Standard ISO/IEC
17025:2005 General requirements for the competence of testing and calibration laboratories. The test
scope can be found as below link: https://portal.a2la.org/scopepdf/4346-01.pdf
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
Project No.: CCISE1812134
Page 7 of 55
Report No: CCISE181213401
5.7 Laboratory Location
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
Address: No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Tel: +86-755-23118282, Fax: +86-755-23116366
Email: info@ccis-cb.com, Website: http://www.ccis-cb.com
5.8 Test Instruments list
966
497
359
916
1805
BBHA9170582
Cal. Date
(mm-dd-yy)
07-22-2017
03-16-2018
06-22-2017
03-16-2018
06-22-2017
11-21-2018
Cal. Due date
(mm-dd-yy)
07-21-2020
03-15-2019
06-21-2020
03-15-2019
06-21-2020
11-20-2019
2944A09358
11804
101454
100363
Version: 6.110919b
03-07-2018
03-07-2018
03-07-2018
11-21-2018
03-06-2019
03-06-2019
03-06-2019
11-20-2019
Test Equipment
Manufacturer
Model No.
Serial No.
3m SAC
BiConiLog Antenna
Biconical Antenna
Horn Antenna
Horn Antenna
Horn Antenna
SAEMC
SCHWARZBECK
SCHWARZBECK
SCHWARZBECK
SCHWARZBECK
SCHWARZBECK
9m*6m*6m
VULB9163
VUBA9117
BBHA9120D
BBHA9120D
BBHA 9170
EMI Test Software
Pre-amplifier
Pre-amplifier
Spectrum analyzer
Spectrum analyzer
AUDIX
HP
CD
Rohde & Schwarz
Rohde & Schwarz
E3
8447D
PAP-1G18
FSP30
FSP40
EMI Test Receiver
Spectrum Analyzer
Signal Generator
Signal Generator
RF Switch Unit
Test Software
Cable
Cable
Cable
DC Power Supply
Temperature
Humidity Chamber
Simulated Station
Rohde & Schwarz
Agilent
Rohde & Schwarz
R&S
MWRFTEST
MWRFTEST
ZDECL
MICRO-COAX
SUHNER
XinNuoEr
ESRP7
N9020A
SMX
SMR20
MW200
MTS8200
Z108-NJ-NJ-81
MFR64639
SUCOFLEX100
WYK-10020K
HengPu
HPGDS-500
20140828008
09-24-2018
09-23-2019
Rohde & Schwarz
CMW500
140493
07-16-2018
07-15-2019
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
101070
MY50510123
835454/016
1008100050
N/A
03-07-2018
11-10-2018
03-07-2018
03-07-2018
N/A
Version: 2.0.0.0
1608458
03-07-2018
K10742-5
03-07-2018
58193/4PE
03-07-2018
1409050110020
10-31-2018
03-06-2019
11-09-2019
03-06-2019
03-06-2019
N/A
03-06-2019
03-06-2019
03-06-2019
10-30-2019
Project No.: CCISE1812134
Page 8 of 55
Report No: CCISE181213401
6. Test results
6.1 Conducted Output Power, ERP and EIRP
Test Requirement:
FCC part 22.913(a)(2), FCC part 24.232(c), FCC part 27.50(d)(4)
Test Method:
ANSI/TIA-603-D 2010
Limit:
GSM 850: 7W, PCS 1900: 2W
WCDMA Band V: 7W, WCDMA Band II: 2W, WCDMA Band IV: 1W
Test setup:
Test Procedure:
The transmitter output was connected to a calibrated attenuator, the other
end of which was connected to the simulated station. Transmitter output
power was read off in dBm.
Test Instruments:
Refer to section 5.8 for details
Test mode:
Refer to section 5.3 for details
Test results:
Passed
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
Project No.: CCISE1812134
Page 9 of 55
Report No: CCISE181213401
Measurement Data:
EUT Mode
128
824.20 (MHz)
33.32
33.25
32.65
30.60
29.15
GSM 850
GPRS 850 (1 Uplink slot)
GPRS 850 (2 Uplink slot)
GPRS 850 (3 Uplink slot)
GPRS 850 (4 Uplink slot)
Antenna Gain (dBi)
Max. ERP (dBm)
ERP Limit (dBm)
EUT Mode
PCS 1900
GPRS 1900 (1 Uplink slot)
GPRS 1900 (2 Uplink slot)
GPRS 1900 (3 Uplink slot)
GPRS 1900 (4 Uplink slot)
Antenna Gain (dBi)
Max. EIRP (dBm)
EIRP Limit (dBm)
Burst Average power (dBm)
190
251
836.60 (MHz)
848.80 (MHz)
33.33
33.35
33.25
33.26
32.62
32.63
30.40
30.32
28.88
28.75
-1.0
30.20
38.45
Burst Average power (dBm)
512
661
810
1850.20 (MHz)
1880.00 (MHz)
1909.80 (MHz)
29.59
29.22
29.05
29.57
29.21
29.04
28.87
28.42
28.24
26.98
26.42
26.23
25.78
25.20
24.91
-1.0
28.59
33.00
Note: EIRP (dBm) = Burst Average power (dBm) + Antenna Gain (dBi).
ERP (dBm ) = EIRP (dBm) - 2.15 (dB).
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
Project No.: CCISE1812134
Page 10 of 55
Report No: CCISE181213401
EUT Mode
UMTS 850
HSDPA
UMTS 850
HSUPA
UMTS 850 RMC
UMTS 850 AMR
Antenna Gain (dBi)
Max. ERP (dBm)
ERP Limit (dBm)
Subtest 1
Subtest 2
Subtest 3
Subtest 4
Subtest 1
Subtest 2
Subtest 3
Subtest 4
Subtest 5
12.2kbps
12.2kbps
4132
826.40 (MHz)
21.69
21.40
19.86
19.95
21.60
21.60
19.82
21.67
20.83
22.65
22.64
Subtest 1
Subtest 2
Subtest 3
Subtest 4
Subtest 1
Subtest 2
Subtest 3
Subtest 4
Subtest 5
12.2kbps
12.2kbps
9262
1852.40
(MHz)
22.12
21.69
20.17
20.24
21.97
22.08
20.13
22.08
21.11
23.04
22.99
EUT Mode
UMTS 1900
HSDPA
UMTS 1900
HSUPA
UMTS 1900 RMC
UMTS 1900 AMR
Antenna Gain (dBi)
Max. EIRP (dBm)
EIRP Limit (dBm)
Burst Average power (dBm)
4183
4233
836.60 (MHz)
846.60 (MHz)
21.61
21.63
21.29
21.29
19.78
19.77
19.69
19.72
21.51
21.58
21.53
21.53
19.61
19.77
21.60
21.62
20.71
20.73
22.51
22.65
22.51
22.62
1.0
21.50
38.45
Burst Average power (dBm)
9400
1880.00
(MHz)
21.96
21.56
20.03
20.01
21.87
21.88
20.06
21.93
20.94
22.90
22.88
1.0
24.04
33.00
9538
1907.60
(MHz)
21.66
21.25
19.76
19.92
21.61
21.45
19.75
21.68
20.82
22.71
22.67
Note: EIRP (dBm) = Burst Average power (dBm) + Antenna Gain (dBi).
ERP (dBm ) = EIRP (dBm) - 2.15 (dB).
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
Project No.: CCISE1812134
Page 11 of 55
Report No: CCISE181213401
EUT Mode
UMTS 1700
HSDPA
UMTS 1700
HSUPA
UMTS 1700 RMC
UMTS 1700 AMR
Antenna Gain (dBi)
Max. EIRP (dBm)
EIRP Limit (dBm)
Subtest 1
Subtest 2
Subtest 3
Subtest 4
Subtest 1
Subtest 2
Subtest 3
Subtest 4
Subtest 5
12.2kbps
12.2kbps
Burst Average power (dBm)
1312
1412
1513
1712.40 (MHz)
1732.40 (MHz)
1752.60 (MHz)
22.16
22.20
22.23
21.74
21.85
21.93
20.42
20.40
20.56
20.25
20.24
20.42
22.15
22.17
22.21
22.16
22.15
22.21
20.24
20.33
20.32
22.21
22.21
22.21
21.19
21.19
21.24
23.11
23.23
23.21
23.04
23.18
23.09
1.0
24.23
30.00
Note: EIRP (dBm) = Burst Average power (dBm) + Antenna Gain (dBi).
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
Project No.: CCISE1812134
Page 12 of 55
Report No: CCISE181213401
6.2 Peak-to-Average Power Ratio
Test Requirement:
FCC part 24.232(d), FCC part 27.50(d)(5)
Test Method
ANSI/TIA-603-D 2010
Limit:
The peak-to-average ratio (PAR) of the transmission may not exceed 13
dB.
Test setup:
Test Procedure:
The RF output of the transceiver was connected to a spectrum
analyzer through appropriate attenuation.
Set the CCDF option in spectrum analyzer, RBW ≥ OBW,
Set the EUT working in highest power level, measured and recorded
the 0.1% as PAPR level.
Repeat step 1~3 at other frequency and modulations.
