120 Transmitter Teardown Internal Photos - FCC ID 2ABYN120
FCC ID 2ABYN120
Internal photos
Transmitter
Document preview loads when visible.
Document Details
| FCC ID | 2ABYN120 |
|---|---|
| Document ID | 7487569 |
| Document Type | Internal Photos |
| Description | Internal photos |
| Document Title | ATTACHMENT PHOTOGRAPHS OF EUT |
| Applicant | GODOX PHOTO EQUIPMENT CO.,LTD |
| Equipment Class | Transmitter |
| Product Code | 120 |
| Application ID | mxoxayVxZd1guE1yd87kXA== |
| Application Purpose | Original Equipment |
| Application Date | 2024-07-19 |
| Frequency Range | 2402-2480 MHz |
| FRN | 0032751521 |
| Test Firm | Shenzhen NTEK Testing Technology Co., Ltd. |
| Certified By | Alex Li |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Short-Term Confidentiality Date | 01/15/2025 |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Submitted | 2024-07-18 |
| Available | 2025-01-15 |
| Created | 2024-07-02 |
| Modified | 2024-07-02 |
| Pages | 3 |
| File Type | Adobe Acrobat PDF |
| File Size | 448083 |
| File SHA-256 | 17e15bdaa3981f7c9d8be9d6855a4bce701fb624caa198d9e24df1f37a5ece2a |
| PDF Metadata Author | 高莹莹 Sky123.Org |
| PDF Metadata Producer | 高莹莹 Adobe PDF Library 11.0 |
| FCC.gov Sources | FCC.gov 7487569 |
