FCC ID 2AC46-DS003
ActiveSense Rodent Sensor
by Mesh Systems LLC
Grantee Code: 2AC46 Product Code: DS003
Latest application date: 2016-03-18
Device Images
FCC ID Device Details
| FCC ID | 2AC46-DS003 |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | 2AC46 |
| Product Code | DS003 |
| Applicant Business | Mesh Systems LLC 🇺🇸 |
| Related Domains |  mesh-systems.com |
| Equipment Class | ActiveSense Rodent Sensor |
| Test Firm | International Compliance Laboratories, LLC |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 904.5-926.5 MHz | Original Equipment | 2016-03-18 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| Manual | Users Manual | 2016-05-02 | PDF 1.6 MB |
| Internal Photos | Internal Photos | 2016-05-02 | PDF 969.2 KB |
| External Photos | External Photos | 2016-05-02 | PDF 819.1 KB |
| Label Information 1 of 2 | ID Label/Location Info | 2016-03-18 | PDF 8.7 KB |
| Label Information 2 of 2 | ID Label/Location Info | 2016-03-18 | PDF 571.5 KB |
| Test Setup Photos | Test Setup Photos | 2016-05-02 | PDF 801.1 KB |
| Test Report | Test Report | 2016-03-18 | PDF 2.3 MB |
| Agency Agreement | Cover Letter(s) | 2016-03-18 | PDF 594.9 KB |
| Confidentiality Request | Cover Letter(s) | 2016-03-18 | PDF 592.2 KB |
| Block Diagram Metadata only | Block Diagram | PDF 13.1 KB | |
| Schematics Metadata only | Schematics | PDF 38.9 KB | |
| Theory of Operation Metadata only | Operational Description | PDF 22.8 KB | |
| Parts List Metadata only | Parts List/Tune Up Info | PDF 44.4 KB |
Application Information
| Application ID | onFMw/XffTwragDwTf/jww== |
|---|---|
| Final Action Date | 2016-03-18 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0023906472 |
| Model | DS003 |
| Frequency Range | 904.5-926.5 MHz |
| Equipment Class | DTS - Digital Transmission System |
| Device Description | ActiveSense Rodent Sensor |
| Responsible Party | Nate Welch, Associate Embedded Engineer, nate.welch@mesh-systems.com , 920-363-0563 |
| Agent | Daniel Daniel Daniel, International Compliance Laboratories, LLC |
| Test Firm | Ronald Zimmerman, International Compliance Laboratories, LLC, rzimmerman@icl-us.com  , 920-720-5555 |
| TCB Email | jwoods@acstestlab.com  |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | Yes |
| Short-Term Confidentiality Date | 05/02/2016 |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Power listed is conducted. The antenna for this transmitter must not be co-located or operating in conjunction with any other antenna or transmitter except in accordance with FCC multi-transmitter product procedures. Users and installers must be provided with antenna installation instructions and transmitter operating conditions if required for satisfying RF exposure compliance. Device must operate with a source-based, time-averaged duty cycle not to exceed 11.6% controlled by firmware or software. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| onFMw/XffTwragDwTf/jww== | 2016-03-18 | Original Equipment |
Equipment Authorization
| Frequency | Output | Rules |
|---|---|---|
| 904.5-926.5 MHz | 0.0188000 | 15C |
Grants
TCB Grant - Application onFMw/XffTwragDwTf/jww==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
TUV SUD America Inc. 401 Edgewater Place Suite #500 Wakefield, MA 01880 |
Date of Grant: 03/18/2016 Application Dated: 03/18/2016 |
| Mesh Systems LLC |
| 1920 N Casaloma Drive |
| Appleton, WI 54913 |
| Attention: Nate Welch , Associate Embedded Engineer |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2AC46-DS003 |
| Name of Grantee: | Mesh Systems LLC |
| Equipment Class: | Digital Transmission System |
| Notes: | ActiveSense Rodent Sensor |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 904.5 - 926.5 | 0.0188 |
| Power listed is conducted. The antenna for this transmitter must not be co-located or operating in conjunction with any other antenna or transmitter except in accordance with FCC multi-transmitter product procedures. Users and installers must be provided with antenna installation instructions and transmitter operating conditions if required for satisfying RF exposure compliance. Device must operate with a source-based, time-averaged duty cycle not to exceed 11.6% controlled by firmware or software. |
EAS Grant - Application onFMw/XffTwragDwTf/jww==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Mesh Systems LLC 1920 N Casaloma Drive Appleton, WI 54913 United States |
Date of Grant: 03/18/2016 Application Dated: 03/18/2016 |
| Attention: Nate Welch , Associate Embedded Engineer |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2AC46-DS003 |
| Name of Grantee: | Mesh Systems LLC |
| Equipment Class: | Digital Transmission System |
| Notes: | ActiveSense Rodent Sensor |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 904.5 - 926.5 | 0.0188 |
| Power listed is conducted. The antenna for this transmitter must not be co-located or operating in conjunction with any other antenna or transmitter except in accordance with FCC multi-transmitter product procedures. Users and installers must be provided with antenna installation instructions and transmitter operating conditions if required for satisfying RF exposure compliance. Device must operate with a source-based, time-averaged duty cycle not to exceed 11.6% controlled by firmware or software. |