Test Instruments:
Refer to section 5.8 for details
Test mode:
Refer to section 5.3 for details
Test results:
Passed
Measurement Data:
Modulation
Test channel
PAPR
GSM 850
190
0.13
PCS 1900
661
0.10
UMTS 850 RMC
4183
3.00
UMTS 1900 RMC
9400
3.12
UMTS1700 RMC
1413
2.48
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
Project No.: CCISE1812134
Page 13 of 55
Report No: CCISE181213401
Test plots as below:
GSM 850
Ref
40
40 dBm
Offset
* Att
* RBW
1 MHz
* VBW
3 MHz
40 dB
10 dB
SWT 2.5 ms
PCS 1900
Delta 1 [T3 ]
-0.13 dB
-40.000000000 kHz
Ref
Marker 1 [T1 ]
11
40
* RBW
1 MHz
* VBW
3 MHz
40 dB
SWT 2.5 ms
10 dB
Delta 1 [T3 ]
-0.10 dB
130.000000000 kHz
Marker 1 [T1 ]
28.73 dBm
1 1
30
1.879940000 GHz
MAXH
20
LVL
20
LVL
10
3 AV *
3 AV *
MAXH
-10
-10
3DB
3DB
-20
-20
-30
-30
-40
-40
-50
-50
-60
-60
Center 836.6 MHz
Date: 29.DEC.2018
500 kHz/
Span 5 MHz
Center 1.88 GHz
17:37:23
Date: 29.DEC.2018
500 kHz/
Middle channel
UMTS 850 RMC
UMTS 1900 RMC
RBW 10 MHz
Ref
30 dBm
Offset
* Att
30 dB
Span 5 MHz
17:38:08
Middle channel
RBW 10 MHz
AQT 3.125 ms
Ref
10 dB
30 dBm
Offset
0.1
1 SA
1 PK
10
MAXH
Offset
* Att
33.26 dBm
836.650000000 MHz
30
1 PK
MAXH
40 dBm
30 dB
AQT 3.125 ms
10 dB
0.1
0.01
1 SA
CLRWR
* Att
0.01
CLRWR
LVL
1E-3
1E-4
LVL
1E-3
1E-4
1E-5
1E-5
3DB
Center 836.6 MHz
2 dB/
Mean Pwr + 20 dB
Complementary Cumulative Distribution Function (100000 samples)
Mean
Peak
Crest
10
.1
.01
1.68
2.52
3.00
3.24
Date: 29.DEC.2018
2 dB/
Mean Pwr + 20 dB
Complementary Cumulative Distribution Function (100000 samples)
Trace 1
22.27 dBm
25.63 dBm
3.36 dB
3DB
Center 1.88 GHz
Mean
Peak
Crest
dB
dB
dB
dB
10
.1
.01
17:14:50
Trace 1
21.76 dBm
25.28 dBm
3.51 dB
Date: 29.DEC.2018
Middle channel
1.76
2.68
3.12
3.40
dB
dB
dB
dB
17:14:12
Middle channel
UMTS1700 RMC
RBW 10 MHz
Ref
30 dBm
Offset
* Att
30 dB
AQT 3.125 ms
10 dB
0.1
1 SA
0.01
CLRWR
LVL
1E-3
1E-4
1E-5
3DB
Center 1.7326 GHz
2 dB/
Mean Pwr + 20 dB
Complementary Cumulative Distribution Function (100000 samples)
Mean
Peak
Crest
10
.1
.01
Trace 1
22.36 dBm
25.06 dBm
2.70 dB
Date: 29.DEC.2018
1.56
2.16
2.48
2.60
dB
dB
dB
dB
17:14:33
Middle channel
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
Project No.: CCISE1812134
Page 14 of 55
Report No: CCISE181213401
6.3 Occupy Bandwidth
Test Requirement:
FCC part 22.917(b), FCC part 24.238(b), FCC Part 27.53(h)
Test Method:
ANSI/TIA-603-D 2010
Test setup:
Test Procedure:
1.
2.
3.
The EUT’s output RF connector was connected with a short cable to
the spectrum analyzer
RBW was set to about 1% of emission BW, VBW= 3 times RBW.
-26dBc display line was placed on the screen (or 99% bandwidth),
the occupied bandwidth is the delta frequency between the two
points where the display line intersects the signal trace.
Test Instruments:
Refer to section 5.8 for details
Test mode:
Refer to section 5.3 for details
Test results:
Passed
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
Project No.: CCISE1812134
Page 15 of 55
Report No: CCISE181213401
Measurement Data:
EUT Mode
GSM 850
PCS 1900
UMTS 850
12.2k RMC
UMTS 1900
12.2k RMC
UMTS 1700
12.2k RMC
Channel
Frequency (MHz)
128
190
251
512
661
810
4132
4183
4233
9262
9400
9538
1312
1413
1513
824.2
836.6
848.8
1850.2
1880.0
1909.8
826.4
836.6
846.6
1852.4
1880.0
1907.6
1712.40
1732.60
1752.60
99% Occupy bandwidth
(kHz)
244
248
246
248
242
250
4160
4160
4180
4160
4160
4180
4180
4180
4180
-26dB bandwidth (kHz)
318
322
316
326
318
326
4720
4720
4720
4700
4700
4680
4740
4720
4740
Note:
GSM & GPRS use the same modulation technical (GMSK), and with the same channels, so the 99% OBW and the -26dB
of GPRS not performed.
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
Project No.: CCISE1812134
Page 16 of 55
Report No: CCISE181213401
Test plot as follows:
GSM 850
99% Occupy bandwidth
Ref
40
40 dBm
Offset
* Att
* RBW
10 kHz
* VBW
30 kHz
40 dB
30.43 dBm
SWT 10 ms
10 dB
26dB Emission Bandwidth
Marker 1 [T1 ]
824.212000000 MHz
Ref
OBW244.000000000 kHz
40
40 dBm
Offset
* Att
* RBW
10 kHz
* VBW
30 kHz
40 dB
10 dB
15.41 dBm
30.95 dBm
824.270000000 MHz
ndB [T1]
Temp 1 [T1 OBW]
30
Marker 1 [T1 ]
SWT 10 ms
1 PK
MAXH
T2
T1
Temp 1 [T1 ndB]
4.35 dBm
1 PK
Temp 2 [T1 OBW]
20
26.00 dB
BW 318.000000000 kHz
30
824.080000000 MHz
17.59 dBm LVL
MAXH
824.042000000 MHz
20
Temp 2 [T1 ndB]
824.324000000 MHz
LVL
5.72 dBm
10
10
824.360000000 MHz
T2
T1
-10
-10
3DB
3DB
-20
-20
-30
-30
-40
-40
-50
-50
-60
-60
Center 824.2 MHz
Date: 29.DEC.2018
100 kHz/
Span 1 MHz
Center 824.2 MHz
17:50:56
Date: 29.DEC.2018
100 kHz/
17:51:30
Lowest channel
Ref
40
40 dBm
Offset
* Att
* RBW
10 kHz
* VBW
30 kHz
40 dB
10 dB
Lowest channel
Marker 1 [T1 ]
29.59 dBm
SWT 10 ms
836.626000000 MHz
Ref
OBW248.000000000 kHz
40
40 dBm
Offset
* Att
15.55 dBm
* RBW
10 kHz
* VBW
30 kHz
40 dB
Marker 1 [T1 ]
28.88 dBm
SWT 10 ms
10 dB
836.610000000 MHz
ndB [T1]
Temp 1 [T1 OBW]
30
Span 1 MHz
MAXH
3.20 dBm
1 PK
Temp 2 [T1 OBW]
20
13.15 dBm LVL
T1
T2
Temp 1 [T1 ndB]
836.480000000 MHz
1 PK
26.00 dB
BW 322.000000000 kHz
30
MAXH
836.438000000 MHz
20
Temp 2 [T1 ndB]
836.728000000 MHz
LVL
3.96 dBm
10
836.760000000 MHz
10
T2
T1
-10
-10
3DB
3DB
-20
-20
-30
-30
-40
-40
-50
-50
-60
-60
Center 836.6 MHz
Date: 29.DEC.2018
100 kHz/
Span 1 MHz
Center 836.6 MHz
17:50:43
Date: 29.DEC.2018
100 kHz/
17:50:33
Middle channel
Ref
40
40 dBm
Offset
* Att
* RBW
10 kHz
* VBW
30 kHz
40 dB
SWT 10 ms
10 dB
Middle channel
Marker 1 [T1 ]
30.67 dBm
Ref
848.820000000 MHz
40
OBW246.000000000 kHz
40 dBm
