DF1 DF1 is a remote sensor device measuring... - FCC ID 2ABTJ-DF1

FCC ID 2ABTJ-DF1

Schematics

DF1 is a remote sensor device measuring 3-axis accelerations and communicating data via a wireless connection to a base station.

by Device Ideas

Document preview loads when visible.

Document Details

FCC ID2ABTJ-DF1
Document ID2256459
Document TypeSchematics
DescriptionSchematics
ApplicantDevice Ideas
Equipment ClassDF1 is a remote sensor device measuring 3-axis accelerations and communicating data via a wireless connection to a base station.
Product CodeDF1
Application IDJ1Oj2kL8v0jeiRGH/AgGqQ==
Application PurposeOriginal Equipment
Application Date2014-05-01
Frequency Range2402-2480 MHz
FRN0023341928
Test FirmEUROFINS ELECTRICAL AND ELECTRONIC TESTING NA, INC
Certified ByDaniel Rose Partner
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2014-05-01
Available2014-05-01
Created2014-02-09
Modified2014-02-09
Pages3
File TypeAdobe Acrobat PDF
File Size92801
File SHA-2565bf62972ee8e0d52418dd7c1de4a1333b124e4664d2fc5fe2bfc033e26e0f9a2
PDF Metadata Producerpdftk 1.44 - www.pdftk.com itext-paulo-155 (itextpdf.sf.net-lowagie.com)
FCC.gov SourcesFCC.gov 2256459
