FCC ID 2ABPTYX4400
Short Range Device - Pedometer
by Wincotime Electronic Ltd
Grantee Code: 2ABPT Product Code: YX4400
Latest application date: 2015-09-18
Device Images
FCC ID Device Details
| FCC ID | 2ABPTYX4400 |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | 2ABPT |
| Product Code | YX4400 |
| Applicant Business | Wincotime Electronic Ltd |
| Related Domains |  winct.com.hk |
| Equipment Class | Short Range Device - Pedometer |
| Test Firm | Hong Kong Productivity Council |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 2402-2480 MHz | Original Equipment | 2015-09-18 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| Users Manual | Users Manual | 2015-09-18 | PDF 417.3 KB |
| Photos Internal | Internal Photos | 2015-09-18 | PDF 328.1 KB |
| Photos External | External Photos | 2015-09-18 | PDF 200.5 KB |
| Label Information | ID Label/Location Info | 2015-09-18 | PDF 75.3 KB |
| Photos - Test Setup | Test Setup Photos | 2015-09-18 | PDF 1.1 MB |
| Test Report | Test Report | 2015-09-18 | PDF 490.4 KB |
| Test Report - Measurement Results | Test Report | 2015-09-18 | PDF 88.7 KB |
| Test Report - RF Exposure | Test Report | 2015-09-18 | PDF 27.3 KB |
| Agent Authorization Letter | Cover Letter(s) | 2015-09-18 | PDF 262.4 KB |
| Confidentiality Request | Cover Letter(s) | 2015-09-18 | PDF 271.3 KB |
| Block Diagram Metadata only | Block Diagram | PDF 19.7 KB | |
| Schematics Metadata only | Schematics | PDF 391.3 KB | |
| Operational Description Metadata only | Operational Description | PDF 16.5 KB | |
| BOM Metadata only | Parts List/Tune Up Info | PDF 35.7 KB |
Application Information
| Application ID | x5wQglviFL1szTR5aCmuSA== |
|---|---|
| Final Action Date | 2015-09-18 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0023266703 |
| Model | YX4400 |
| Frequency Range | 2402-2480 MHz |
| Equipment Class | DXX - Part 15 Low Power Communication Device Transmitter |
| Device Description | Short Range Device - Pedometer |
| Responsible Party | Eric Ho, QA Manager, eric@winct.com.hk , 852 29470911 |
| Agent | Benny Benny Benny, TUV Rheinland Hong Kong Ltd., Benny.Lau@tuv.com  , 0085221921000 |
| Technical Contact | Benny Lau, TUV Rheinland Hong Kong Ltd., Benny.Lau@tuv.com , 85221921000 |
| Test Firm | Ir Angel Wong Yuen-yee, Hong Kong Productivity Council, peter@hkpc.org  , 852-2788-6496 |
| TCB Email | fcb@us.tuv.com  |
| TCB Scope | A2: Low Power Transmitters (except Spread Spectrum) and radar detectors operating above 1 GHz |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| x5wQglviFL1szTR5aCmuSA== | 2015-09-18 | Original Equipment |
Equipment Authorization
| Frequency | Rules |
|---|---|
| 2402-2480 MHz | 15C |
Grants
TCB Grant - Application x5wQglviFL1szTR5aCmuSA==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
TUV Rheinland of North America, Inc. 1279 Quarry Lane Suite A Pleasanton, CA 94566 |
Date of Grant: 09/18/2015 Application Dated: 09/18/2015 |
| Wincotime Electronic Ltd |
| Room 2 8/F Fonda Ind Bld |
| 37-39 Au Pui Wan Street Fo Tan Sha Tin NT |
| Hong Kong, Hong Kong |
| Attention: Eric Ho , QA Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2ABPTYX4400 |
| Name of Grantee: | Wincotime Electronic Ltd |
| Equipment Class: | Part 15 Low Power Communication Device Transmitter |
| Notes: | Short Range Device - Pedometer |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2402.0 - 2480.0 |
EAS Grant - Application x5wQglviFL1szTR5aCmuSA==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Wincotime Electronic Ltd Room 2 8/F Fonda Ind Bld 37-39 Au Pui Wan Street Fo Tan Sha Tin NT Hong Kong, Hong Kong |
Date of Grant: 09/18/2015 Application Dated: 09/18/2015 |
| Attention: Eric Ho , QA Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2ABPTYX4400 |
| Name of Grantee: | Wincotime Electronic Ltd |
| Equipment Class: | Part 15 Low Power Communication Device Transmitter |
| Notes: | Short Range Device - Pedometer |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2402.0 - 2480.0 |
| Mail To: |