Offset
* Att
40 dB
* RBW
10 kHz
* VBW
30 kHz
SWT 10 ms
10 dB
14.84 dBm
30
29.58 dBm
848.870000000 MHz
MAXH
3.64 dBm
1 PK
Temp 2 [T1 OBW]
20
T1
T2
Temp 1 [T1 ndB]
30
848.678000000 MHz
1 PK
26.00 dB
BW 316.000000000 kHz
Marker 1 [T1 ]
ndB [T1]
Temp 1 [T1 OBW]
Span 1 MHz
14.48 dBm LVL
MAXH
848.642000000 MHz
20
Temp 2 [T1 ndB]
LVL
3.44 dBm
848.924000000 MHz
10
10
848.958000000 MHz
T1
T2
-10
-10
3DB
3DB
-20
-20
-30
-30
-40
-40
-50
-50
-60
-60
Center 848.8 MHz
Date: 29.DEC.2018
100 kHz/
16:56:41
Span 1 MHz
Center 848.8 MHz
Date: 29.DEC.2018
Highest channel
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
100 kHz/
Span 1 MHz
17:25:04
Highest channel
Project No.: CCISE1812134
Page 17 of 55
Report No: CCISE181213401
PCS 1900
99% Occupy bandwidth
Ref
40 dBm
Offset
40
* Att
* RBW
10 kHz
* VBW
30 kHz
40 dB
24.96 dBm
SWT 10 ms
10 dB
26dB Emission Bandwidth
Marker 1 [T1 ]
1.850214000 GHz
Ref
OBW248.000000000 kHz
40 dBm
Offset
40
* Att
40 dB
* RBW
10 kHz
* VBW
30 kHz
ndB [T1]
30
20
10.86 dBm LVL
1.850042000 GHz
MAXH
20
Temp 2 [T1 ndB]
1.850328000 GHz
T2
T1
-0.27 dBm
1 PK
Temp 2 [T1 OBW]
MAXH
Temp 1 [T1 ndB]
1.850080000 GHz
1 PK
26.00 dB
BW 326.000000000 kHz
9.97 dBm
25.11 dBm
1.850186000 GHz
10 dB
Temp 1 [T1 OBW]
30
Marker 1 [T1 ]
SWT 10 ms
LVL
-0.14 dBm
10
10
1.850368000 GHz
T2
T1
-10
-10
3DB
3DB
-20
-20
-30
-30
-40
-40
-50
-50
-60
-60
Center 1.8502 GHz
Date: 29.DEC.2018
100 kHz/
Span 1 MHz
Center 1.8502 GHz
17:48:58
Date: 29.DEC.2018
100 kHz/
17:49:06
Lowest channel
Ref
40 dBm
Offset
40
* Att
* RBW
10 kHz
* VBW
30 kHz
40 dB
10 dB
Lowest channel
Marker 1 [T1 ]
25.96 dBm
SWT 10 ms
Span 1 MHz
1.879996000 GHz
Ref
OBW242.000000000 kHz
40 dBm
Offset
40
* Att
40 dB
* RBW
10 kHz
* VBW
30 kHz
ndB [T1]
MAXH
20
11.77 dBm LVL
1.879842000 GHz
MAXH
20
Temp 2 [T1 ndB]
1.880126000 GHz
T2
T1
-2.60 dBm
1 PK
Temp 2 [T1 OBW]
Temp 1 [T1 ndB]
30
1.879884000 GHz
1 PK
26.00 dB
BW 318.000000000 kHz
10.08 dBm
24.54 dBm
1.879994000 GHz
10 dB
Temp 1 [T1 OBW]
30
Marker 1 [T1 ]
SWT 10 ms
LVL
-1.00 dBm
10
10
-10
1.880160000 GHz
T2
T1
-10
3DB
3DB
-20
-20
-30
-30
-40
-40
-50
-50
-60
-60
Center 1.88 GHz
100 kHz/
Date: 29.DEC.2018
Span 1 MHz
Center 1.88 GHz
17:49:27
100 kHz/
Date: 29.DEC.2018
17:49:17
Middle channel
Ref
40
40 dBm
Offset
* Att
40 dB
* RBW
10 kHz
* VBW
30 kHz
10 dB
Middle channel
Marker 1 [T1 ]
25.20 dBm
SWT 10 ms
Span 1 MHz
Ref
1.909824000 GHz
40
OBW250.000000000 kHz
40 dBm
Offset
* Att
40 dB
* RBW
10 kHz
* VBW
30 kHz
11.13 dBm
ndB [T1]
MAXH
9.21 dBm LVL
MAXH
-1.66 dBm
1.909642000 GHz
20
Temp 2 [T1 ndB]
LVL
-1.92 dBm
1.909928000 GHz
T1
Temp 1 [T1 ndB]
30
1 PK
Temp 2 [T1 OBW]
20
26.00 dB
BW 326.000000000 kHz
1.909678000 GHz
1 PK
24.73 dBm
1.909790000 GHz
10 dB
Temp 1 [T1 OBW]
30
Marker 1 [T1 ]
SWT 10 ms
T2
10
10
1.909968000 GHz
T1
T2
-10
-10
3DB
3DB
-20
-20
-30
-30
-40
-40
-50
-50
-60
-60
Center 1.9098 GHz
Date: 29.DEC.2018
100 kHz/
17:49:44
Span 1 MHz
Center 1.9098 GHz
Date: 29.DEC.2018
Highest channel
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
100 kHz/
Span 1 MHz
17:49:54
Highest channel
Project No.: CCISE1812134
Page 18 of 55
Report No: CCISE181213401
UMTS 850 12.2k RMC
99% Occupy bandwidth
Ref
30
30 dBm
Offset
* Att
30 dB
* RBW
100 kHz
* VBW
300 kHz
18.21 dBm
SWT 2.5 ms
10 dB
26dB Emission Bandwidth
Marker 1 [T1 ]
825.540000000 MHz
OBW
Ref
4.160000000 MHz
30
30 dBm
Offset
* Att
30 dB
* RBW
100 kHz
* VBW
300 kHz
10 dB
9.00 dBm
18.21 dBm
825.520000000 MHz
ndB [T1]
Temp 1 [T1 OBW]
20
Marker 1 [T1 ]
SWT 2.5 ms
BW
20
1 PK
MAXH
10
-9.29 dBm
Temp 2 [T1 OBW]
T2
8.48 dBm LVL
828.480000000 MHz
T1
26.00 dB
4.720000000 MHz
Temp 1 [T1 ndB]
824.320000000 MHz
1 PK
MAXH
824.040000000 MHz
10
Temp 2 [T1 ndB]
LVL
-8.81 dBm
-10
-10
828.760000000 MHz
T2
T1
-20
-20
3DB
3DB
-30
-30
-40
-40
-50
-50
-60
-60
-70
-70
Center 826.4 MHz
Date: 29.DEC.2018
1 MHz/
Span 10 MHz
Center 826.4 MHz
17:18:54
Date: 29.DEC.2018
1 MHz/
17:21:04
Lowest channel
Ref
30
30 dBm
Offset
* Att
30 dB
* RBW
100 kHz
* VBW
300 kHz
10 dB
Lowest channel
Marker 1 [T1 ]
17.26 dBm
SWT 2.5 ms
835.680000000 MHz
OBW
Span 10 MHz
Ref
4.160000000 MHz
30
30 dBm
Offset
* Att
30 dB
* RBW
100 kHz
* VBW
300 kHz
10 dB
8.35 dBm
17.19 dBm
837.280000000 MHz
ndB [T1]
Temp 1 [T1 OBW]
20
Marker 1 [T1 ]
SWT 2.5 ms
BW
20
834.520000000 MHz
1 PK
MAXH
10
-10.39 dBm
Temp 2 [T1 OBW]
T2
8.40 dBm LVL
838.680000000 MHz
T1
26.00 dB
4.720000000 MHz
Temp 1 [T1 ndB]
1 PK
MAXH
834.240000000 MHz
10
Temp 2 [T1 ndB]
LVL
-10.77 dBm
-10
-10
838.960000000 MHz
T1
-20
T2
-20
3DB
3DB
-30
-30
-40
-40
-50
-50
-60
-60
-70
-70
Center 836.6 MHz
Date: 29.DEC.2018
1 MHz/
Span 10 MHz
Center 836.6 MHz
17:21:48
Date: 29.DEC.2018
1 MHz/
17:21:38
Middle channel
Ref
30
30 dBm
Offset
* Att
30 dB
* RBW
100 kHz
* VBW
300 kHz
10 dB
Middle channel
Marker 1 [T1 ]
17.21 dBm
SWT 2.5 ms
845.720000000 MHz
OBW
Ref
4.180000000 MHz
30
30 dBm
Offset
* Att
30 dB
* RBW
100 kHz
* VBW
300 kHz
8.65 dBm
Marker 1 [T1 ]
17.20 dBm
SWT 2.5 ms
10 dB
845.780000000 MHz
ndB [T1]
Temp 1 [T1 OBW]
20
Span 10 MHz
BW
20
844.480000000 MHz
1 PK
MAXH
10
Temp 2 [T1 OBW]
T2
8.45 dBm
T1
26.00 dB
4.720000000 MHz
Temp 1 [T1 ndB]
-9.18 dBm
1 PK
MAXH
LVL
844.240000000 MHz
10
Temp 2 [T1 ndB]
848.660000000 MHz
LVL
-10.14 dBm
-10
-10
848.960000000 MHz
T1
-20
T2
-20
3DB
3DB
-30
-30
-40
-40
-50
-50
-60
-60
-70
-70
Center 846.6 MHz
Date: 29.DEC.2018
1 MHz/
17:22:00
Span 10 MHz
Center 846.6 MHz
Date: 29.DEC.2018
Highest channel
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
