FCC ID 2ABPTYX4850
Wireless Activity Band
by Wincotime Electronic Ltd
Grantee Code: 2ABPT Product Code: YX4850
Latest application date: 2016-12-07
Device Images
FCC ID Device Details
| FCC ID | 2ABPTYX4850 |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | 2ABPT |
| Product Code | YX4850 |
| Applicant Business | Wincotime Electronic Ltd |
| Related Domains |  winct.com.hk  tuv.com |
| Equipment Class | Wireless Activity Band |
| Test Firm | Hong Kong Productivity Council |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 2402-2480 MHz | Original Equipment | 2016-12-07 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| Users Manual | Users Manual | 2016-12-07 | PDF 5.3 MB |
| Internal Photos | Internal Photos | 2016-12-07 | PDF 428.5 KB |
| External Photos | External Photos | 2016-12-07 | PDF 335.3 KB |
| ID Label Location Info | ID Label/Location Info | 2016-12-07 | PDF 83.2 KB |
| Test Setup Photos | Test Setup Photos | 2016-12-07 | PDF 538 KB |
| Test Report | Test Report | 2016-12-07 | PDF 1 MB |
| Test Report Annex Test Results | Test Report | 2016-12-07 | PDF 466.1 KB |
| Agent Authorization Letter | Cover Letter(s) | 2016-12-07 | PDF 254.9 KB |
| Confidentiality Request Letter | Cover Letter(s) | 2016-12-07 | PDF 256.3 KB |
| Radio Frequency Exposure | RF Exposure Info | 2016-12-07 | PDF 55.8 KB |
| Block Diagram Metadata only | Block Diagram | PDF 33.5 KB | |
| Schematics Metadata only | Schematics | PDF 40.8 KB | |
| Operational Description Metadata only | Operational Description | PDF 16 KB |
Application Information
| Application ID | p95b34zokL3ybf88aLSBYQ== |
|---|---|
| Final Action Date | 2016-12-07 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0023266703 |
| Model | YX4850 |
| Frequency Range | 2402-2480 MHz |
| Equipment Class | DTS - Digital Transmission System |
| Device Description | Wireless Activity Band |
| Responsible Party | Eric Ho, QA Manager, eric@winct.com.hk , 852 29470911 |
| Agent | Benny Benny Benny, TUV Rheinland Hong Kong Ltd., Benny.Lau@tuv.com , 0085231921000 |
| Technical Contact | Benny Lau, TUV Rheinland Hong Kong Limited, benny.lau@tuv.com , 0085221921000 |
| Non-Technical Contact | Benny Lau, TUV Rheinland Hong Kong Limited, benny.lau@tuv.com , 0085221921000 |
| Test Firm | Ir Angel Wong Yuen-yee, Hong Kong Productivity Council, peter@hkpc.org  , 852-2788-6496 |
| TCB Email | fcb@us.tuv.com  |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Output power listed is conducted. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| p95b34zokL3ybf88aLSBYQ== | 2016-12-07 | Original Equipment |
Equipment Authorization
| Frequency | Output | Rules |
|---|---|---|
| 2402-2480 MHz | 0.0000030 | 15C |
Grants
TCB Grant - Application p95b34zokL3ybf88aLSBYQ==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
TUV Rheinland of North America, Inc. 1279 Quarry Lane Suite A Pleasanton, CA 94566 |
Date of Grant: 12/07/2016 Application Dated: 12/07/2016 |
| Wincotime Electronic Ltd |
| Room 2 8/F Fonda Ind Bld |
| 37-39 Au Pui Wan Street Fo Tan Sha Tin NT |
| Hong Kong, Hong Kong |
| Attention: Eric Ho , QA Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2ABPTYX4850 |
| Name of Grantee: | Wincotime Electronic Ltd |
| Equipment Class: | Digital Transmission System |
| Notes: | Wireless Activity Band |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2402.0 - 2480.0 | 0.000003 |
| Output power listed is conducted. |
EAS Grant - Application p95b34zokL3ybf88aLSBYQ==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Wincotime Electronic Ltd Room 2 8/F Fonda Ind Bld 37-39 Au Pui Wan Street Fo Tan Sha Tin NT Hong Kong, Hong Kong |
Date of Grant: 12/07/2016 Application Dated: 12/07/2016 |
| Attention: Eric Ho , QA Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2ABPTYX4850 |
| Name of Grantee: | Wincotime Electronic Ltd |
| Equipment Class: | Digital Transmission System |
| Notes: | Wireless Activity Band |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2402.0 - 2480.0 | 0.000003 |
| Output power listed is conducted. |
