TUW8402A Tablet PC Test Setup Photos - FCC ID 2ABZATU-W8402A
FCC ID 2ABZATU-W8402A
2ABZATU-W8402A Setup Photos
Tablet PC
Document preview loads when visible.
Document Details
| FCC ID | 2ABZATU-W8402A |
|---|---|
| Document ID | 2569262 |
| Document Type | Test Setup Photos |
| Description | 2ABZATU-W8402A Setup Photos |
| Document Title | 2ABZATU-W8402A Setup Photos |
| Applicant | Xie He Kong Company Limited |
| Equipment Class | Tablet PC |
| Product Code | TUW8402A |
| Application ID | AVPc6c3mIfHyjR4iHtfKog== |
| Application Purpose | Original Equipment |
| Application Date | 2015-03-30 |
| Frequency Range | 2412-2462 MHz |
| FRN | 0023419278 |
| Test Firm | Keyway Testing Technology Co., Ltd. |
| Certified By | Yuan Ping |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Submitted | 2015-03-29 |
| Available | 2015-03-30 |
| Created | 2015-03-20 |
| Modified | 2015-03-20 |
| Pages | 2 |
| File Type | Adobe Acrobat PDF |
| File Size | 163680 |
| File SHA-256 | 8dd85616d56ad827b95d7c831f514552a0816a1bc2e5d816d9657daed8f2a6fe |
| PDF Metadata Author | lenovo |
| PDF Metadata Producer | Acrobat Distiller 10.1.0 (Windows) lenovo |
| FCC.gov Sources | FCC.gov 2569262 |