1 MHz/
Span 10 MHz
17:22:11
Highest channel
Project No.: CCISE1812134
Page 19 of 55
Report No: CCISE181213401
UMTS 1900 12.2k RMC
99% Occupy bandwidth
Ref
30
30 dBm
Offset
* Att
30 dB
* RBW
100 kHz
* VBW
300 kHz
17.18 dBm
SWT 2.5 ms
10 dB
26dB Emission Bandwidth
Marker 1 [T1 ]
OBW
1.853000000 GHz
Ref
4.160000000 MHz
30
30 dBm
Offset
* Att
30 dB
* RBW
100 kHz
* VBW
300 kHz
10 dB
8.41 dBm
16.91 dBm
1.853080000 GHz
ndB [T1]
Temp 1 [T1 OBW]
20
Marker 1 [T1 ]
SWT 2.5 ms
BW
1 PK
MAXH
10
-9.63 dBm
Temp 2 [T1 OBW]
T2
8.19 dBm LVL
1.854480000 GHz
T1
26.00 dB
4.700000000 MHz
Temp 1 [T1 ndB]
20
1.850320000 GHz
1 PK
MAXH
1.850040000 GHz
10
Temp 2 [T1 ndB]
LVL
-9.25 dBm
-10
-10
1.854740000 GHz
T2
T1
-20
-20
3DB
3DB
-30
-30
-40
-40
-50
-50
-60
-60
-70
-70
Center 1.8524 GHz
Date: 29.DEC.2018
1 MHz/
Span 10 MHz
Center 1.8524 GHz
17:13:16
Date: 29.DEC.2018
1 MHz/
17:13:26
Lowest channel
Ref
30
30 dBm
Offset
* Att
30 dB
* RBW
100 kHz
* VBW
300 kHz
10 dB
Lowest channel
Marker 1 [T1 ]
16.50 dBm
SWT 2.5 ms
OBW
Span 10 MHz
1.880360000 GHz
Ref
4.160000000 MHz
30
30 dBm
Offset
* Att
30 dB
* RBW
100 kHz
* VBW
300 kHz
10 dB
8.21 dBm
17.57 dBm
1.880580000 GHz
ndB [T1]
Temp 1 [T1 OBW]
20
Marker 1 [T1 ]
SWT 2.5 ms
BW
20
1.877920000 GHz
1 PK
MAXH
-9.23 dBm
Temp 2 [T1 OBW]
T2
8.56 dBm LVL
1.882080000 GHz
T1
10
26.00 dB
4.700000000 MHz
Temp 1 [T1 ndB]
1 PK
MAXH
1.877640000 GHz
10
Temp 2 [T1 ndB]
LVL
-7.38 dBm
-10
-10
1.882340000 GHz
T2
T1
-20
-20
3DB
3DB
-30
-30
-40
-40
-50
-50
-60
-60
-70
-70
Center 1.88 GHz
Date: 29.DEC.2018
1 MHz/
Span 10 MHz
Center 1.88 GHz
17:13:04
Date: 29.DEC.2018
1 MHz/
17:12:55
Middle channel
Ref
30
30 dBm
Offset
* Att
30 dB
* RBW
100 kHz
* VBW
300 kHz
10 dB
Middle channel
Marker 1 [T1 ]
15.46 dBm
SWT 2.5 ms
OBW
1.907060000 GHz
Ref
4.180000000 MHz
30
30 dBm
Offset
* Att
30 dB
* RBW
100 kHz
* VBW
300 kHz
7.37 dBm
10 dB
Temp 2 [T1 OBW]
T2
7.55 dBm
T1
10
17.70 dBm
1.906720000 GHz
ndB [T1]
BW
20
26.00 dB
4.680000000 MHz
Temp 1 [T1 ndB]
1.905500000 GHz
1 PK
MAXH
Marker 1 [T1 ]
SWT 2.5 ms
Temp 1 [T1 OBW]
20
Span 10 MHz
-8.35 dBm
1 PK
MAXH
LVL
1.905260000 GHz
10
Temp 2 [T1 ndB]
1.909680000 GHz
LVL
-8.81 dBm
-10
-10
1.909940000 GHz
T1
-20
T2
-20
3DB
3DB
-30
-30
-40
-40
-50
-50
-60
-60
-70
-70
Center 1.9076 GHz
Date: 29.DEC.2018
1 MHz/
17:12:09
Span 10 MHz
Center 1.9076 GHz
Date: 29.DEC.2018
Highest channel
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
1 MHz/
Span 10 MHz
17:12:30
Highest channel
Project No.: CCISE1812134
Page 20 of 55
Report No: CCISE181213401
UMTS 1700 12.2k RMC
99% Occupy bandwidth
Ref
30
30 dBm
Offset
* Att
30 dB
* RBW
100 kHz
* VBW
300 kHz
17.47 dBm
SWT 2.5 ms
10 dB
26dB Emission Bandwidth
Marker 1 [T1 ]
OBW
1.713120000 GHz
Ref
4.180000000 MHz
30
30 dBm
Offset
* Att
30 dB
* RBW
100 kHz
* VBW
300 kHz
10 dB
7.68 dBm
17.10 dBm
1.712080000 GHz
ndB [T1]
Temp 1 [T1 OBW]
20
Marker 1 [T1 ]
SWT 2.5 ms
BW
1 PK
MAXH
T1
T2
-7.86 dBm
1 PK
Temp 2 [T1 OBW]
10
26.00 dB
4.740000000 MHz
Temp 1 [T1 ndB]
20
1.710300000 GHz
6.46 dBm LVL
MAXH
1.710040000 GHz
10
Temp 2 [T1 ndB]
1.714480000 GHz
LVL
-10.25 dBm
-10
-10
1.714780000 GHz
T1
T2
-20
-20
3DB
3DB
-30
-30
-40
-40
-50
-50
-60
-60
-70
-70
Center 1.7124 GHz
Date: 29.DEC.2018
1 MHz/
Span 10 MHz
Center 1.7124 GHz
17:22:57
Date: 29.DEC.2018
1 MHz/
17:23:06
Lowest channel
Ref
30
30 dBm
Offset
* Att
30 dB
* RBW
100 kHz
* VBW
300 kHz
10 dB
Lowest channel
Marker 1 [T1 ]
16.50 dBm
SWT 2.5 ms
OBW
Span 10 MHz
1.733500000 GHz
Ref
4.180000000 MHz
30
30 dBm
Offset
* Att
30 dB
* RBW
100 kHz
* VBW
300 kHz
10 dB
8.29 dBm
17.36 dBm
1.731780000 GHz
ndB [T1]
Temp 1 [T1 OBW]
20
Marker 1 [T1 ]
SWT 2.5 ms
BW
20
1.730500000 GHz
1 PK
MAXH
10
-8.31 dBm
Temp 2 [T1 OBW]
T2
8.78 dBm LVL
1.734680000 GHz
T1
26.00 dB
4.720000000 MHz
Temp 1 [T1 ndB]
1 PK
MAXH
1.730240000 GHz
10
Temp 2 [T1 ndB]
LVL
-8.38 dBm
-10
-10
1.734960000 GHz
T1
-20
T2
-20
3DB
3DB
-30
-30
-40
-40
-50
-50
-60
-60
-70
-70
Center 1.7326 GHz
Date: 29.DEC.2018
1 MHz/
Span 10 MHz
Center 1.7326 GHz
17:22:40
Date: 29.DEC.2018
1 MHz/
17:22:31
Middle channel
Ref
30
30 dBm
Offset
* Att
30 dB
* RBW
100 kHz
* VBW
300 kHz
10 dB
Middle channel
Marker 1 [T1 ]
17.26 dBm
SWT 2.5 ms
OBW
1.753320000 GHz
Ref
4.180000000 MHz
30
30 dBm
Offset
* Att
30 dB
* RBW
100 kHz
* VBW
300 kHz
8.26 dBm
Marker 1 [T1 ]
17.24 dBm
SWT 2.5 ms
10 dB
1.751720000 GHz
ndB [T1]
Temp 1 [T1 OBW]
20
Span 10 MHz
BW
20
1.750500000 GHz
1 PK
MAXH
Temp 2 [T1 OBW]
T2
8.18 dBm
T1
10
26.00 dB
4.740000000 MHz
Temp 1 [T1 ndB]
-9.39 dBm
1 PK
MAXH
LVL
1.750220000 GHz
10
Temp 2 [T1 ndB]
1.754680000 GHz
LVL
-8.01 dBm
-10
-10
1.754960000 GHz
T2
T1
-20
-20
3DB
3DB
-30
-30
-40
-40
-50
-50
-60
-60
-70
-70
Center 1.7526 GHz
Date: 29.DEC.2018
1 MHz/
17:23:28
Span 10 MHz
Center 1.7526 GHz
Date: 29.DEC.2018
Highest channel
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
1 MHz/
Span 10 MHz
17:23:21
Highest channel
Project No.: CCISE1812134
Page 21 of 55
Report No: CCISE181213401
6.4 Modulation Characteristic
According to FCC § 2.1047(d), Part 22H & 24E & 27L there is no specific requirement for digital modulation,
therefore modulation characteristic is not presented.
6.5 Out of band emission at antenna terminals
Test Requirement:
FCC part 22.917(a), FCC part 24.238(a), FCC Part 27.53 (h)
Test Method:
ANSI/TIA-603-D 2010
Limit:
-13dBm
Test setup:
Test Procedure:
The RF output of the transceiver was connected to a spectrum
analyzer through appropriate attenuation.
