FCC ID 2ABZMAP340
Wireless Access Point
by SHENZHEN IP-COM NETWORKS CO.,LTD.
Grantee Code: 2ABZM Product Code: AP340
Latest application date: 2016-01-13
Device Images
FCC ID Device Details
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 2412-2462 MHz | Original Equipment | 2016-01-13 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| Users Manual | Users Manual | 2016-01-13 | PDF 4.7 MB |
| Int Photos | Internal Photos | 2016-01-13 | PDF 430.1 KB |
| Ext Photos | External Photos | 2016-01-13 | PDF 315.1 KB |
| FCC ID Label | ID Label/Location Info | 2016-01-13 | PDF 53.2 KB |
| Setup Photos | Test Setup Photos | 2016-01-13 | PDF 211.3 KB |
| Test Report | Test Report | 2016-01-13 | PDF 3.2 MB |
| Confidentiality Letter | Cover Letter(s) | 2016-01-13 | PDF 240.6 KB |
| POA | Cover Letter(s) | 2016-01-13 | PDF 213.1 KB |
| RF Exposure | RF Exposure Info | 2016-01-13 | PDF 123.7 KB |
| Block Diagram Metadata only | Block Diagram | PDF 115.5 KB | |
| Schematics Metadata only | Schematics | PDF 2 MB | |
| Circuit Description Metadata only | Operational Description | PDF 24 KB |
Application Information
| Application ID | FHKx+LHRLsFW7n9qizQNsQ== |
|---|---|
| Final Action Date | 2016-01-13 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0023428113 |
| Model | AP340 |
| Frequency Range | 2412-2462 MHz |
| Equipment Class | DTS - Digital Transmission System |
| Device Description | Wireless Access Point |
| Responsible Party | Shen Yue, Engineer, cert@tenda.cn  , 86-755-2765 7098 |
| Test Firm | John Chan, Bay Area Compliance Laboratories Corp. (Dongguan), john.chan@baclcorp.com  , 86-769-86858888 |
| TCB Email | bacl.regulatory@baclcorp.com |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Output power listed is conducted. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. Users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. The device supports 20 MHz and 40 MHz bandwidth modes. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| FHKx+LHRLsFW7n9qizQNsQ== | 2016-01-13 | Original Equipment |
Grants
TCB Grant - Application FHKx+LHRLsFW7n9qizQNsQ==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Bay Area Compliance Laboratory Corp. 1274 Anvilwood Avenue Sunnyvale, CA 94089 |
Date of Grant: 01/13/2016 Application Dated: 01/13/2016 |
| SHENZHEN IP-COM NETWORKS CO.,LTD. |
| Unit A, First Floor, Tower E3, No. 1001, |
| Zhongshanyuan Road,Nanshan District, |
| Shenzhen, 518052 China |
| Attention: Shen Yue , Engineer |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2ABZMAP340 |
| Name of Grantee: | SHENZHEN IP-COM NETWORKS CO.,LTD. |
| Equipment Class: | Digital Transmission System |
| Notes: | Wireless Access Point |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| MO | 15C | 2412.0 - 2462.0 | 0.847 |
| Output power listed is conducted. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. Users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. The device supports 20 MHz and 40 MHz bandwidth modes. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
EAS Grant - Application FHKx+LHRLsFW7n9qizQNsQ==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
SHENZHEN IP-COM NETWORKS CO.,LTD. Unit A, First Floor, Tower E3, No. 1001, Zhongshanyuan Road,Nanshan District, Shenzhen, 518052 China |
Date of Grant: 01/13/2016 Application Dated: 01/13/2016 |
| Attention: Shen Yue , Engineer |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2ABZMAP340 |
| Name of Grantee: | SHENZHEN IP-COM NETWORKS CO.,LTD. |
| Equipment Class: | Digital Transmission System |
| Notes: | Wireless Access Point |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| MO | 15C | 2412.0 - 2462.0 | 0.847 |
| Output power listed is conducted. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. Users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. The device supports 20 MHz and 40 MHz bandwidth modes. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
| Mail To: |
