FCC ID 2ABT4TS100WU
Toucan Smart Socket
by Sky Light Imaging Limited
Grantee Code: 2ABT4 Product Code: TS100WU
Latest application date: 2016-05-09
Device Images
FCC ID Device Details
| FCC ID | 2ABT4TS100WU |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | 2ABT4 |
| Product Code | TS100WU |
| Applicant Business | Sky Light Imaging Limited |
| Related Domains |  sky-light.com.hk |
| Equipment Class | Toucan Smart Socket |
| Test Firm | EMTEK (Shenzhen) Co., Ltd. |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 2402-2480 MHz | Original Equipment | 2016-05-09 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| User manual | Users Manual | 2016-05-09 | PDF 2.2 MB |
| Int photo | Internal Photos | 2016-05-09 | PDF 284.6 KB |
| Ext photo | External Photos | 2016-05-09 | PDF 890.5 KB |
| ID label | ID Label/Location Info | 2016-05-09 | PDF 140 KB |
| ID label location | ID Label/Location Info | 2016-05-09 | PDF 79.9 KB |
| Test setup photo | Test Setup Photos | 2016-05-09 | PDF 308.8 KB |
| Test report | Test Report | 2016-05-09 | PDF 2.6 MB |
| Confidential request letter | Cover Letter(s) | 2016-05-09 | PDF 29.2 KB |
| POA | Cover Letter(s) | 2016-05-09 | PDF 90.1 KB |
| MPE | RF Exposure Info | 2016-05-09 | PDF 19.2 KB |
| Block diagram Metadata only | Block Diagram | PDF 36.3 KB | |
| SCH Metadata only | Schematics | PDF 78 KB | |
| OpDes Metadata only | Operational Description | PDF 84.1 KB |
Application Information
| Application ID | D5QVj5BK5+EQBXJi4AaiVw== |
|---|---|
| Final Action Date | 2016-05-09 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0023351026 |
| Model | TS100WU |
| Frequency Range | 2402-2480 MHz |
| Equipment Class | DTS - Digital Transmission System |
| Device Description | Toucan Smart Socket |
| Responsible Party | Zeng Hui, zenghui@sky-light.com.hk , 86-755-27511234 |
| Test Firm | David Lee, EMTEK (Shenzhen) Co., Ltd., david.lee@emtek.com.cn  , 86-755-26504659 |
| TCB Email | TCB@siemic.com  |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Power listed is the maximum conducted output power. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter, except in accordance with FCC multi- transmitter product procedures. End-Users must be provided with transmitter operation conditions for satisfying RF exposure compliance. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| D5QVj5BK5+EQBXJi4AaiVw== | 2016-05-09 | Original Equipment |
Equipment Authorization
| Frequency | Output | Rules |
|---|---|---|
| 2402-2480 MHz | 0.0009000 | 15C |
Grants
TCB Grant - Application D5QVj5BK5+EQBXJi4AaiVw==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Bureau Veritas Consumer Products Services, Inc. 775 Montague Expressway Milpitas, CA 95035 |
Date of Grant: 05/09/2016 Application Dated: 05/09/2016 |
| Sky Light Imaging Limited |
| Room 1910, 19/F, Kwong Sang Hong Centre 151-153 |
| Hoi Bun Road, Kwun Tong, Kowloon |
| Hong Kong, Hong Kong |
| Attention: Zeng Hui |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2ABT4TS100WU |
| Name of Grantee: | Sky Light Imaging Limited |
| Equipment Class: | Digital Transmission System |
| Notes: | Toucan Smart Socket |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2402.0 - 2480.0 | 0.0009 |
| Power listed is the maximum conducted output power. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter, except in accordance with FCC multi- transmitter product procedures. End-Users must be provided with transmitter operation conditions for satisfying RF exposure compliance. |
EAS Grant - Application D5QVj5BK5+EQBXJi4AaiVw==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Sky Light Imaging Limited Room 1910, 19/F, Kwong Sang Hong Centre 151-153 Hoi Bun Road, Kwun Tong, Kowloon Hong Kong, Hong Kong |
Date of Grant: 05/09/2016 Application Dated: 05/09/2016 |
| Attention: Zeng Hui |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2ABT4TS100WU |
| Name of Grantee: | Sky Light Imaging Limited |
| Equipment Class: | Digital Transmission System |
| Notes: | Toucan Smart Socket |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2402.0 - 2480.0 | 0.0009 |
| Power listed is the maximum conducted output power. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter, except in accordance with FCC multi- transmitter product procedures. End-Users must be provided with transmitter operation conditions for satisfying RF exposure compliance. |