The resolution bandwidth of the spectrum analyzer was set at 100
kHz when below 1GHz, 1MHz when above 1 GHz; sufficient scans
were taken to show the out of band Emissions if any up to 10th
harmonic.
For the out of band: Set the RBW=100 kHz, VBW=300 kHz when
below 1 GHz, RBW =1 MHz, VBW=3 MHz when above 1 GHz,
Start=30MHz, Stop= 10th harmonic.
Band Edge Requirements: In the 1 MHz bands immediately outside
and adjacent to the frequency block, a resolution bandwidth of at
least 1 percent of the emission bandwidth of the fundamental
emission of the transmitter may be employed to measure the out of
band Emissions.
Test Instruments:
Refer to section 5.8 for details
Test mode:
Refer to section 5.3 for details
Test results:
Passed
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
Project No.: CCISE1812134
Page 22 of 55
Report No: CCISE181213401
Test plots as follows (Spurious emission):
GSM 850
Lowest Channel
Ref
40
40 dBm
Offset
* Att
40 dB
* RBW
100 kHz
* VBW
300 kHz
SWT 100 ms
Marker 1 [T1 ]
-28.71 dBm
501.958000000 MHz
Ref
10 dB
40
30
Offset
* Att
40 dB
* RBW
1 MHz
* VBW
3 MHz
SWT 160 ms
Marker 1 [T1 ]
-23.44 dBm
7.320000000 GHz
10 dB
30
1 PK
MAXH
40 dBm
1 PK
MAXH
20
LVL
20
10
10
-10
LVL
-10
D1 -13 dBm
D1 -13 dBm
3DB
3DB
-20
-20
-30
-30
-40
-40
-50
-50
-60
-60
Start 30 MHz
Date: 29.DEC.2018
97 MHz/
Stop 1 GHz
Start 1 GHz
16:59:46
800 MHz/
Date: 29.DEC.2018
Stop 9 GHz
17:03:58
Middle channel
Ref
40
40 dBm
Offset
* Att
40 dB
* RBW
100 kHz
* VBW
300 kHz
SWT 100 ms
Marker 1 [T1 ]
-28.19 dBm
66.860000000 MHz
Ref
10 dB
40
30
Offset
* Att
40 dB
* RBW
1 MHz
* VBW
3 MHz
SWT 160 ms
Marker 1 [T1 ]
-23.35 dBm
8.680000000 GHz
10 dB
30
1 PK
1 PK
MAXH
MAXH
20
40 dBm
LVL
20
10
10
-10
LVL
-10
D1 -13 dBm
D1 -13 dBm
3DB
3DB
-20
-20
-30
-30
-40
-40
-50
-50
-60
-60
Start 30 MHz
Date: 29.DEC.2018
97 MHz/
Stop 1 GHz
Start 1 GHz
17:01:19
800 MHz/
Date: 29.DEC.2018
Stop 9 GHz
17:03:48
Highest Channel
Ref
40
40 dBm
Offset
* Att
40 dB
* RBW
100 kHz
* VBW
300 kHz
SWT 100 ms
Marker 1 [T1 ]
-28.46 dBm
450.980000000 MHz
Ref
10 dB
40
30
1 PK
MAXH
MAXH
LVL
40 dB
* RBW
1 MHz
* VBW
3 MHz
SWT 160 ms
Marker 1 [T1 ]
-22.80 dBm
5.640000000 GHz
10 dB
20
10
10
-10
Offset
* Att
30
1 PK
20
40 dBm
LVL
-10
D1 -13 dBm
D1 -13 dBm
3DB
-20
3DB
-20
-30
-30
-40
-40
-50
-50
-60
-60
Start 30 MHz
Date: 29.DEC.2018
97 MHz/
17:01:45
Stop 1 GHz
Start 1 GHz
Date: 29.DEC.2018
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
800 MHz/
Stop 9 GHz
17:03:41
Project No.: CCISE1812134
Page 23 of 55
Report No: CCISE181213401
PCS 1900
Lowest Channel
Ref
40
40 dBm
Offset
* Att
40 dB
* RBW
100 kHz
* VBW
300 kHz
SWT 100 ms
Marker 1 [T1 ]
-28.00 dBm
66.860000000 MHz
Ref
10 dB
30
30
Offset
* Att
30 dB
* RBW
1 MHz
* VBW
3 MHz
Marker 1 [T1 ]
-20.55 dBm
SWT 380 ms
13.654000000 GHz
10 dB
20
1 PK
MAXH
30 dBm
1 PK
MAXH
20
LVL
10
10
-10
LVL
D1 -13 dBm
-10
-20
D1 -13 dBm
3DB
3DB
-20
-30
-30
-40
-40
-50
-50
-60
-60
-70
Start 30 MHz
Date: 29.DEC.2018
97 MHz/
Stop 1 GHz
Start 1 GHz
17:44:27
1.9 GHz/
Date: 29.DEC.2018
Stop 20 GHz
17:42:19
Middle Channel
Ref
40
40 dBm
Offset
* Att
40 dB
* RBW
100 kHz
* VBW
300 kHz
SWT 100 ms
Marker 1 [T1 ]
-28.63 dBm
88.200000000 MHz
Ref
10 dB
30
30
Offset
* Att
30 dB
* RBW
1 MHz
* VBW
3 MHz
Marker 1 [T1 ]
-20.87 dBm
SWT 380 ms
13.654000000 GHz
10 dB
20
1 PK
1 PK
MAXH
MAXH
20
30 dBm
LVL
10
10
-10
LVL
D1 -13 dBm
-10
-20
D1 -13 dBm
3DB
3DB
-20
-30
-30
-40
-40
-50
-50
-60
-60
-70
Start 30 MHz
Date: 29.DEC.2018
97 MHz/
Stop 1 GHz
Start 1 GHz
17:44:15
1.9 GHz/
Date: 29.DEC.2018
Stop 20 GHz
17:39:58
Highest Channel
Ref
40
40 dBm
Offset
* Att
40 dB
* RBW
100 kHz
* VBW
300 kHz
SWT 100 ms
Marker 1 [T1 ]
-28.09 dBm
804.060000000 MHz
Ref
10 dB
30
30
1 PK
MAXH
30 dBm
Offset
* Att
30 dB
* RBW
1 MHz
* VBW
3 MHz
Marker 1 [T1 ]
-20.35 dBm
SWT 380 ms
13.616000000 GHz
10 dB
20
1 PK
MAXH
20
LVL
10
10
-10
-10
-20
LVL
D1 -13 dBm
D1 -13 dBm
3DB
-20
3DB
-30
-30
-40
-40
-50
-50
-60
-60
-70
Start 30 MHz
Date: 29.DEC.2018
97 MHz/
17:44:08
Stop 1 GHz
Start 1 GHz
Date: 29.DEC.2018
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
1.9 GHz/
Stop 20 GHz
17:43:02
Project No.: CCISE1812134
Page 24 of 55
Report No: CCISE181213401
UMTS 850 12.2k RMC
Lowest Channel
Ref
30
30 dBm
Offset
* Att
30 dB
* RBW
100 kHz
* VBW
300 kHz
SWT 100 ms
Marker 1 [T1 ]
-38.89 dBm
788.540000000 MHz
Ref
10 dB
30
20
Offset
* Att
30 dB
* RBW
1 MHz
* VBW
3 MHz
SWT 160 ms
Marker 1 [T1 ]
-33.30 dBm
8.280000000 GHz
10 dB
20
1 PK
MAXH
30 dBm
1 PK
MAXH
10
LVL
10
LVL
-10
-10
D1 -13 dBm
D1 -13 dBm
-20
-20
3DB
3DB
-30
-30
-40
-40
-50
-50
-60
-60
-70
-70
Start 30 MHz
Date: 29.DEC.2018
97 MHz/
Stop 1 GHz
Start 1 GHz
17:16:09
800 MHz/
Date: 29.DEC.2018
Stop 9 GHz
17:17:08
Middle Channel
Ref
30
30 dBm
Offset
* Att
30 dB
* RBW
100 kHz
* VBW
300 kHz
SWT 100 ms
Marker 1 [T1 ]
-38.93 dBm
877.780000000 MHz
Ref
10 dB
30
20
Offset
* Att
30 dB
* RBW
1 MHz
* VBW
3 MHz
SWT 160 ms
Marker 1 [T1 ]
-32.80 dBm
3.560000000 GHz
10 dB
20
1 PK
1 PK
MAXH
MAXH
10
30 dBm
LVL
10
LVL
-10
-10
D1 -13 dBm
D1 -13 dBm
-20
-20
3DB
3DB
-30
-30
-40
-40
-50
-50
-60
-60
-70
-70
Start 30 MHz
Date: 29.DEC.2018
97 MHz/
Stop 1 GHz
Start 1 GHz
17:15:55
800 MHz/
Date: 29.DEC.2018
Stop 9 GHz
17:16:57
Highest Channel
Ref
30
30 dBm
Offset
* Att
30 dB
* RBW
100 kHz
* VBW
300 kHz
SWT 100 ms
Marker 1 [T1 ]
-38.35 dBm
598.420000000 MHz
Ref
10 dB
30
20
1 PK
MAXH
30 dBm
Offset
* Att
30 dB
* RBW
1 MHz
* VBW
3 MHz
SWT 160 ms
Marker 1 [T1 ]
-32.73 dBm
3.016000000 GHz
10 dB
20
1 PK
MAXH
10
LVL
10
LVL
-10
-10
D1 -13 dBm
D1 -13 dBm
-20
-20
3DB
-30
3DB
-30
-40
-40
-50
-50
-60
-60
-70
-70
Start 30 MHz
Date: 29.DEC.2018
97 MHz/
17:16:31
Stop 1 GHz
Start 1 GHz
Date: 29.DEC.2018
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
