WCT5J WIFI+BT Module Label Diagram - FCC ID 2AC23-WCT5J

FCC ID 2AC23-WCT5J

Label and Label Location

WIFI+BT Module

by Hui Zhou Gaoshengda Technology Co.,LTD

Document preview loads when visible.

Document Details

FCC ID2AC23-WCT5J
Document ID4693685
Document TypeID Label/Location Info
DescriptionLabel and Label Location
Document Title1
ApplicantHui Zhou Gaoshengda Technology Co.,LTD
Equipment ClassWIFI+BT Module
Product CodeWCT5J
Application IDRFp8Z+UIeOoG73T9AhnOcg==
Application PurposeOriginal Equipment
Application Date2020-04-19
Frequency Range5180-5240 MHz
FRN0023889280
Test FirmUL Verification Services (Guangzhou) Co., Ltd.
Certified ByHui Guan Manager
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentSingle Modular Approval
Composite DeviceYes
Composite PartNo
Submitted2020-04-19
Available2020-04-19
Created2020-04-20
Modified2020-04-20
Pages1
File TypeAdobe Acrobat PDF
File Size67386
File SHA-256fa5ef09c2b2e7b8235d59f3e63dc591ed0e74c2b05eaabb253d6b9b37ac04c85
