WXT5V WIFI+BT Module Label Diagram - FCC ID 2AC23-WXT5V

FCC ID 2AC23-WXT5V

Label and location

WIFI+BT Module

by Hui Zhou Gaoshengda Technology Co.,LTD

Document preview loads when visible.

Document Details

FCC ID2AC23-WXT5V
Document ID7402136
Document TypeID Label/Location Info
DescriptionLabel and location
ApplicantHui Zhou Gaoshengda Technology Co.,LTD
Equipment ClassWIFI+BT Module
Product CodeWXT5V
Application IDQmQFgPG1xMIv9B4WCv3Ykw==
Application PurposeOriginal Equipment
Application Date2024-06-15
Frequency Range5180-5240 MHz
FRN0023889280
Test FirmUL Verification Services (Guangzhou) Co., Ltd.
Certified ByHui Guan
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentSingle Modular Approval
Composite DeviceYes
Composite PartNo
Submitted2024-06-15
Available2024-06-15
Created2020-07-09
Modified2024-06-06
Pages1
File TypeAdobe Acrobat PDF
File Size496059
File SHA-2560596588e51630f9e6ab3544f8aa5a8b8fe58956fce9980372eddafeb6f1fd96d
PDF Metadata ProducerSkyPDF Driver 4.0.13 Build 12
FCC.gov SourcesFCC.gov 7402136, FCC.gov 7402115, FCC.gov 7402098