800 MHz/
Stop 9 GHz
17:16:49
Project No.: CCISE1812134
Page 25 of 55
Report No: CCISE181213401
UMTS 1900 12.2k RMC
Lowest Channel
Ref
30
30 dBm
Offset
* Att
30 dB
* RBW
100 kHz
* VBW
300 kHz
SWT 100 ms
Marker 1 [T1 ]
-38.36 dBm
441.280000000 MHz
Ref
10 dB
30
20
Offset
* Att
30 dB
* RBW
1 MHz
* VBW
3 MHz
Marker 1 [T1 ]
-19.74 dBm
SWT 380 ms
13.692000000 GHz
10 dB
20
1 PK
MAXH
30 dBm
1 PK
MAXH
10
LVL
10
LVL
-10
-10
D1 -13 dBm
D1 -13 dBm
-20
-20
3DB
3DB
-30
-30
-40
-40
-50
-50
-60
-60
-70
-70
Start 30 MHz
Date: 29.DEC.2018
97 MHz/
Stop 1 GHz
Start 1 GHz
17:10:06
1.9 GHz/
Date: 29.DEC.2018
Stop 20 GHz
17:06:46
Middle Channel
Ref
30
30 dBm
Offset
* Att
30 dB
* RBW
100 kHz
* VBW
300 kHz
SWT 100 ms
Marker 1 [T1 ]
-38.79 dBm
369.500000000 MHz
Ref
10 dB
30
20
Offset
* Att
30 dB
* RBW
1 MHz
* VBW
3 MHz
Marker 1 [T1 ]
-19.97 dBm
SWT 380 ms
13.692000000 GHz
10 dB
20
1 PK
1 PK
MAXH
MAXH
10
30 dBm
LVL
10
LVL
-10
-10
D1 -13 dBm
D1 -13 dBm
-20
-20
3DB
3DB
-30
-30
-40
-40
-50
-50
-60
-60
-70
-70
Start 30 MHz
Date: 29.DEC.2018
97 MHz/
Stop 1 GHz
Start 1 GHz
17:09:57
1.9 GHz/
Date: 29.DEC.2018
Stop 20 GHz
17:07:05
Highest Channel
Ref
30
30 dBm
Offset
* Att
30 dB
* RBW
100 kHz
* VBW
300 kHz
SWT 100 ms
Marker 1 [T1 ]
-38.25 dBm
264.740000000 MHz
Ref
10 dB
30
20
1 PK
MAXH
30 dBm
Offset
* Att
30 dB
* RBW
1 MHz
* VBW
3 MHz
Marker 1 [T1 ]
-20.70 dBm
SWT 380 ms
13.616000000 GHz
10 dB
20
1 PK
MAXH
10
LVL
10
LVL
-10
-10
D1 -13 dBm
D1 -13 dBm
-20
-20
3DB
-30
3DB
-30
-40
-40
-50
-50
-60
-60
-70
-70
Start 30 MHz
Date: 29.DEC.2018
97 MHz/
17:09:48
Stop 1 GHz
Start 1 GHz
Date: 29.DEC.2018
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
1.9 GHz/
Stop 20 GHz
17:07:22
Project No.: CCISE1812134
Page 26 of 55
Report No: CCISE181213401
UMTS 1700 12.2k RMC
Lowest Channel
Ref
30
30 dBm
Offset
* Att
30 dB
* RBW
100 kHz
* VBW
300 kHz
Marker 1 [T1 ]
-38.14 dBm
SWT 100 ms
724.520000000 MHz
Ref
10 dB
30
20
1 PK
MAXH
30 dBm
Offset
* Att
30 dB
* RBW
1 MHz
* VBW
3 MHz
Marker 1 [T1 ]
-20.64 dBm
SWT 380 ms
13.692000000 GHz
10 dB
20
1 PK
MAXH
10
LVL
10
LVL
-10
-10
D1 -13 dBm
D1 -13 dBm
-20
-20
3DB
3DB
-30
-30
-40
-40
-50
-50
-60
-60
-70
-70
Start 30 MHz
Date: 29.DEC.2018
97 MHz/
Stop 1 GHz
Start 1 GHz
17:24:28
1.9 GHz/
Date: 29.DEC.2018
Stop 20 GHz
17:25:16
Middle Channel
Ref
30
30 dBm
Offset
* Att
30 dB
* RBW
100 kHz
* VBW
300 kHz
SWT 100 ms
Marker 1 [T1 ]
-38.33 dBm
472.320000000 MHz
Ref
10 dB
30
20
Offset
* Att
30 dB
* RBW
1 MHz
* VBW
3 MHz
Marker 1 [T1 ]
-20.75 dBm
SWT 380 ms
14.718000000 GHz
10 dB
20
1 PK
1 PK
MAXH
MAXH
10
30 dBm
LVL
10
LVL
-10
-10
D1 -13 dBm
D1 -13 dBm
-20
-20
3DB
3DB
-30
-30
-40
-40
-50
-50
-60
-60
-70
-70
Start 30 MHz
Date: 29.DEC.2018
97 MHz/
Stop 1 GHz
Start 1 GHz
17:24:35
1.9 GHz/
Date: 29.DEC.2018
Stop 20 GHz
17:25:45
Highest Channel
Ref
30
30 dBm
Offset
* Att
30 dB
* RBW
100 kHz
* VBW
300 kHz
SWT 100 ms
Marker 1 [T1 ]
-38.26 dBm
941.800000000 MHz
Ref
10 dB
30
20
1 PK
MAXH
30 dBm
Offset
* Att
30 dB
* RBW
1 MHz
* VBW
3 MHz
Marker 1 [T1 ]
-20.48 dBm
SWT 380 ms
13.654000000 GHz
10 dB
20
1 PK
MAXH
10
LVL
10
LVL
-10
-10
D1 -13 dBm
D1 -13 dBm
-20
-20
3DB
-30
3DB
-30
-40
-40
-50
-50
-60
-60
-70
-70
Start 30 MHz
Date: 29.DEC.2018
97 MHz/
17:24:43
Stop 1 GHz
Start 1 GHz
Date: 29.DEC.2018
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
1.9 GHz/
Stop 20 GHz
17:26:13
Project No.: CCISE1812134
Page 27 of 55
Report No: CCISE181213401
Band edge emission:
GSM850
Ref
40
40 dBm
Offset
* Att
40 dB
* RBW
3 kHz
* VBW
10 kHz
Marker 1 [T1 ]
-15.48 dBm
* SWT
200 ms
823.998000000 MHz
Ref
10 dB
40
30
1 RM *
MAXH
40 dBm
Offset
* Att
40 dB
* RBW
3 kHz
* VBW
10 kHz
-13.65 dBm
* SWT
200 ms
Marker 1 [T1 ]
849.022000000 MHz
10 dB
30
1 RM *
MAXH
20
LVL
20
10
10
-10
LVL
-10
D1 -13 dBm
D1 -13 dBm
3DB
3DB
-20
-20
-30
-30
-40
-40
-50
-50
-60
-60
Center 824 MHz
Date: 29.DEC.2018
100 kHz/
Span 1 MHz
Center 849 MHz
16:59:14
Date: 29.DEC.2018
100 kHz/
Span 1 MHz
16:58:54
Lowest channel
Highest channel
PCS1900
Ref
40
40 dBm
Offset
* Att
40 dB
* RBW
3 kHz
* VBW
10 kHz
Marker 1 [T1 ]
-16.54 dBm
SWT 115 ms
1.849978000 GHz
Ref
10 dB
40
30
1 RM *
MAXH
MAXH
LVL
* RBW
3 kHz
* VBW
10 kHz
-16.47 dBm
SWT 115 ms
1.910020000 GHz
40 dB
Marker 1 [T1 ]
10 dB
20
10
10
-10
Offset
* Att
30
1 RM *
20
40 dBm
LVL
-10
D1 -13 dBm
D1 -13 dBm
3DB
3DB
-20
-20
-30
-30
-40
-40
-50
-50
-60
-60
Center 1.85 GHz
Date: 29.DEC.2018
100 kHz/
17:48:18
Span 1 MHz
Center 1.91 GHz
Date: 29.DEC.2018
Lowest channel
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
100 kHz/
Span 1 MHz
17:46:19
Highest channel
Project No.: CCISE1812134
Page 28 of 55
Report No: CCISE181213401
UMTS 850 RMC 12.2kbps
Ref
30
30 dBm
Offset
* Att
30 dB
* RBW
100 kHz
* VBW
300 kHz
Marker 1 [T1 ]
-15.74 dBm
SWT 2.5 ms
824.000000000 MHz
Ref
10 dB
30
20
1 RM *
MAXH
30 dBm
Offset
* Att
30 dB
* RBW
100 kHz
* VBW
300 kHz
SWT 2.5 ms
Marker 1 [T1 ]
-16.45 dBm
849.000000000 MHz
10 dB
20
1 RM *
MAXH
10
LVL
10
LVL
-10
-10
D1 -13 dBm
D1 -13 dBm
-20
-20
3DB
3DB
-30
-30
-40
-40
-50
-50
-60
-60
-70
-70
Center 824 MHz
Date: 29.DEC.2018
1 MHz/
Span 10 MHz
Center 849 MHz
17:18:06
Date: 29.DEC.2018
1 MHz/
Span 10 MHz
17:17:50
Lowest channel
Highest channel
UMTS 1900 RMC 12.2kbps
Ref
30
30 dBm
Offset
* Att
30 dB
* RBW
100 kHz
* VBW
300 kHz
Marker 1 [T1 ]
SWT 2.5 ms
-18.10 dBm
1.850000000 GHz
Ref
10 dB
30
20
1 RM *
MAXH
30 dBm
Offset
* Att
30 dB
* RBW
100 kHz
* VBW
300 kHz
Marker 1 [T1 ]
SWT 2.5 ms
-18.82 dBm
1.910000000 GHz
10 dB
20
1 RM *
MAXH
10
LVL
10
LVL
-10
-10
D1 -13 dBm
D1 -13 dBm
-20
-20
3DB
3DB
-30
-30
-40
-40
-50
-50
-60
-60
-70
-70
Center 1.85 GHz
Date: 29.DEC.2018
1 MHz/
17:11:35
Span 10 MHz
Center 1.91 GHz
Date: 29.DEC.2018
Lowest channel
