WTM1D15 Wireless Power Transmitter Module... - FCC ID 2AC3UWTM1D15
FCC ID 2AC3UWTM1D15
Test Setup Photo
Wireless Power Transmitter Module
Document preview loads when visible.
Document Details
| FCC ID | 2AC3UWTM1D15 |
|---|---|
| Document ID | 5183206 |
| Document Type | Test Setup Photos |
| Description | Test Setup Photo |
| Applicant | Channel Well Technology Co., Ltd. |
| Equipment Class | Wireless Power Transmitter Module |
| Product Code | WTM1D15 |
| Application ID | nl92STI75oLeDKDsVxAwfA== |
| Application Purpose | Original Equipment |
| Application Date | 2021-04-08 |
| Frequency Range | 0.12-0.13 MHz |
| FRN | 0017931452 |
| Test Firm | Audix Technology Corporation |
| Certified By | Ben Cheng |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Grant Deferral | No |
| Modular Equipment | Limited Single Modular Approval |
| Composite Device | No |
| Composite Part | No |
| Submitted | 2021-03-30 |
| Available | 2021-04-08 |
| Created | 2021-03-11 |
| Modified | 2021-03-11 |
| Pages | 5 |
| File Type | Adobe Acrobat PDF |
| File Size | 953369 |
| File SHA-256 | 421efed73ff4781e251fda33b9ab0ea01d3c74cdccbd4079db420a9e317153a0 |
| PDF Metadata Author | tina_huang |
| PDF Metadata Producer | Microsoft® Word 2010 Microsoft® Word 2010 |
| FCC.gov Sources | FCC.gov 5183206 |