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
1 MHz/
Span 10 MHz
17:11:53
Highest channel
Project No.: CCISE1812134
Page 29 of 55
Report No: CCISE181213401
UMTS 1700 RMC 12.2kbps
Ref
30
30 dBm
Offset
* Att
30 dB
* RBW
100 kHz
* VBW
300 kHz
Marker 1 [T1 ]
SWT 2.5 ms
-13.79 dBm
1.710000000 GHz
Ref
10 dB
30
20
1 RM *
MAXH
30 dBm
Offset
* Att
30 dB
* RBW
100 kHz
* VBW
300 kHz
Marker 1 [T1 ]
SWT 2.5 ms
-13.51 dBm
1.755000000 GHz
10 dB
20
1 RM *
MAXH
10
LVL
10
LVL
-10
D1 -13 dBm
-10
D1 -13 dBm
-20
-20
3DB
3DB
-30
-30
-40
-40
-50
-50
-60
-60
-70
-70
Center 1.71 GHz
Date: 29.DEC.2018
AC
1 MHz/
Span 10 MHz
Center 1.755 GHz
Date: 22.FEB.2019
17:24:12
Lowest channel
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
1 MHz/
Span 10 MHz
09:20:05
Highest channel
Project No.: CCISE1812134
Page 30 of 55
Report No: CCISE181213401
6.6 Field strength of spurious radiation measurement
Test Requirement:
FCC part 22.917(a), FCC part 24.238(a), FCC part 27.53(h)
Test Method:
ANSI/TIA-603-D 2010
Limit:
Test setup:
-13dBm
Below 1GHz
Above 1GHz
Test Procedure:
1.
2.
3.
4.
The EUT was placed on an non-conductive turntable using a nonconductive support. The radiated emission at the fundamental
frequency was measured at 3 m with a test antenna and EMI
spectrum analyzer.
During the tests, the antenna height and the EUT azimuth were
varied in order to identify the maximum level of emissions from the
EUT. This maximization process was repeated with the EUT
positioned in each of its three orthogonal orientations.
The frequency range up to tenth harmonic was investigated for each
of three fundamental frequency (low, middle and high channels).
Once spurious emission was identified, the power of the emission
was determined using the substitution method.
The spurious emissions attenuation was calculated as the difference
between radiated power at the fundamental frequency and the
spurious emissions frequency.
ERP / EIRP = S.G. output (dBm) + Antenna Gain(dB/dBi) –
Cable Loss (dB)
Test Instruments:
Refer to section 5.8 for details
Test mode:
Refer to section 5.3 for details.
Test results:
Passed
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
Project No.: CCISE1812134
Page 31 of 55
Report No: CCISE181213401
Measurement Data (worst case):
GSM850
Lowest channel
Frequency (MHz)
Spurious Emission
Polarization
Level (dBm)
1648.40
Vertical
-46.28
2472.60
-46.98
3296.80
-52.71
1648.40
Horizontal
-50.16
2472.60
-49.57
3296.80
-52.36
Limit (dBm)
Result
-13.00
Pass
-13.00
Pass
Limit (dBm)
Result
-13.00
Pass
-13.00
Pass
Limit (dBm)
Result
-13.00
Pass
-13.00
Pass
Middle channel
Frequency (MHz)
Spurious Emission
Polarization
Level (dBm)
1673.20
Vertical
-46.82
2509.80
-46.71
3346.40
-52.06
1673.20
Horizontal
-50.45
2509.80
-49.20
3346.40
-52.28
Highest channel
Frequency (MHz)
Spurious Emission
Polarization
Level (dBm)
1697.60
Vertical
-46.98
2546.40
-46.25
3395.20
-52.83
1697.60
Horizontal
-50.12
2546.40
-49.83
3395.20
-52.09
Remark:
1.
The emission levels of below 1 GHz are very lower than the limit and not show in test report.
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
Project No.: CCISE1812134
Page 32 of 55
Report No: CCISE181213401
PCS1900
Lowest channel
Frequency (MHz)
Spurious Emission
Polarization
Level (dBm)
3700.40
Vertical
-46.64
5550.60
-43.62
3700.40
Horizontal
-49.74
5550.60
-41.85
Limit (dBm)
Result
-13.00
Pass
-13.00
Pass
Limit (dBm)
Result
-13.00
Pass
-13.00
Pass
Limit (dBm)
Result
-13.00
Pass
-13.00
Pass
Middle channel
Frequency (MHz)
Spurious Emission
Polarization
Level (dBm)
3760.00
Vertical
-46.79
5640.00
-43.91
3760.00
Horizontal
-49.70
5640.00
-41.43
Highest channel
Frequency (MHz)
Spurious Emission
Polarization
Level (dBm)
3819.60
Vertical
-45.85
5729.40
-44.81
3819.60
Horizontal
-49.81
5729.40
-42.62
Remark:
1.
The emission levels of below 1 GHz are very lower than the limit and not show in test report.
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
Project No.: CCISE1812134
Page 33 of 55
Report No: CCISE181213401
WCDMA BAND V 12.2k RMC
Lowest channel
Frequency (MHz)
Spurious Emission
Polarization
Level (dBm)
1652.80
Vertical
-57.42
2479.20
-49.54
3305.60
-50.74
1652.80
Horizontal
-57.41
2479.20
-50.44
3305.60
-51.12
Limit (dBm)
Result
-13.00
Pass
-13.00
Pass
Limit (dBm)
Result
-13.00
Pass
-13.00
Pass
Limit (dBm)
Result
-13.00
Pass
-13.00
Pass
Middle channel
Frequency (MHz)
Spurious Emission
Polarization
Level (dBm)
1673.20
Vertical
-57.30
2509.80
-49.43
3346.40
-50.95
1673.20
Horizontal
-57.69
2509.80
-50.79
3346.40
-51.28
Highest channel
Frequency (MHz)
Spurious Emission
Polarization
Level (dBm)
1693.20
Vertical
-57.41
2539.80
-49.44
3386.40
-50.92
1693.20
Horizontal
-57.44
2539.80
-50.28
3386.40
-51.92
Remark:
1.
The emission levels of below 1 GHz are very lower than the limit and not show in test report.
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
Project No.: CCISE1812134
Page 34 of 55
Report No: CCISE181213401
WCDMA Band II 12.2k RMC
Lowest channel
Frequency (MHz)
Spurious Emission
Polarization
Level (dBm)
3704.80
Vertical
-46.37
5557.20
-43.61
3704.80
Horizontal
-51.64
5557.20
-43.51
Limit (dBm)
Result
-13.00
Pass
-13.00
Pass
Limit (dBm)
Result
-13.00
Pass
-13.00
Pass
Limit (dBm)
Result
-13.00
Pass
-13.00
Pass
Middle channel
Frequency (MHz)
Spurious Emission
Polarization
Level (dBm)
3760.00
Vertical
-47.64
5640.00
-43.23
3760.00
Horizontal
-51.50
5640.00
-43.83
Highest channel
Frequency (MHz)
Spurious Emission
Polarization
Level (dBm)
3815.20
Vertical
-47.42
5722.80
-43.61
3815.20
Horizontal
-51.12
5722.80
-43.51
Remark:
1.
The emission levels of below 1 GHz are very lower than the limit and not show in test report.
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
Project No.: CCISE1812134
Page 35 of 55
Report No: CCISE181213401
WCDMA Band IV 12.2k RMC
Lowest channel
Frequency (MHz)
Spurious Emission
Polarization
Level (dBm)
3424.40
Vertical
-51.91
5136.60
-45.44
3424.40
Horizontal
-51.37
5136.60
-46.54
Limit (dBm)
Result
-13.00
Pass
-13.00
Pass
Limit (dBm)
Result
-13.00
Pass
-13.00
Pass
Limit (dBm)
Result
-13.00
Pass
-13.00
Pass
Middle channel
Frequency (MHz)
Spurious Emission
Polarization
Level (dBm)
3464.80
Vertical
-51.45
5197.20
-45.91
3464.80
Horizontal
-51.64
5197.20
-46.09
Highest channel
Frequency (MHz)
Spurious Emission
Polarization
Level (dBm)
3505.20
Vertical
-51.67
5257.80
-45.63
3505.20
Horizontal
-51.71
5257.80
-46.12
Remark:
1.
The emission levels of below 1 GHz are very lower than the limit and not show in test report.
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
Project No.: CCISE1812134
Page 36 of 55
Report No: CCISE181213401
6.7 Frequency stability V.S. Temperature measurement
Test Requirement:
FCC Part 22.355, FCC Part 24.235, FCC Part 27.54,
FCC Part 2.1055(a)(1)(b)
Test Method:
ANSI/TIA-6-3-D 2010
Limit:
±2.5 ppm
Test setup:
Test procedure:
1.
2.
3.
4.
5.
6.
The equipment under test was connected to an external DC power
supply and input rated voltage.
RF output was connected to a frequency counter or spectrum
analyzer via feed through attenuators.
The EUT was placed inside the temperature chamber.
Set the spectrum analyzer RBW low enough to obtain the desired
frequency resolution and measure EUT 25℃ operating frequency as
reference frequency.
Turn EUT off and set the chamber temperature to –30℃. After the
temperature stabilized for approximately 30 minutes recorded the
frequency.
Repeat step measure with 10℃ increased per stage until the highest
temperature of +50℃ reached
Test Instruments:
Refer to section 5.8 for details
Test mode:
Refer to section 5.3 for details
Test results:
Passed
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
Project No.: CCISE1812134
Page 37 of 55
Report No: CCISE181213401
Measurement Data (the worst channel):
Reference Frequency: GSM850 Middle channel=190 channel=836.6MHz
Power supplied
(Vdc)
3.7
Temperature (℃)
Frequency error
Hz
ppm
-30
199
0.237868
-20
185
0.221133
-10
123
0.147024
165
0.197227
10
144
0.172125
20
174
0.207985
30
126
0.150610
40
146
0.174516
50
188
0.224719
Limit (ppm)
Result
±2.5
Pass
Reference Frequency: PCS1900 Middle channel=661 channel=1880MHz
Power supplied
(Vdc)
3.7
Temperature (℃)
Frequency error
Hz
ppm
-30
196
0.104255
-20
181
0.096277
-10
174
0.092553
123
0.065426
10
136
0.072340
20
155
0.082447
30
144
0.076596
40
102
0.054255
50
115
0.061170
Limit (ppm)
Result
±2.5
Pass
Note: Only the worst case shown in the report.
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
Project No.: CCISE1812134
Page 38 of 55
Report No: CCISE181213401
Reference Frequency: WCDMA BAND V 12.2k RMC Middle channel=4183 channel=836.6MHz
Power supplied
(Vdc)
3.7
Temperature (℃)
Frequency error
Hz
ppm
-30
197
0.235477
-20
155
0.185274
-10
132
0.157781
165
0.197227
10
144
0.172125
20
180
0.215157
30
177
0.211571
40
123
0.147024
50
105
0.125508
Limit (ppm)
Result
±2.5
Pass
Reference Frequency: WCDMA BAND II 12.2k RMC Middle channel=9400 channel=1880MHz
Power supplied
(Vdc)
3.7
Temperature (℃)
Frequency error
Hz
ppm
-30
194
0.103191
-20
122
0.064894
-10
131
0.069681
165
0.087766
10
102
0.054255
20
144
0.076596
30
170
0.090426
40
151
0.080319
50
130
0.069149
Limit (ppm)
Result
±2.5
Pass
Reference Frequency: UMTS1700 12.2k RMC Middle channel=1413 channel=1732.6MHz
Power supplied
(Vdc)
3.7
Temperature (℃)
Frequency error
Hz
ppm
-30
199
0.114856
-20
123
0.070992
-10
165
0.095233
144
0.083112
10
102
0.058871
20
111
0.064066
30
171
0.098696
40
180
0.103890
50
150
0.086575
Limit (ppm)
Result
±2.5
Pass
Note: Only the worst case shown in the report.
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
Project No.: CCISE1812134
Page 39 of 55
Report No: CCISE181213401
6.8 Frequency stability V.S. Voltage measurement
Test Requirement:
FCC Part 22.355, FCC Part 24.235, FCC Part 27.54,
FCC Part 2.1055(d)(2)
Test Method:
ANSI/TIA-603-D 2010
Limit:
±2.5ppm
Test setup:
Test procedure:
1.
2.
3.
Set chamber temperature to 25℃. Use a variable DC power source
to power the EUT and set the voltage to rated voltage.
Set the spectrum analyzer RBW low enough to obtain the desired
frequency resolution and recorded the frequency.
Reduce the input voltage to specify extreme voltage variation (+/15%) and endpoint, record the maximum frequency change.
Test Instruments:
Refer to section 5.8 for details
Test mode:
Refer to section 5.3 for details
Test results:
Passed
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
Project No.: CCISE1812134
Page 40 of 55
Report No: CCISE181213401
Measurement Data (the worst channel):
Reference Frequency: GSM850 Middle channel=190 channel=836.6MHz
Temperature (℃)
25
Frequency error
Power supplied
(Vdc)
Hz
ppm
4.2
96
0.114750
3.7
85
0.101602
3.5
65
0.077695
Limit (ppm)
Result
±2.5
Pass
Reference Frequency: PCS1900 Middle channel=661 channel=1880MHz
Temperature (℃)
25
Frequency error
Power supplied
(Vdc)
Hz
ppm
4.2
88
0.046809
3.7
90
0.047872
3.5
74
0.039362
Limit (ppm)
Result
±2.5
Pass
Reference Frequency: UMTS 850 12.2k RMC Middle channel=4183 channel=836.6MHz
Temperature (℃)
25
Frequency error
Power supplied
(Vdc)
Hz
ppm
4.2
99
0.118336
3.7
84
0.100406
3.5
65
0.077695
Limit (ppm)
Result
±2.5
Pass
Reference Frequency: UMTS 1900 12.2k RMC Middle channel=9400 channel=1880MHz
Temperature (℃)
25
Frequency error
Power supplied
(Vdc)
Hz
ppm
4.2
80
0.042553
3.7
90
0.047872
3.5
67
0.035638
Limit (ppm)
Result
±2.5
Pass
Reference Frequency: UMTS1700 12.2k RMC Middle channel=1413 channel=1732.6MHz
Temperature (℃)
25
Frequency error
Power supplied
(Vdc)
Hz
ppm
4.2
99
0.057140
3.7
80
0.046173
3.5
74
0.042710
Limit (ppm)
Result
±2.5
Pass
Note: Only the worst case shown in the report.
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
Project No.: CCISE1812134
Page 41 of 55
Download: SKYPLATUNO 3G Smart Phone Test Report HD 271 S1 Sky Phone
Mirror Download [FCC.gov]SKYPLATUNO 3G Smart Phone Test Report HD 271 S1 Sky Phone
Document ID4176777
Application ID35/kMD2+QqJoWTSNAoIeSw==
Document DescriptionTest report
Short Term ConfidentialNo
Permanent ConfidentialNo
SupercedeNo
Document TypeTest Report
Display FormatAdobe Acrobat PDF - pdf
Filesize146.16kB (1826979 bits)
Date Submitted2019-02-22 00:00:00
Date Available2019-02-22 00:00:00
Creation Date2019-02-22 10:38:41
Producing SoftwareMicrosoft® Word 2010
Document Lastmod2019-02-22 10:39:09
Document TitleHD 271 S1
Document CreatorMicrosoft® Word 2010
Document Author: LAB02

Source Exif Data [exif.tools]:
File Type                       : PDF
File Type Extension             : pdf
MIME Type                       : application/pdf
PDF Version                     : 1.6
Linearized                      : No
Author                          : LAB02
Create Date                     : 2019:02:22 10:38:41+08:00
Modify Date                     : 2019:02:22 10:39:09+08:00
Language                        : zh-CN
XMP Toolkit                     : Adobe XMP Core 5.2-c001 63.139439, 2010/09/27-13:37:26
Format                          : application/pdf
Creator                         : LAB02
Title                           : HD 271 S1
Creator Tool                    : Microsoft® Word 2010
Metadata Date                   : 2019:02:22 10:39:09+08:00
Producer                        : Microsoft® Word 2010
Document ID                     : uuid:6818b936-c2ae-4aba-9754-70c0f8b2183e
Instance ID                     : uuid:ec9be7ee-550a-48b5-8625-1e867ad99f6b
Page Count                      : 41
